- Page 1 OF BIOLOGICAL MICROSCOPE OPERATION MANUAL READ THIS MANUAL BEFORE USING THE MICROSCOPE...
- Page 2 OF BIOLOGICAL MICROSCOPE OPERATION MANUAL Ⅰ.Application xsp-200 of biological microscope is based on the XSP-2CA, and combine advanced modular design, developed a new products. The products have high degree of standardization, beautiful appearance, and also have the feature about rational structure, easy to use, clarity of visual field and quality stability.
- Page 3 : 160mm Mechanical tube length 5. ABBE condenser, NA=1.25 6. Filter diameter: 32mm 7. Coarse/fine focal range:20mm 8. Stage size:X-Y:115*125mm Longitudinal movement range: 70mm Horizontal movement range: 30mm 9. lamp:LED lamp 10. power:AC input 110v, Amerindian standard plug. Ⅲ. Structure This series of microscopes are composed of the following main components.
- Page 4 Ⅳ. Operation Instruction 1. Unpacking and installation： host packed in plastic bags, Objective are on Microscope packaging is foam and carton; the transparent plastic box, Eyepiece with a plastic bag, it should be carefully when install. 2. Adjustment of the microscope: 1）Insert the eyepiece into the eyepiece tube, and screw objectives into the nos epiece in sequence of different magnification from low to high.
- Page 5 lace them into a dry box, and put the dust cover onto the microscope. Full set of the instrument Mainframe of bio-microscope 1 set Eyepiece: WF10X WF16X 1 pair each Tube 1 pc Achromatic Objective:4X,10X,40X,100X(oil) 1pc of each Filter: blue 1 pc Cedar wood oil 0.3ml/bottle...
