The illustration shows SC-HT720 for the U.S.A. and
Canada.
Before connecting, operating or adjusting this product,
please read these instructions completely.
Please keep this manual for future reference.
Region number
The player plays DVD-Video marked with labels containing the
region number or "ALL".
Region
U.S.A., Canada and units with PX printed on
the outer packaging
Latin America
[U.S.A.[and[Canada[
Example:
[U.S.A.[and[Canada[
As an ENERGY STAR Partner,
Panasonic has determined that
this product meets the ENERGY STAR
guidelines for energy efficiency.
§
For Canada only: The word "Participant" is used in place of the
word "Partner".
P
PC PX
GCP
Number
1
4
1
1
2
ALL
4
®
®
Operating Instructions
DVD Home Theater Sound System
Model No.

Table of contents

Getting started
Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
STEP 1
Locating . . . . . . . . . . . . . . . . . . . . . . . 4
STEP 2
Video connections . . . . . . . . . . . . . . . 7
The remote control. . . . . . . . . . . . . . . 8
QUICK SETUP. . . . . . . . . . . . . . . . . . . 9
Control reference guide . . . . . . . . . . . . . . . . . . . . 9
Discs that can be played. . . . . . . . . . . . . . . . . . . 10
Main unit and disc caution . . . . . . . . . . . . . . . . . 11
Disc operations
Basic play . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Convenient functions . . . . . . . . . . . . . . . . . . . . . 14
Position memory/Zoom/Audio/Subtitle/Quick replay/
Page skip/Repeat play/All group, random and program
Using navigation menus . . . . . . . . . . . . . . . . . . . 16
Playing data discs/Playing HighMAT
the programs/Playing a play list
Using on-screen menus . . . . . . . . . . . . . . . . . . . 18
Changing the player settings . . . . . . . . . . . . . . . 20
Other operations
The radio. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Automatic presetting/Selecting the preset channels/
Sound field and sound quality . . . . . . . . . . . . 24
Other functions . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Sleep timer/Muting/Using headphones
Operating other equipment. . . . . . . . . . . . . . . . . 28
Reference
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Troubleshooting guide . . . . . . . . . . . . . . . . . . . . 32
SC-HT720
SC-HT692
TM
discs/Playing
-
26
RQT7433-2P
