LIGHT INC UPFOGGER 1500 RGB Manual

Thank you for buying the Light-inc UPFOGGER 1500 RGB. For your own
safety, please read this user manual carefully before installing the device.
When receiving the machine, open the package and check carefully whether
the machine is damaged or the accessories are lost, if any problems, please
contact the supplier.
Technical Parameters
Power: 1500W
Voltage: AC 230V 50Hz
Control mode: LCD display, DMX 512, wireless remote control
Warm-up time: 3 minutes
Capacity of tank: 2 liters
Fluid consumption (100% output): 18000 Cu. ft/min
Smoke distance: 6-8 meters
Weight: 12.3kgs
...............................................................■
Guidance
1. This product can be installed upwards or placed on the ground.
2. Keep the fog machine flat, do not tilt or flip. Before connecting this unit to
the mains power supply, you must add the fluid tank with high quality fog
fluid and check that the nozzle is clean and unobstructed.
3. Before connect to power, you should check whether the voltage you use is
suitable for the fog machine or not.
4. Power cord should be plugged in to a grounded electrical outlet and put the
switch to "ON". Then the fog machine starts warming up and you can spray
fog after warming up is completed.
Control Mode......................................................■
1. Remote control key functions:
Button A: Fog + 100% Red
Button B: Fog + 100% Red + 40% Blue
2. DMX control: 7 DMX channels.
CH1: Smoke output CH2: red light
CH5: LED strobe CH6: built-in program CH7: built-in program speed
Button C: Fog + 100% Blue
Button D: Fog + 100% Red + 40% Green
CH3: green light CH4: blue light
3. LCD display
Function
Button
FUNCTION Enters the programming mode
UP Value adjustment upward
DOWN Value adjustment downward
TIMER Starts the timer controlled operation
VOLUME Starts or stops all operation
MANUAL Press and hold for manual fog output
1——200
Interval
Duration 1——200
DMX512 1——512
Volume 1——100
Red 0——255
Blue 0——255
Skip 0——255
Notice 1...............................................................■
1. This fog machine should be used in dry and well-ventilated place.
Please avoid any water or rain fall in the machines, if water or rain falls
in, turn off the power immediately. The distance to another object should
be at least 30cm. Keep far away from children, fire, explosive and
flammable things.
2. When the fog fluid is running out, add fog fluid in time. If the fog
machine is out of fluid, the pump and other parts will get damaged.
When adding fluid, remember to turn off the power and carefully avoid
spilling over.
3. The fog machine should work under professional worker's super
vision, please do not add flammable liquids, gas or perfume into the fog
fluid tank.
4. All fog machine will have condensation or moisture around the nozzle.
5. All fog machine have cycles and temperature cooling to a point, the
pump will automatically turn on and begin heating, until heating
complete, the machine starts to spray smoke.
Pause time between timed output
Duration time of timed operation
Set the starting DMX address
et the volume output
S
Green 0——255
Glint 0——255
Gradual 0——255
