- Page 1 PCI-DIO32 Interface Adapter Board User’s Guide Manual PN: 931-0007-00-A July 2000...
- Page 2 © 2000 ICS Advent, a California Corporation. All rights reserved. The information in this document is provided for reference only. ICS Advent does not assume any liability arising out of the application or use of the information or products described herein. This document may contain or reference information and products protected by copyrights or patents and does not convey any license under the patent rights of ICS Advent, nor the rights of others.
- Page 3 Foreword About This Manual This product manual describes the PCI-DIO32 interface adapter board and how to install and program it. Note: Additional technical information and BIOS updates are available from the ICS Advent Web site, www.icsadvent.com, along with advanced troubleshooting information in FAQs and release notes.
- Page 4 This page intentionally left blank. PCI-DIO32 User’s Guide...
- Page 5 Disclaimer: We have tried to identify all situations that may pose a warning or caution condition in this manual. However, ICS Advent does not claim to have covered all situations that might require the use of a Caution or Warning.
- Page 6 This page intentionally left blank. PCI-DIO32 User’s Guide...
- Page 7 Safety Instructions Before handling the PCI-DIO32, read the following instructions and safety guidelines to prevent damage to the product and to ensure your own personal safety. Refer to the “Advisories” section for advisory conventions used in this manual, including the distinction between Warnings, Cautions, and Notes.
- Page 8 Static electricity can harm system boards. Perform service at an ESD workstation and follow proper ESD procedure to reduce the risk of damage to components. ICS Advent strongly encourages you to follow proper ESD procedure, which can include wrist straps and smocks, when servicing equipment.
- Page 9 Although ICS Advent offers accessories, the customer must ensure that these products are installed with proper shielding to maintain CE compliance. ICS Advent does not offer engineering services for designing cabling systems. In addition, ICS Advent will not retest or recertify systems or components that have been reconfigured by customers.
- Page 10 This page intentionally left blank. PCI-DIO32 User’s Guide...
- Page 11 ICS Advent or its authorized agent; or if the failure is caused by accident, acts of God, or other causes beyond the control of ICS Advent or the manufacturer. Neglect, misuse, and abuse shall include any installation, operation, or maintenance of the product other than in accordance with the user’s manual.
- Page 12 To reduce risk of damage, returns of product must be in an ICS Advent shipping container. If the original container has been lost or damaged, new shipping containers may be obtained from ICS Advent Customer Service at a nominal cost.
- Page 13 Limitation of Liability In no event shall ICS Advent be liable for any defect in hardware, software, loss, or inadequacy of data of any kind, or for any direct, indirect, incidental, or consequential damages in connection with or arising out of the performance or use of any product furnished hereunder.
- Page 14 This page intentionally left blank. PCI-DIO32 User’s Guide...
-
Page 15: Table Of Contents
Contents Chapter 1 Introduction Overview ..........1-1 What’s Included . -
Page 16: Overview
The PCI-DIO32 board is PCI 2.1 bus compliant. Addressing, data, and control signals are TTL compatible. What’s Included The PCI-DIO32 is shipped with the following items. If any of these items are missing or damaged, contact ICS Advent. PCI-DIO32 interface adapter board... -
Page 17: Installation
For users of DOS, Windows 3.1, etc., run disk 3 and the Read Me file. System Installation The PCI-DIO32 board can be installed in any PCI expansion slot as follows: 1) Turn off system power. Disconnect the power cord from the electrical outlet. -
Page 18: Technical Description
Chapter 3 Technical Description The PCI-DIO32 provides four parallel input/output (I/O) ports, organized as ports A, B, C, and D. Port A and B are input ports interfaced to optically isolated inputs. Ports C and D are reed relay output ports. Assuming an I/O... -
Page 19: Input Ports
Isolator diode drop = 1.1V Maximum resistor power = 0.25W Turn-on voltage = diode drop + (turn-on current) x ( resistance) Or : 1.1 + (0.003) x R Maximum voltage = square root of (0.25 x (resistor value)) PCI-DIO32 User’s Guide... -
Page 20: Table 3-1. Sensor Input Ports Pin Assignments
The following table shows four common input resistors and the ranges associated with each: Input Value Max Input Resistor Turn-On Range Current (ohms) (volts) (volts) (mA) 1.76 2.2K The maximum input voltage can be increased by increasing the input resistor accordingly. -
Page 21: Output Ports (Reed Relay)
Contact Resistance, Initial = 0.15 ohms Rated Life: Low Load = 200 million closures Maximum Load = 100 million closures Contact Speed: Operate = 0.5 ms Release = 0.5 ms Bounce = 0.5 ms Maximum Operating Speed = 600Hz PCI-DIO32 User’s Guide... -
Page 22: Software
+ 5V + 12V Software The PCI-DIO32 board ships with ICS Advent’s SeaI/O suite of Windows 95/98/ 2000/NT drivers on floppy disks 1 and 2. SeaI/O provides the user with a consistent and straightforward API, allowing the developer to concentrate on the details of the application instead of low level driver development. -
Page 23: Programming Examples
NOT AL ; Invert input – see note below OR AL,00001000B ;OR in bit 3 OUT DX, AL ;Set bit 3 Note: Reading back the ports (C and D) results in the binary complement of the output. PCI-DIO32 User’s Guide... -
Page 24: Table 3-3. Register Description
Table 3-3. Register Description Address Mode Base+0 PAD7 PAD6 PAD5 PAD4 PAD3 PAD2 PAD1 PAD0 Base+1 PBD7 PBD6 PBD5 PBD4 PBD3 PBD2 PBD1 PBD0 Base+2 PCD7 PCD6 PCD5 PCD4 PCD3 PCD2 PCD1 PCD0 Base+3 PDD7 PDD6 PDD5 PDD4 PDD3 PDD2 PDD1 PDD0 Base+4... -
Page 25: Specifications
Chapter 4 Specifications Power Requirements +5VDC +12VDC Size Length: 6.00 in (152mm) Height: 4.20 in (107mm) with goldfingers, 3.825 in (97 mm) excluding goldfingers Temperature Range Operating: 0 °C to 50 °C (32 °F to 122 °F) Storage: -20 °C to 70 °C (-4 °F to 158 °F) Humidity 10 to 90% RHNC MTBF... -
Page 26: Appendix A Troubleshooting
3) Ensure that there is no conflict with currently installed adapters. No two adapters can occupy the same I/O address and may not be allowed to share IRQs. 4) Make sure the PCI-DIO32 adapter is securely installed in a motherboard slot. Troubleshooting... -
Page 27: Appendix B Board Layout Drawing
Appendix B Board Layout Drawing 4.200" 6.00" 3.825" Board Layout Drawing... - Page 28 The technical documentation required to demonstrate this product meets the requirements of the EMC Directive and the Low Voltage Directive has been compiled by ICS Advent and is available for inspection by the relevant enforcement authorities. The CE mark was first applied in 2000.
