GE Spacemaker GUD37ESMMDG Installation Instructions Manual

Installation
Instructions
Questions? Call GE Appliances at 800.GE.CARES (800.432.2737) or visit our Web site at: GEAppliances.com
In Canada, call 1.800.561.3344 or visit www.GEAppliances.ca
BEFORE YOU BEGIN
Read these instructions completely and carefully.
IMPORTANT
– Save these instructions for local electrical
inspector's use.
IMPORTANT
–
Observe all governing codes and
ordinances.
• Install the appliance according to the manufacturer's
instructions and local codes.
• Note to Installer – Be sure to leave these instructions
with the Consumer.
• Note to Consumer – Keep these instructions for future
reference.
• Appliance installation must be performed by a qualified
installer.
• This dryer must be exhausted to the outdoors.
• Before the old appliance is removed from service or
discarded, remove the washer and dryer doors.
• Do not allow children on or in the appliance. Close
supervision of children is necessary when the appliance
is used near children.
• Proper installation is the responsibility of the installer.
• Product failure due to improper installation is not
covered under the Warranty.
• Install the appliance where the temperature is above 50°F
for satisfactory operation of the appliance control system.
• Remove and discard existing plastic or metal foil duct
and replace with UL-listed duct.
• Service information and the wiring diagram are located
at the access panel.
FOR GAS DRYERS ONLY
State of California Proposition 65 Warnings
This product contains one or more chemicals known to the State of California to cause cancer, and birth
WARNING
defects or other reproductive harm.
Gas appliances can cause low-level exposure to some of these substances, including benzene, carbon monoxide,
formaldehyde and soot, caused primarily by the incomplete combustion of natural gas or LP fuels. Exposure to these
substances can be minimized by properly venting the dryer to the outdoors.
PARTS SUPPLIED
1 Cable Tie
2 Washer Hoses
2 Strainer Screens/
Rubber Washers
NOTE: The Rubber
Washers may be in
the water hoses
Unitized Washer/Dryer
WARNING
• Appliance installation must be performed by a qualified
installer.
• Install the appliance according to these instructions
and local codes.
• DO NOT install a clothes dryer with flexible plastic venting
materials. If flexible metal (semi-rigid or foil-type) duct is
installed, it must be UL-listed and installed in accordance
with the instructions found in "Connecting the Dryer
to House Vent" later in this manual. Flexible venting
materials are known to collapse, be easily crushed and
trap lint. These conditions will obstruct dryer airflow and
increase the risk of fire.
• DO NOT install or store this appliance in any location
where it could be exposed to water or weather.
• To reduce the risk of severe injury or death, follow all
installation instructions.
• Save these instructions. (Installers: Be sure to leave
these instructions with the customer.)
FOR GAS DRYERS ONLY
In the Commonwealth of Massachusetts,
the following installation instructions apply:
• Installation must be performed by a qualified or
licensed contractor, plumber, or gasfitter qualified
or licensed by the State.
• If using a ball valve, it shall be a T-handle type.
• A flexible gas connector, when used, must not
exceed 3 feet.
- Fire Hazard
234D2665P001
31-16781-1
09-17 GEA
