showArt 8MG3BU User Manual

Dmx 512 merger

DMX 512 MERGER SERIES

8MG3BU DMX MERGER

User Manual

VERSION: 1.0 2020.03.05

This product manual contains important information about the safe installation and

use of this product. Please read and follow these instructions carefully and keep this

manual in a safe place for future reference.

Table of Contents

Need help?

Do you have a question about the 8MG3BU and is the answer not in the manual?

Page 1 DMX 512 MERGER SERIES 8MG3BU DMX MERGER User Manual VERSION: 1.0 2020.03.05 This product manual contains important information about the safe installation and use of this product. Please read and follow these instructions carefully and keep this manual in a safe place for future reference.
Page 2 DMX 512 MERGER SERIES 8MG3BU DMX MERGER User Manual This DMX Merger can choose HTP Mode or BACKUP Mode to connect main console and 2 backup consoles. All the inputs and outputs are completely isolated by the latest electrical isolation technology. Each DMX output has super driving ability.
Page 3 DMX 512 MERGER SERIES Control Panel Instruction ④ ⑥ ① ② ③ ⑤ ⑦ ⑧ ⑨ ① LED INDICATORS OF DMX OUTPUTS: used to show the working status of DMX OUTPUT 1-8. It stays on when there is DMX signal input, and off when there is no DMX signal input.
Page 4 DMX 512 MERGER SERIES 5.The pinout appears below: Pin 1:GND(SCREEN) Pin 2:Signal(-) Pin 3:Signal(+) 3Pins canon(plug) 3Pins canon(plug) Pin 1: GND(SCREEN) Pin 1: GND(SCREEN) Pin 2: Signal(-) Pin 2: Signal(-) Pin 3: Signal(+) Pin 3: Signal(+) 6. Connection diagram: Input C Input B Input A Output1...
