Exibel CX1040 Installation

Car Speakers
Art. no 38-3309 Model CX1040
38-3310 CX1055
38-3311 CX1065
38-3312 CX1069
Please read the entire instruction
manual before using the product
and save it for future reference.
We reserve the right for any errors
in text or images and any neces-
sary changes made to technical
data. If you have any questions re-
garding technical problems please
contact Customer Services.
Safety
Start by setting the volume to a
low level and increasing it slowly
to the desired level. Remeber
that prolonged exposure to high
volume can damage your hearing.
Specifications
Art.no 38-3309 Model CX1040
2 x 3 m cables included
Max. power: 60 W (30 W RMS)
Type: 4" (10 cm), 2-way
Impedance: 4 ohms
Frequency response: 80 – 22,000 Hz
Size: 100 x 100 mm
Mounting depth: 52 mm
Sensitivity: 84 dB/W/m
Ø 28 mm Mylar tweeter
GREAT BRITAIN For consumer contact, please visit www.clasohlson.co.uk and click on customer service.
Art.no 38-3310 Model CX1055
2 x 3 m cables included
Max. power: 80 W (40 W RMS)
Type: 5.25" (13 cm), 2-way
Impedance: 4 ohms
Frequency response: 70 – 22,000 Hz
Size: 130 x 130 mm
Mounting depth: 51 mm
Sensitivity: 85 dB/W/m
Ø 28 mm Mylar tweeter
Art.no 38-3311 Model CX1065
2 x 3 m cables included
Max. power: 100 W (50 W RMS)
Type: 6.5" (17 cm), 2-way
Impedance: 4 ohms
Frequency response: 65 – 22,000 Hz
Size: 165 x 165 mm
Mounting depth: 60 mm
Sensitivity: 86 dB/W/m
Ø 28 mm Mylar tweeter
Art.no 38-3312 Model CX1069
2 x 3 m cables included
Max. power: 160 W (80 W RMS)
Typ 6 x 9" (16 x 24 cm), 3-way
Impedance: 4 ohms
Frequency response: 55 – 22,000 Hz
Size: 236 x 165 mm
Mounting depth: 83 mm
Sensitivity: 88 dB/W/m
Ø 28 mm Mylar tweeter
Ø 66 mm Mylar midrange
ENGLISH
Installation
Refer to your car stereo owner's manual.
