- Page 1 MiCOM H16X Global Documentation H16x/EN GL/A11...
-
Page 3: Table Of Contents
MiCOM H16x FUNCTIONAL DESCRIPTION MiCOM H16x Range Ultra fast redundant dual-homing capability 3.2.1 Dual-homing principles 3.2.2 MiCOM H16x Ethernet switch with dual-homing facilities 3.2.3 Max time of end to end delay 3.2.4 Benefices MiCOM H16x functional composition Ethernet Port Switching Features 3.4.1... - Page 4 3.5.5 Broadcast storm protection 3.5.6 Auto Negotiation and Speed-Sensing 3.5.7 Forwarding 3.5.8 Priority tagging 3.5.9 VLAN Operation TECHNICAL DATA MiCOM H16x Range HUMAN MACHINE INTERFACE INSTALLATION Installing the Controller HARDWARE Indentification Label CONNECTION Ethernet connection 8.1.1 Ethernet cable type 8.1.2...
-
Page 5: Safety & Handling
Page 3/26 SAFETY & HANDLING Introduction The present document describes the safety, handling, packing and unpacking procedures applicable to MiCOM H16x Ethernet Switch Range and associated equipments. Safety WARNING: This safety section should be read before commencing any work on the equipment. -
Page 6: Decommissioning And Disposal
Decommissioning and Disposal Decommissioning: The auxiliary supply circuit in the MiCOM H16x may include capacitors across the supply or to earth. To avoid electric shock or energy hazards, after completely isolating the supplies to the MiCOM H16x (both poles of any dc supply), the capacitors should be safely discharged via the external terminals prior to decommissioning. -
Page 7: Specification Upon Device/People Protection
Global Documentation H16x/EN GL/A11 MiCOM H16x Page 5/26 Specification upon device/people protection The recommended maximum rating of the external protective fuse for this equipment is 16A, Red Spot type of equipment, unless otherwise stated in the technical data section of the product documentation. -
Page 8: Packing And Unpacking
After unpacking the device, inspect it visually to make sure it is in proper mechanical condition. If the MiCOM H16x Ethernet switch needs to be shipped, both inner and outer packaging must be used. If the original packaging is no longer available, make sure that packaging conforms to ISO 2248 specifications for a drop height ≤0.8m. -
Page 9: Copyrights & Trademarks
Global Documentation H16x/EN GL/A11 MiCOM H16x Page 7/26 Expect as specified herein, T&D AUTOMATION makes no guaranties, express or implied and specifically disclaims and guaranties of merchantability or fitness for a particular purpose. Customer's rights to recover damages caused by fault or negligence on the part T&D AUTOMATION shall be limited to the amount therefore paid by the customer. -
Page 10: Introduction
H16x/EN GL/A11 Global Documentation Page 8/26 MiCOM H16x INTRODUCTION MiCOM Ethernet range is designed to address the needs of a wide range of electric plant. Emphasis has been placed on strong compliance to standards, scalability, modularity and openness architecture. These facilitate use in a range of applications from the most basic to the most demanding. -
Page 11: Micom H16X
200 Mbps of data throughput (2 times in duplex the 100Mbps of one link). The MiCOM H16x is plug and play devices. It can running with the factory setting. To adapt the switch to your application you simply configure using the jumpers the necessary... -
Page 12: Functional Description
MiCOM H16x FUNCTIONAL DESCRIPTION The MiCOM H16x is designed to be an Ethernet switch PCI format board. The MiCOM H16x has to be integrated in a PC (industrial or not depending on environment constraints) or in a Box with a PCI connector and a Power supply. - Page 13 SWITCH Network A Network B Dual Homing Dual Homing S0434ENb FIGURE 2 : 4 MiCOM H16x SWITCHES TROUGH 2 OPTICAL STARS Dual Homing « Dual Homing » LinK A et B Dual Homing S0465ENa FIGURE 3 : 2 MiCOM H16x SWITCHES OPTICAL STARS NOT NEEDED...
