- Page 1 Owner’s Manual Product: DC-DC Step Down Converter Model: CPC-5 Thank you for purchasing a Canadian Power Conversion product. Please read this manual before operating this converter.
- Page 2 24 VDC TO 12VDC CONVERTER MODEL NO. CPC-5 CPC-5 is a 24 VDC (nominal) to 12 VDC (nominal) dc-dc converter based on a high performance fixed frequency power switching regulator. It is designed to deliver a maximum current of 5 A at a dc voltage of 13.8 VDC.
- Page 3 Sizing of input and output conductors. Conductors have resistance that opposes the current flow and produces a voltage drop and heating. The resistance is directly proportional to the length of the conductor and is inversely proportional to the thickness. Consequently, a longer and thinner conductor will have higher resistance and will produce a higher voltage drop and more heating.
- Page 4 SPECIFICATIONS Input to output isolation Not isolated Input voltage 20 to 32 VDC Output voltage 13.8 VDC ± 0.1 V Output voltage regulation Input current at no load < 5 mA Output current Continuous Current limit * 5.5A *Note: In current limit condition, the output voltage will drop if the current drawn increases beyond the current limit value of 5.5 A Output ripple and noise less than 50 mV...
- Page 5 Contact Information Corporate Address: 10673 – 240A Street, Maple Ridge, B.C. Canada V3W 2B1 t. 604.476.1553 f. 604.123.4567 cpc@canadianpowerconversion.com www.canadianpowerconversion.com...
