- Page 1 User Manual Countertop Convection Ovens 10/2021 Models: 177CO14, 177CO16, 177CO28M Please read and save these instructions for future reference. Indoor use only.
-
Page 2: Table Of Contents
User Manual Index Important Safeguards ������������������������������������������������������������������������� 3 Identification of Key Parts ������������������������������������������������������������������� 4 Identification of Accessories ���������������������������������������������������������������� 4 Usage Guidelines ��������������������������������������������������������������������������������� 5 Before Using Your Oven ����������������������������������������������������������������������� 6 Using Your Oven ���������������������������������������������������������������������������������� 6 Typical Operation Sequence ���������������������������������������������������������������� 6 Temperature Control Knob ������������������������������������������������������������������ 7 Power and Heating Indicator Light �������������������������������������������������������... -
Page 3: Important Safeguards
User Manual Important Safeguards When using electrical appliances, basic safety precautions should always be followed, including the following: Read all instructions carefully and completely. For commercial use only. Do not touch hot surfaces. Protect against electrical shock by keeping all cords, plugs, and other electrical components away from water or other liquids. -
Page 4: Identification Of Key Parts
Timer Knob Temperature Light Power Light Indicator Temperature Control Knob Identification of Accessories Roasting Racks - 177COTRAY1 for 177CO14 - 177COTRAY2 for 177CO16, 177CO28M Recommended Bun Pans - Quarter Size (407BUNQRTR) for 177CO14 - Half Size (407BUNHALF) for 177CO16, 177CO28M... -
Page 5: Usage Guidelines
User Manual Usage Guidelines 120V Units Food Items Temperature (°F) Time (Minutes) Quantity/HR Cookies Brownies 2 Trays Biscuits Dinner Rolls Bacon (sliced) 3 Trays Cheese Medium Pizza (frozen) Baked Chicken Breast 8oz* *Times and temperatures are used as a guide only. • Good for limited electrical options and/or outlets • Great for supplemental baking, low volume small batches of baked goods, and sandwich warming at coffee chops, kiosks, churches, schools, and more... -
Page 6: Before Using Your Oven
User Manual Before Using Your Oven Before cooking anything in your oven for the first time, please follow these simple instructions: Using a small amount of detergent, wash the handle and roasting racks with soapy water. (NOTE: Do not use a spray or abrasive polishing agent.) Gently wipe down interior walls with a damp cloth. While washing this unit, do not to touch the electric heating element. Do not soak the inside of the oven with water. After washing and thoroughly drying the surfaces noted above, place the roasting racks back inside the oven. For first-time use of the oven, close the door and turn the bake control to max temperature. Set the timer for 30 minutes. During this burn-in you may notice a slight odor, this is normal. This process helps remove any fumes or odors which may be present. Using Your Oven To start your oven, you need to turn on the temperature dial to set your desired cooking temperature, and turn on the timer dial to set the cooking time. -
Page 7: Temperature Control Knob
User Manual Temperature Control Knob The temperature range of this unit is 0-500°F on 120V models and 0-550°F on 208/240V models. This thermostatic switch controls the temperature inside the oven and helps to maintain the proper temperature during various heating, roasting, and baking applications. Power &... -
Page 8: Specifications
User Manual Specifications Model # Power Supply Dimensions Unit Weight Size Capacity Rack # Plug 177CO14 120V, 60Hz, 1440W 18¾"W x 18"D x 15"H 30 lbs. (35 lbs. shipping) Quarter 0.8 cu. ft. 3 Racks NEMA 5-15 177CO16 120V, 60Hz, 1600W 23"W x 22½"D x 16½"H... -
Page 9: Parts List
User Manual Parts List PART CATEGORY ITEM NUMBER COMPATIBLE MODELS COMPATIBLE DISCONTINUED MODELS INTERIOR RACK BOLT 177COBOLT ALL MODELS CO12 QUARTER 120V DOOR 177PCO14DOOR CO14 QUARTER 120V DOOR 177PCO16DOOR CO16 HALF 120V CO12 QUARTER 120V DOOR 177PCO28DOOR CO28 HALF 208V/240V HEATING ELEMENT 177COELEMT12 CO16 HALF 120V... -
Page 10: Wiring Diagram
User Manual Wiring Diagram www.AvantcoEquipment.com... -
Page 11: Equipment Limted Warranty
Avantco reserves the right to approve or deny the repair or replacement of any part or repair request. The warranty is not transferable. Avantco Equipment installed in/on a food truck or trailer will be limited to a period of 30 days from the original date of purchase.
