TET SICA14I2P Instructions For Use

Small Interface Cable Adapter, SICA14I2P

1. Product description

The SICA14I2P is designed to save space on the target board when using JTAG
equipment to test, debug or evaluate a system. The target board connector has a 5 x 7mm
footprint, which is 1/6
This cable adapter converts 2.54mm pitch connector at an emulator side into 0.5mm pitch
at a target board. Therefore, this cable can be placed closed to CPU. The target board
connector surface mounted on PCB without needing any "through holes". Now, the other
side of PCB is available for mounting more components.

2. Specifications

2.1 Operating and Storage environments:
Title
1. Temperature
2. Relative humidity
3. Chemical gas
2.2 Mechanical and Electrical specifications:
Title
１ Outer dimensions
２
Connector at an emulator side
３
Header at target side
４
Socket at target side
５
Cable material
６ DC resistance
７
Life of connectors
８
Current rating
Instruction for use
the size compared with traditional connector with 2.54mm pitch.
th
Operating environment
10 to 35℃
35 to 80% (No condensation on any devices)
No corrosive gas should exist in the environment.
34 x 52 x 17mm
HIF3FC-14PA-2.54DSA(71)
Custom made connector, 20pins, 0.5 mm pitch
Custom made connector, 20pins, 0.5mm pitch
FPC, polyamides, double layers
300ｍΩ Max
500 times Min
0.5A/line Max
TET
TOKYO ELETECH CORPORATION TOKYO ELETECH CORPORATION TOKYO ELETECH CORPORATION TOKYO ELETECH CORPORATION
Specifications
1
Storage environment
-10 to 50℃
