Page 1 TITAN IMPRESSIONS...
Page 2 TEMPLE DISASSEMBLY Hold the frame side parts with the mounting pliers. Slightly bend the temple, and pull it straight backwards out of the disc-hinge ATTENTION: Only pull the temple backwards, not up or down.
Page 3 FIXING BLS-HINGE Always use a new disc when installing the temple. Place BLS disc hinge on both sides of the loop. NOTE: The oval shape of the BLS‘ plug system ensures correct positioning.
Page 4 TEMPLE ASSEMBLY Align the temple at the slot of the disc hinge. Push temple carefully forwards, until it clicks all the way in.
Page 5 INCLINATION Inclination Inclination groove groove Hold flat pliers at the hinge Remove the temple and hinge disc. loop and carefully bend to the Hold lens fixation firmly in its desired position. position with mounting pliers.
Page 6 TEMPLE END DISASSEMBLY Pull off temple end in a small Loosen the glue by pressing the beginning of rotating motion. the temple end softly with the flat pliers. NOTE: This temple design cannot be shortened Protect temple surface with a cleaning cloth.
Page 7 TEMPLE CURVING - ADJUSTMENT Curve temple and temple end in a large, gradual motion. Do not use a frame warmer or bend the metal of the frame.
