- Page 1 SYSTEMS CORP. Version:2.0 Total 16 Pages (Cover Page included)
-
Page 2: Revision History
ervice SP-HF1250K uide Revision History Version Date Changes Official Release 1．0 2．0 07.06.25 Version: 2.0 Page 1/16... -
Page 3: Table Of Contents
ervice SP-HF1250K uide Table of Contents Revision History ……………………………………………………………… ……..1 Table of Contents………………………………………………… ………….2 Getting Started………………………………………………… ……….……………..3 Conventions Used in this Guide………………… ………...…………….….3 Safety Precautions……………………………… ………………...…….…..3 Chapter1. How to Handle Defective Returns………………… ……………………..….4 1.1 Overview…………………………………………………………...…….4 1.2 Problems………………………………………………………...………..5 1.2.1 Power LED (indicator) Unlighted………………...……………..6 1.2.2 Does not work or one channel no sound……………………………..7 1.2.3 Noise……………………………………………………………...….7 Chapter2. -
Page 4: Getting Started
ervice SP-HF1250K uide Getting Started Conventions Used in this Guide Pay Special Attention: Instructions that are important to remember and may prevent mistakes. Attention Caution: Information that, if not followed, may result in damage to the product. Safety Precautions The following precautions should be observed in handling the speaker described in this guide: Place the speakers on a flat level and stable surface. -
Page 5: Chapter1. How To Handle Defective Returns
ervice SP-HF1250K uide Chapter 1. How to Handle Defective Returns 1.1 Overview Receiving Defective Speakers from Customers Verifying problems& Proceeding necessary tests Functioning NG Analyzing possible Malfunction causes Deciding & proceeding Functioning OK the rectification methods Functioning NG Replacing necessary Defective parts Proceeding tests To verify if the speaker is... -
Page 6: Problems
ervice SP-HF1250K uide 1.2 Problems Item Problem descriptions 1.2.1 Power LED (indicator) unlighted 1.2.2 Does not work or one channel no sound 1.2.3 Noise Version: 2.0 Page 5/16... -
Page 7: Power Led (Indicator) Unlighted
ervice SP-HF1250K uide Please follow the numbered sequence marked within parenthesis given in individual Flow chart, in that this is the best-recommended sequence to rectify the problems. Attention 1.2.1 Power LED (indicator) unlighted Problem Power LED （indicator）unlighted Analyze Secondary wire Of CheckD1.2 Check Defective power... -
Page 8: Does Not Work Or One Channel No Sound
ervice SP-HF1250K uide 1.2.2 Does not work or one channel no sound Problem Mic Does not work or One channel no sound Analyze and Defective Broken or Defective IC Identify the Audio cable Short circuit Causes Replace Check solder Solutions Check and replace Audio cable Points on PCB... -
Page 9: Chapter2. Specifications
ervice SP-HF1250K uide Chapter 2. Specifications Satellite NOMINAL LIMIT DESCRIPTION UNIT FRONT OUTPUT POWER @THD 10% ≥20 SENSITIVITY（1KHz）@RATED O/P ±50 POWER SENSITIVITY(1KHz)@1W O/P POWER ±15 MAX INPUT LEVEL@1% ±40 FREQUENCY RESPONSE(1KHz=0dB) ±0.5 ±0.5 ±0.5 S/N @RATED O/P POWER ≥60 CHANNEL UNBALANCE @REF O/P ≤0.5 POWER CHANNEL SEPARATION(ONE... -
Page 10: Chapter3. Block Diagram
ervice SP-HF1250K uide Chapter 3. Block Diagram Version: 2.0 Page 9/16... -
Page 11: Chapter4. Exploded View
ervice SP-HF1250K uide Chapter 4. Exploded View Subwoofer Version: 2.0 Page 10/16... - Page 12 ervice SP-HF1250K uide Chapter 4. Exploded View SATELLITE Version: 2.0 Page 11/16...
-
Page 13: Chapter5. Part List
ervice SP-HF1250K uide Chapter 5. Part List Subwoofer Description Ref. No. RS Part No. Part No. Knob Silver Color 0107HIPS81002G09 Key press, Silver Color 0107HIPS81001G08 Panel , Silver Color, Black Silk-screen 0102HIPS84056G02 Fram, Black HIPS 0101HIPS80090G01 Badge, Black Color AL 0406030401050G01 Speaker, 5.25"... - Page 14 ervice SP-HF1250K uide Chapter 5. Part List Satellite Description Ref. No. RS Part No. Part No. Badge, Black Color AL 0406030401050G01 Fram, Black HIPS 0101HIPS00104G01 Speaker, 5.25" 4Ω 20W 084020045A112G02 Speaker, 1" 8Ω 15W 0820150801312G01 Rubber Foot, Black 4311020050010G01 Wood-box, Silver Color, 12T MDF 9411040011950G02 RCA , Monotrematous Yellow 2021184084101G01...
-
Page 15: Chapter6. Important Notes
ervice SP-HF1250K uide Chapter 6. Important Notes 6.1 Packing requirement for sending the PCB assembly by post PCB assembly is a kind of sophisticated electronic circuit board. Well packing Will be required when sending them by post. *Some sophisticated IC components are mounted on the PCB assembly, hence it is necessary to pack each PCB assembly with a separate static protecting bag, in order to avoid static electricity. -
Page 16: Chapter7. Circuit Schematic
ervice SP-HF1250K uide Chapter 7. Circuit schematic Version: 2.0 Page 15/16... - Page 17 ervice SP-HF1250K uide Chapter 7. Circuit schematic Version: 2.0 Page 16/16...
