FEB100-NT
Free Exit Box - No Touch Sensor
Product Manual
• Installation Instructions
• Wiring Instructions
Revision A
Advertisement
Summary of Contents for Access One FEB100-NT
- Page 1 FEB100-NT Free Exit Box - No Touch Sensor Product Manual • Installation Instructions • Wiring Instructions Read and follow all UL and Safety Standards before installing. Refer to the manual and qualified personnel for assistance. DO NOT install this device unless all entrapment and pinch points are eliminated.
- Page 2 VERVIEW ONNECTING OWER The FEB100-NT Free Exit Box uses a “No Touch” The FEB100-NT can only be powered by 12-24 VDC. Infrared sensor to sense a user and open the door or Use the 12VDC transformer supplied with the unit. To gate.
- Page 3 ONNECTING LECTRIC TRIKE NFRARED ENSOR VERVIEW To connect the FEB100-NT to an electric strike: 1. Connect two wires from the electric strike to the Wire Terminal NO and NOC terminals: • One leg of strike power to NO terminal. Time Delay...
- Page 4 MPORTANT NSTRUCTIONS Automatic gate systems provide user convenience and limit vehicular traffic. Because these systems can produce high levels of force, it is important that you are aware of the potential hazards associated with the system. Potential hazards may include pinch points, entrapment positions, lack of proper pedestrian access, blind spots for traffic visibility.
