Summary of Contents for Cameron Communications VA400
- Page 1 Operation Manual VA400 4K UHD Video Bar Version 1.0...
- Page 2 VA400 4K UHD Video Bar Overview The VA400 is a premium USB 4K video bar for small and medi- um sized meeting rooms. Providing face detection, audio positioning, and voice tracking, with simple USB connectivity. The VA400 Video Bar delivers an efficient video conferencing meeting experience, with exceptional audio and video quality to every participant.
- Page 3 Attention This manual introduces the functions, installation and operation of the VA400 video conferencing Bar. VA400 Please read this manual carefully before installation and use. 1. How to use To prevent damage to this product or any product connected to it, this product can only be used with- in the specified range.
- Page 4 1. Quick Installation Instructions Dimensions Product Use 1) Installation: Fix the device to the wall, over the display screen or directly put it on the desktop.
- Page 5 2. Product Overview Product Features With a compact design, The VA400 is the ideal solution for small and medium sized meeting rooms, with USB plug-and-play, providing easy connection to any PC or laptop. Integration：A one-piece design integrating camera, microphone, and speaker;...
- Page 6 3 Technical Parameters...
- Page 7 4 Remote Instructions...
- Page 8 5 Menu Settings 5.1 Press [MENU] button in MJPG, YUY2, NV12 or H264 compression encoding formats. 5.2 Language 5.3 Setting Move the pointer to (Settings) in the main menu, press [HOME] to get into the exposure page as shown below. Image style: Default/Standard/Clear/Bright/Soft Auto Framing: on/off Voice Locating: on/off...
- Page 9 5.4 Exposure In the main menu, move the pointer to (Exposure), and press [HOME] to enter the exposure page, as shown below. Mode: automatic, manual, shutter priority, brightness priority Exposure Compensation: on/off (only valid in auto mode) Compensation Level: -7～7 (only valid when "Exposure Compensation" is on in automatic mode) Backlight: On/Off (only valid in auto mode) Anti-flicker: off, 50Hz, 60Hz (only valid in auto, aperture priority, brightness priority mode) Gain Limit: 0～15 (only valid in auto, aperture priority, brightness priority mode)
- Page 10 5.5 Colour Move the pointer to (Colour) in the main menu, and press [HOME] to get into the colour page, as shown below WB Mode: automatic, manual, white balance, a key, specified colour temperature Saturation: 60%, 70%, 80%, 90%, 100%, 110%, 120%, 130%, 140%, 150%, 160%, 170%, 180%, 190%, 200 % AWB Sensitivity: high, medium, low (valid only in automatic mode) Chroma (Hue): 0～8...
- Page 11 5.6 Image Move the pointer to (Image) in the main menu, and press [HOME] to get into the image page, as shown below. Brightness：Settable：0～14 Contrast：0～14 Sharpness：0～15 Flip-H：On/Off Flip-V：On/Off B&W Mode：Colour, Black and White Gamma Curve：Default.0.34.0.39.0.47.0.50 Low-light Mode：On/Off...
- Page 12 5.7 Noise Reduction Move the pointer to (Noise Reduction) in the main menu, press [HOME] to get into the noise reduction page, as shown below. 2D Noise Reduction: Auto, Off, 1-7 3D Noise Reduction：Off, 1-8 6 Camera Version Move the pointer to (version) in the main menu. 7 Restore Default Move the pointer to (Reset) in the main menu, press [HOME] to get into the reset page, as shown below.
- Page 13 8 Maintenance and Troubleshooting 8.1 Product Maintenance ) If camera is not used for long time, please turn off power adapter switch and AC plug. 2) Use soft cloth or tissue to clean the camera cover. 3) Use soft cloth to clean the lens; Use neuter cleanser if bad smeared. No use strong or corrosive cleanser or corrosive cleanser avoiding scuffing.
