User

Manual

ZCARE: Warning Wristband

CLEODE - Siège : 3, rue Thomas Edison - 22300 LANNION– France

T. +33 (0)2 96 48 68 18 - F. +33 (0)2 96 48 19 11

SAS au capital de 167 200 € - 450 570 767 RCS Saint Brieuc

References: ZCARE 2.0

Reference: UM_ZCARE_20180605_001_01_00

Revision: 1.0

Date: 08/31/2018

State: Beta

Table of Contents

Need help?

Do you have a question about the ZCARE and is the answer not in the manual?

Questions and answers

Summary of Contents for Cleode ZCARE

Page 1 State: Beta Reference: UM_ZCARE_20180605_001_01_00 CLEODE - Siège : 3, rue Thomas Edison - 22300 LANNION– France T. +33 (0)2 96 48 68 18 - F. +33 (0)2 96 48 19 11 SAS au capital de 167 200 € - 450 570 767 RCS Saint Brieuc...
Page 2 équipe médicalisée qui par ailleurs effectuera elle-même les vérifications sur l’état de santé du porteur du wristband ZCare. L’utilisation du produit ZCare sous-entend de la part de l’utilisateur et de l’équipe de surveillance (si elle existe) une connaissance des termes ci-dessus et un accord sur la non responsabilité...
Page 3 In order to invoke the warranty, the buyer must immediately send written notice to CLEODE of the flaws that it attributes to the device. It must enable CLEODE to have access to the device to observe these defects and repair them. The warranty provided by CLEODE is strictly limited to the equipment provided and shall only have for effect the replacement or repair, at CLEODE’s expense, on its own premises, of all devices or parts that are not...
Page 4 Table of content Version Author(s) Version description Date CLEODE Initial version 05/22/2018 CLEODE Validated document 05/29/2018 CLEODE User Manual: ZCARE : Warning Wristband page...
Page 5: Table Of Contents
PPLICATION V.2.1 ’ ESCRIPTION DE L APPLICATION V.2.2 ESCRIPTION DES LUSTERS V.2.2.1 Cluster Basic V.2.2.2 Cluster Power Configuration V.2.2.3 Cluster Identify V.2.2.4 Cluster Alarms V.2.2.5 Cluster IAS Zone V.2.2.6 Cluster Care Configuration CLEODE User Manual: ZCARE : Warning Wristband page...
Page 6 IGURE ROCEDURE TO SWITCH IN CONFIG MODE 8 : P ’ ..............16 IGURE ROCEDURE D ACQUITTEMENT DES ALARMES SUR LE WRISTBAND 9 : P ........................20 RINCIPE OF VALIDATION OF A HEAVY FALL CLEODE User Manual: ZCARE : Warning Wristband page...
Page 7: Presentation
I. Presentation ZCare is wrist watch ZigBee® to issue radio frequency alerts of type: 1. Manual alert by pressing the call button 2. Fall detection 3. Low battery detection The figure shows the product: Warning light Call button Warning charge I.1 Main features...
Page 8: Technical Caracteristic
ZigBee® secure mode Fréquence 2.4GHz Frequency Puissance de sortie <10dBm Output power Sensibilité -97 dBm Sensibility Antenne Interne Antenna Internal Approbation Conforme à la norme radio ZigBee® Approval Conforms to radio standard for ZigBee® CLEODE User Manual: ZCARE : Warning Wristband page...
Page 9 -40°C to +80°C ambient Storage temperature range MECANIQUE / MECHANICAL Dimension 55x46x17 mm Overall dimension RoHS RoHS 6 FIABILITE / RELIABILITY Durée de vie >5 years @ 25°C Lifetime MTBF >60,000 hours @ 25°C CLEODE User Manual: ZCARE : Warning Wristband page...
Page 10: Quick Start
3) Shift in regular mode (for more details, look at chapter Configuration III.3) 4) Manage the warnings realise (for more details, look at chapter Configuration 0) 5) Refill the wristband (for more details, look at chapter Configuration IV.5) CLEODE User Manual: ZCARE : Warning Wristband page...
Page 11: Implementation
2. Mode Config : the wristband ZCare is under maintenance, included in ZigBee® Network and available. The call and fall functions stay inactive 3. Standard mode: the wristband ZCare is integrated in the ZigBee® Network and available. The call and fall functions are activated according to the layout done during the maintenance.
Page 12: Iii.2 Pairing In A Zigbee® Network
2) To approach the magnet on the LED NWK side: 3) ZCare flashes 2 times Red to report the research phase of ZigBee® network: 4) Push 10 seconds minimum on the call button of the Zcare to delete the settings network and obtain a new setting of pairing:...
Page 13: Iii.3 Swing Procedure In Standard Mode
6) ZCare gets in Standby mode and report itself to switch on the LED NWK in static orange during 2 seconds: Once the network parameters have been erased, it is possible to integrate the wristband into a ZigBee ZigBee® network in the same way as for a first use: see paragraph III.2.1.
Page 14: Iii.5 Procedure To Switch In Config Mode
2) Approach the magnet on the LED NWK side then click on call button: 3) The ZCare switches on LED NWK in fixe Orange during 2 seconds to inform its new state (Standby mode) : III.5 Procedure to switch in config mode Config mode allows to configure the functions of the wristband (Cf.
Page 15: Proceedings
To modify the value of this attribute, it is necessary to switch the wristband in config mode : Cf. paragraph III.5 When a fall is detected by the wristband Zcare, the wristband inform that an alert has been done in flashing 2 seconds the LED NWK in red.
Page 16: Iv.4 Settlement
3) The status change notification is immediately issued to cluster IASZone subscribers If this procedure is applied to a wristband Zcare which is not in emergency, LED NWK doesn’t switch on in green color. None notification of change status will be done by the wristband ZCare.
Page 17: Software Interface
V. Software interface V.1 Presentation The wristband ZCare is ZigBee® pro compliant, and Home Automation 1.2 compliant ZigBee® Alliance. It has IASZone application and manages 2 alarms : 1) A fall detection alarm 2) A manual press alarm V.2 ZCare Application The signaling of an alarm is done by means of a comand IASZone cluster.
Page 18: Cluster Identify
V.2.2.3 Cluster Identify This cluster is used to identify physically the ZCare in ZigBee® network. On writing a value in the attribute IdentifyTime, the wristband will flash the LED NWK in red during the specified value (in seconds). Attribute AttributeID...
Page 19 Time threshold for taking into account pressing the emergency call button in milliseconds Default value: 0x C8 (200ms) Taking account the absence of move after the fall detection is interpreted as follow by the algorithm of the ZCare: 1) If attribute...
Page 20 Fig 9 : Principe of validation of a heavy fall CLEODE User Manual: ZCARE : Warning Wristband page...
Page 21 Repair and maintenance The defective material elements will have returned to CLEODE accompanied by: A copy of the delivery note, A description of the failure observed and context. The delay is about 4 weeks. Repair is done Repair is assured by the manufacturers of the material elements to not cancel the guarantee of the element.
Page 22 Support and Maintenance 3 rue Thomas Edison 22300 Lannion Tel: +33 (0) 2 96 48 68 18 Fax: +33 (0) 2 96 48 19 11 E-mail: support@cleode.com Web: http://www.cleode.com User Manual End CLEODE User Manual: ZCARE : Warning Wristband page...