-
Page 14: Micom H16X Ethernet Switch With Dual-Homing Facilities
MiCOM H16x 3.2.2 MiCOM H16x Ethernet switch with dual-homing facilities The MiCOM H16x is a “repeater” with a standard 802.3 Ethernet switch plus the self healing manager (SHM). The following drawing describes the internal architecture of such device. Parameters :... -
Page 15: Micom H16X Functional Composition
Each Ethernet device inserts its unique “MAC address” into each message it send out. The port on the MiCOM H16x used for given MAC address is automatically learned when a frame is received from that address. Once an address is learned, the MiCOM H16x will route messages to only the appropriate port. -
Page 16: Back Off Operation
VLAN is from the input port and which output ports it sees directly through the MiCOM H16x. For example if port 1 only participated in a VLAN with ports 2 and 9 then one would set bits 0 and 7 in register 13 (Port 1 VLAN Mask Register). Note that different ports can be setup independently. - Page 17 Global Documentation H16x/EN GL/A11 MiCOM H16x Page 15/26 Further, there are provisions to specify the tag value to be inserted on a per port basis. The table below briefly summarizes VLAN features. For more detailed settings see the EEPROM register description.
-
Page 18: Technical Data
H16x/EN GL/A11 Global Documentation Page 16/26 MiCOM H16x TECHNICAL DATA MiCOM H16x Range Ports 10/100BaseTxCopper 100 BaseFx Multi Mode MiCOM H162 10/100BaseT(x) Ports Connector type Shielded RJ45 jack Twisted pair cable Cat 5 Max cable length with Cat 5 100 m... -
Page 19: Human Machine Interface
Global Documentation H16x/EN GL/A11 MiCOM H16x Page 17/26 HUMAN MACHINE INTERFACE Some LED are used to indicate the state of the links. The table below indicates the function of each LED : Function LED number Colour Description Ports Tx 1 - 2 - 3 - 4... -
Page 20: Installation
Global Documentation Page 18/26 MiCOM H16x INSTALLATION The MiCOM H16x can be easily mounted on a standard PCI bus connector in horizontal or vertical position. FIGURE 6 : MiCOM H162 PCI BOARD Installing the Controller To install the MiCOM H16x in the system cabinet: Shut down your computer and disconnect the power cord. - Page 21 Install the controller in the PCI slot Close the computer cabinet and re-attach the power cord. Use the Ethernet twisted pair cables to connect your MiCOM H16x to your PC Ethernet port. Use the Ethernet Optical cables to connect your MiCOM H16x to the Ethernet network...
-
Page 22: Hardware
Indentification Label • On the lower face of the MiCOM H16x a rectangular label is displayed. This stick is enlarged below. The major indication for MiCOM H16x is given with Multi (MiCOM 162) or Single-modefor the kind of optical fiber supported. -
Page 23: Connection
The RJ45 connector when seen face on, flat side on bottom, side tab on top, then pin 1 is on the left and pin 8 on the right. The MiCOM H16x support star network topology on the Ethernet Twisted pair connectors and redundant ring network on the optical ports.. -
Page 24: Settings
H16x/EN GL/A11 Global Documentation Page 22/26 MiCOM H16x SETTINGS Internal Jumpers Meaning Some jumpers are used to adapt the MiCOM H16x to your network: N° Open Closed Factory setting Enable 802.1p selected by EEPROM Enable 802.1p field for all port... -
Page 25: Applications
Global Documentation H16x/EN GL/A11 MiCOM H16x Page 23/26 APPLICATIONS 10.1 Fibber Optic budget calculations Optical power is expressed in Watts. However, the common unit of power measure is the dBm and defined by the following equation: Power (dBm) = 10 log Power (mW) / 1 mW. -
Page 26: Lexical
Each Ethernet device inserts its unique “MAC address” into each message it send out. The port on the MiCOM H16x used for given MAC address is automatically learned when a frame is received from that address. Once an address is learned, the MiCOM H16x will route messages to only the appropriate port. -
Page 27: Flow Control
The MiCOM H16x automatically supports standard flow control frames on both the transmit and receive sides. On the receive side, if the MiCOM H16x receives a pause control frame it will not transmit the next normal frame until the timer, specified in the pause control frame, expires. If another pause frame is received before the current timer expires, the timer will be updated with the new value in the second pause frame. - Page 28 H16x/EN GL/A11 Global Documentation Page 26/26 MiCOM H16x BLANK PAGE...
- Page 30 AREVA T&D's Automation & Information Systems Business www.areva-td.com T&D Worldwide Contact Centre online 24 hours a day: +44 (0) 1785 25 00 70 http://www.areva-td.com/contactcentre/...
