Summary of Contents for EarthLinked ACM-024C
-
Page 1: Table Of Contents
® EarthLinked Auxiliary Cooling Module Models ACM-024C thru ACM-072C For R-410A Installation Manual CONTENTS PAGE Pre-Installation Installation • Placement • Refrigerant Connections • Electrical ACM-410D-IM (11/12) Copyright 2012 Earthlinked Technologies, Inc. - Page 2 ® manual will void the limited warranty coverage for the EarthLinked system. Earthlinked Technologies shall not be liable for any defect, unsatisfactory performance, damage or loss, whether direct or consequential, relative to the design, manufacture, construction, application ® or installation of other components in the EarthLinked system.
-
Page 3: Pre-Installation
® ® This EarthLinked Auxiliary Cooling Module is approved for use with EarthLinked space heating and cooling systems utilizing Series SC, SD, and SCW compressor units operating with R-410A refrigerant. This Auxiliary Cooling Module is sold as a system component and must be properly matched with the compressor unit to provide the anticipated performance and safe operation of the ®... - Page 4 Max. Voltage Full Model Power Circuit Fuse Rated Nominal Width, Depth, Height, Range Load Amps Amps* inches inches inches Amps ACM-024C 230-1-60 207-253 1/10 1010 24.25 24.25 24.50 ACM-036C 230-1-60 207-253 1/10 1010 24.24 24.25 24.50 ACM-048C 230-1-60 207-253 1/10 1010 24.25...
-
Page 5: Installation
The Auxiliary Cooling Module is located outdoors and will be connected to the refrigerant line set outside the building. ® Figure 1. Auxiliary Cooling Module Placement in EarthLinked System Location Requirements for the Auxiliary Cooling Module: 1. Within 40 Feet of the earth loop line set. Minimize refrigerant line lengths. - Page 6 6. On a solid, level mounting slab. The mounting slab should extend a minimum of 2 inches beyond the sides of the Auxiliary Cooling Module. To reduce the possibility of noise transmission, the mounting slab should NOT be in contact with or be an integral part of the building foundation.
-
Page 7: Refrigerant Connections
Installation – Refrigerant Connections Figure 2. Auxiliary Cooling Module Refrigerant Connections The Auxiliary Cooling Module has two refrigerant connections on the service side of the unit as shown in Figure 2. The connections are the same size as each other. These sizes are listed in Figure 2 for each Auxiliary Cooling Module model. - Page 8 Figure 3. Auxiliary Cooling Module Refrigerant Piping A top view of typical Auxiliary Cooling Module and line set vapor line connections are illustrated in Figure 4. Figure 4. Top View of Line Set Connections ACM-410D-IM (11/12) Page 8...
- Page 9 All refrigerant piping joints and connections in the EarthLinked® heating and cooling system, including the Auxiliary Cooling Module, line sets and earth loop system are to be brazed with 15% silver content brazing alloy, utilizing the NITROGEN BRAZING PROCESS. IMPORTANT!
-
Page 10: Electrical
Installation - Electrical 1. After turning “OFF” power to all EarthLinked® and field supplied system components at the appropriate breakers remove the front and top panels of the compressor unit cabinet. 2. Reference Figure 5 for compressor unit electrical box. Remove available hole covers from the front of the electrical box. - Page 11 4. Install two-pole terminal strip inside electrical box and fasten into existing hole with screw provided. 5. Attach pink wire with piggyback connector onto “T2” (for single phase) or “T3” (for three phase) on the compressor contractor and the other connector to the center terminal of the bottom fuse holder.
- Page 12 Figure 6. Auxiliary Cooling Module Field Wiring 12. Check all wiring and electrical connections to ensure proper routing and good contact before restoring electric power, evacuating and recharging system in accordance ® with the appropriate EarthLinked system Installation Manual. ACM-410D-IM (11/12) Page 12...
