Vandlion V30 User Manual

Digital voice recorder
Hide thumbs

Advertisement

Quick Links

Download this manual
Vandlion digital voice recorder
V30
User Manual
0

Advertisement

loading
Need help?

Need help?

Do you have a question about the V30 and is the answer not in the manual?

Questions and answers

Related Manuals for Vandlion V30

Summary of Contents for Vandlion V30

  • Page 1 Vandlion digital voice recorder User Manual...
  • Page 2 Vandlion digital voice recorder Thank you for your purchase! We are very happy that you have chosen our portable voice recorder. We are 100% committed to your customer satisfaction. If you experience any issue with your device at any time, please contact us at support@vandlion.net...
  • Page 3 Vandlion digital voice recorder interference sources when the Recorder works. Backup Please keep backup documents in case that external errors or operation failure may lead the machine to lose itself documents. Transmission Do not disconnect the Recorder from computer during data transmission process to prevent data loss.
  • Page 4 Vandlion digital voice recorder 1.Record/Save button 2.Volume up button 3.Volume down button 4.Screen 5.Rewind/Previous file button 6.Stop/Escape button 7.Fast forward/Next file button 8.Pause/Play button 9.Power switch 10.USB port 11.Headphone jack 12.Microphone 13.Line in jack...
  • Page 5 Vandlion digital voice recorder 3.Charge Connect the recorder to your computer via the USB cable(Supplied). Inset the micro USB end to the recorder, and the USB end to the USB port of a running computer. When the recorder is charging, the screen will show electric quantity atop right.
  • Page 6 Vandlion digital voice recorder 5.Turn the Power Off Slid down the “Power switch”, the “BYE” animation appears, and the recorder is turned off.  Hint When the recorder is in the stop mode, and you leave the recorder without attempting. an operation for approximately 5 minute, the auto power off function will take effect.
  • Page 7 Vandlion digital voice recorder start recording in the stop mode.  Place the recorder so that the built-in microphones face the direction of the source to be recorded. The new file will be automatically recorded as the last file in the current folder.
  • Page 8 Vandlion digital voice recorder button to start playing the file.  Press “VOL+”or “VOL-”button to adjust the volume.  Press“ ”button to stop playing. 8. “A-B”Repeat Play  Playing state,Press “ ” to select “A”,the screen will flash “A”, press this button again to select “B”,and then start “A-B”...
  • Page 9 Vandlion digital voice recorder  In standby mode, select the file you want to delete,Long press stop key to enter.  Press “ ”or“ button select ” “No”/“Yes”/“Delete all”, Press confirmation. “ ”  “No”：Cancel delete.  “Yes” ：Delete single file.

  • Page 10: Recording Settings

    Vandlion digital voice recorder  Press “ ” to enter the MP3 player interface.  Play music with the same voice. Recording Settings In standby mode, press the “ ” key to enter.  The following settings press the button “...
  • Page 11 Vandlion digital voice recorder tentative recording, please use this feature. 2) Catalog choice a. A b. B c. C d. D When selecting the A folder, the voice file is stored in the A folder. 3) Record type a.PCM b.SP Recording c.LP Recording...
  • Page 12 Vandlion digital voice recorder c.Train Station d.Remote According to the different settings, recording effect is not the same. 6) Vox Set a.Clsoe b.Open 7) VOR Level When the sound recording is turned on, it can adjust the size of the input.
  • Page 13 Vandlion digital voice recorder In standby mode, press the “ ” key to enter.  The following settings press the button “ ” to confirm, press the “ ” key to exit. Press “ to select the Play Mode, press the ...
  • Page 14 Vandlion digital voice recorder 1) Press “ to select the ” desired position. 2) Press“+/-”adjust number. 15. Language  The following settings press the button “ ” to confirm, press the “ ” key to exit. 1) Simple Chinese/Trad Chinese/English....
  • Page 15 Vandlion digital voice recorder “Record(On)” quasi current system time.  Into the regular “Record(On)”, adjust the start time, press the “ ”or“ button to select the ” location, “+/-” adjust the number. 2) Password Switch a.Password Off b.Password On  When you “Password On”, set a password.
  • Page 16 Vandlion digital voice recorder d.10 Minute e. 30Minute f. 60Minute Press the “ ”or“ button to select the timing ” of the shutdown time. 18. Restore factory Settings  All settings are restored to the initial state. 19.Copy Files with PC Connect the Recorder to the PC via the USB cable.
  • Page 17 Vandlion digital voice recorder Copy files or folders to your computer. Copy the PC side of the music to voice recorder.

  • Page 18: General Specification

    Vandlion digital voice recorder 20. General Specification Display screen 128*64 LCD screen Disk Capacity 8GB/16GB Product size 4.25 x1.41x0.4 Inches Weight 2.57 OZ Recording Format Recording Mode Microphone/Line-in REC type Recording bit 8GB Storage time ratetime(8GB 384kbps 45hours SP Recording...
  • Page 19 Vandlion digital voice recorder CONTACT US We really appreciate you choosing Vandlion® as your trusted brand of digital voice recorders and we sincerely hope you enjoy your purchase. We love making our customers happy by providing true value with our products.
