Summary of Contents for Master FORCE 300 N
- Page 1 CLOUD RADIO ____ CHAIN OPERATED ACTUATOR 300 N - ORCE MAXIMUM STROKE Art. 1120.8 230VAC 50 H LECTRICAL FEEDING INSTRUCTION MANUAL ENGLISH...
- Page 2 “presumed in conformity with directives” issued by the EU. MASTER holds the technical file with all the documentation to show that our products have all been inspected to ensure compliance with directives conformity.
-
Page 3: Table Of Contents
Contents 1. Safety indications ..................... 4 2. Formulas and recommendations for installation ............5 2.1. Calculation of opening / closure force ............5 2.2. Maximum opening according to height of sash ..........6 3. Technical information about function ................ 6 4. -
Page 4: Safety Indications
1. Safety indications ATTENTION B EFORE INSTALLING THIS APPLIANCE ENSURE ALL SAFETY INDICATIONS HAVE BEEN READ CAREFULLY AND UNDERSTOOD IN ORDER TO PREVENT CONTACT WITH ELECTRICITY INJURY OR ANY OTHER INCIDENT THE MANUAL SHOULD BE CONSERVED FOR FURTHER CONSULTATION AT A LATER DATE Series CLOUD RADIO chain actuators have been designed to move windows. -
Page 5: Formulas And Recommendations For Installation
WARNING With bottom hung windows injury could be caused if the window accidentally falls. An appropriately sized flexible link arm or fall prevention safety system designed to resist a force equal to at least three times the total weight of the window MUST be installed. -
Page 6: Maximum Opening According To Height Of Sash
2.2. Maximum opening according to height of sash The actuator stroke is in accordance with the height of the sash and its application. Check that the actuator stroke does not touch the profile of the sash and that the chain does not exert force on the window frame (measurements in mm). -
Page 7: Technical Data
The CLOUD RADIO actuator is packed in one single carton. Each package contains: • Actuator with 2 metre (±5%) lead. • Standard support brackets with distancer (A). • Bracket for vertical assembly of the actuator (B). • Bracket for transom window (C). •... -
Page 8: Electric Power Supply
7. Electric power supply Warning. Check that the electric power supply used corresponds to that specified on the “technical data” label attached to the machine. The manufacturer cannot be held liable for damage due to an application which is incorrect or non-compliant with regulatory requirements. The actuator is powered by a mains voltage, in alternating current, of 110/230V~(AC) (+15%, -10%) with a frequency of 50/60 Hz. -
Page 9: Electrical Connection
9. Electrical connection LECTRIC SHOCK HAZARD Before beginning any work on the machine's wiring, make certain that the electric power has been disconnected; failure to observe this rule may compromise safety. Cable entry to the terminal block • No connection symbols indicated to the side. -
Page 10: Saving The Radio Remote Control
10.1.1. Saving the radio remote control The radio remote control supplied is the WI-CONTROL model, with 30 channels and a display, which transmits at the radio frequency of 433.92 MHz; no other radio remote control model is provided for the CLOUD RADIO. Several actuators can be controlled with a single radio remote control, however each channel must correspond to a CLOUD RADIO actuator and thus a window. -
Page 11: Control With Conventional Button
Within 10 seconds, press any one of the up arrow ▲, or down arrow ▼ buttons of STOP the (new) radio remote control that you want to program two times (once to activate the display of the radio remote control and the second time to transmit the radio code). 10.2. -
Page 12: Programming Actuator
13. Programming actuator 13.1. Limit switches at opening Four (4) positions can be selected for the limit switch of the outgoing chain. To program, adjust the two dip-switches near left terminal board, as indicated in the following table. Limit switch at: Dip-switch n°... -
Page 13: Assembly
14. Assembly These indications are intended for the attention of technicians and specialized personnel. Basic job and safety techniques are therefore not included. All preparatory operations, assembly and electrical connections must be carried out by technical and specialized personnel to guarantee best performances and good function of the CLOUD RADIO chain operated actuator. -
Page 14: Assembly With Outward Opening Window
14.2. Assembly with outward opening window. Aside the drawing of specific application using accessories provided. For different mountings, please contact manufacturer. Pencil in an “X” over the centre line of the window frame (Fig. 2). Outward application Select the correct form of brackets (Fig. 3). Attach the template to the window frame (fixed part) and line axis up with the centre line “X”... -
Page 15: Assembly On Transom Window
14.3. Assembly on transom window Aside the drawing of specific application using accessories provided. For different mountings, please contact manufacturer. Before starting, check that there are at least two mechanical compass safety stops or other form of stops connected to the frame, and ensure that the stops can prevent any accidental fall of the window. -
Page 16: Assembly Of Actuator Onto Bay Or Outward Opening Window
14.4. Assembly of actuator onto bay or outward opening window. Aside the drawing of specific application using accessories provided. For different mountings, please contact manufacturer. Pencil in an “X” over the centre line of the window frame (fig. 12). Select the correct form of brackets (fig. 13). Vertical assembly on outward Fold the template along the green dotted line and keep opening... -
Page 17: Configurations
14.5. Configurations Page 17... -
Page 18: Meaning Of The Led Flashing Mode
15. Meaning of the LED flashing mode The LED can be seen on the electronic board after removing the closure plug. In some cases it flashes in different ways depending on the signal it is emitting; the different flashing modes indicate the precise behavior of the actuator during the programming of the machine, radio remote control or rain sensor. -
Page 19: Emergency Manoeuvres, Maintenance And Cleaning
17. Emergency manoeuvres, maintenance and cleaning Should the window have to be opened manually in the event of no electricity, mechanical failure, or for normal maintenance or cleaning of the external surface of the window frame, the following instructions should be followed: 1. -
Page 20: Environmental Protection
19. Environmental protection All materials used in the manufacture of this appliance are recyclable. We recommend that the device itself, and any accessories, packaging, etc. be sent to a centre for ecological recycling as established from laws in force on recycling. The device is mainly made from the following materials: aluminium, zinc, iron, plastic of various type, cuprum. -
Page 21: Conformity
21. Conformity Page 21... - Page 22 MASTERITALY S.r.l. s.p.37 Conversano-Castiglione km. 0,7 - z.i. 70014 Conversano (Bari) Italy – C.P. 81 - ITALY +39 080.4959823 +39 080.4959030 – Fax http://www.masteritaly.com info@masteritaly.com I460B – 31/03/2016 Page 22...
