Floureon FC100 User Manual

TWO-WAY RADIO
User Manual
Keypad Control and Function
Antenna
Channel+ key
Channel- key/Call tone key
PTT key
Note: LED only displays the channel
FC100
LED display
ON/OFF key
Volume+ key
Volume- key/Lock key
Microphone
Speaker
Features
● 9 Channels
● Up to 1.5km range
● 5 call tones for selection
● Call Roger Tone
● Keypad Tone
● Auto power off (1.5h)
● Keypad Lock
● Auto Squelch Control
● Battery Save
● Low Battery Alert
● TOT (time-out timer)
● Volume (0-7)
Installing the Batteries
1. Remove the battery cover.
2. Insert 3 AAA Alkaline Batteries with +
and - polarity as shown inside.
3. Close the battery cover firmly.
Auto Power Off
If there is no
responsein 1.5 hour,
the radio will turn off
automatically.
2
Turn Radio On and Off
1. Press and hold [ ] key for 3 seconds to
turn the radio on or off.
2. Upon power on, the radio chirps and
briefly shows all feature icons available
on the radio.
3. The display screen then shows the
current channel, and all features that
are enabled.
Setting the Volume
1. Press VOL[▲] key to increase the
volume level.
2. Press VOL[▼/ ] key to decrease the
volume level or mute the speaker.
NOTE:
Do not hold the radio close to your
ear, if the volume is set to
uncomfortable level, it could hurt you
hear.
1
3
