D2E146-HT67-01

3.2 Nominal data

Motor M2E068-EC
Phase 1~
Nominal voltage / VAC 230
Frequency / Hz 50
Method of obtaining
ml
data
Valid for approval/ -
standard
-1
Speed (rpm) / min 1850
Power consumption / W 355
Current draw / A
1.55
Capacitor / µF 8
Capacitor voltage / VDB 450
Capacitor standard S2 (CE)
Min. back pressure / Pa 0
Min. ambient
-20
temperature / °C
Max. ambient 55
temperature / °C
Starting current / A 1.8
ml = Max. load · me = Max. efficiency · fa = Free air
cs = Customer specification · ce = Customer equipment
Subject to change

3.3 Technical description

Weight 3.25 kg
Size 146 mm
Motor size
68
Rotor surface Unpainted
Terminal box material PP plastic, black
Impeller material Sheet steel, hot-dip galvanized
Housing material PP plastic, black
Motor suspension
Motor vibration-damped on both sides
Direction of rotation Counterclockwise, viewed toward rotor
Degree of protection IP20
Insulation class "F"
Moisture (F) / H0 - dry environment
Environmental (H)
protection class
Installation position Shaft horizontal or rotor on bottom; rotor
on top on request
Condensation
None, open rotor
drainage holes
Mode S1
Motor bearing Calotte bearing
Speed levels 4
Touch current < 0.75 mA
according to IEC
60990 (measuring
circuit Fig. 4, TN
system)
Electrical hookup Plug; Via terminal box, capacitor
integrated and connected
Motor protection Thermal overload protector (TOP)
internally connected
with cable Variable
Item no. 10892-5-9970 · ENU · Change 202174 · Approved 2018-12-28 · Page 5 / 10
ebm-papst Mulfingen GmbH & Co. KG · Bachmühle 2 · D-74673 Mulfingen · Phone +49 (0) 7938 81-0 · Fax +49 (0) 7938 81-110 · info1@de.ebmpapst.com · www.ebmpapst.com
Operating instructions
Protection class
Motor capacitor
according to EN 60252-
1~
1 in safety protection
230
class
60
Conformity with
standards
ml
Approval
-
2100
400
1.75
; Use the device in accordance with its degree of protection.
8
450
Information on surface quality
S2 (CE)
The surfaces of the products conform to the generally applicable industrial
200
standard. The surface quality may change during the production period.
-20
This has no effect on strength, dimensional stability and dimensional
accuracy.
50
The color pigments in the paints used perceptibly react to UV light over
the course of time. This does not however in any way affect the
1.9 technical properties of the products. The product is to be protected against
UV radiation to prevent the formation of patches and fading. Changes in
color are not a reason for complaint and are not covered by the warranty.

3.4 Mounting data

; Secure the screws against unintentional loosening (e.g. use self-
For screw clearance, see Chapter 3.1 Product drawing
Strength class of
screws
Any further mounting data required can be taken from the product
drawing or Section Chapter 4.1 Mechanical connection.

3.5 Transport and storage conditions

Max. permitted
ambient temp. for
motor (transport/
storage)
Min. permitted
ambient temp. for
motor (transport/
storage)
I (with customer connection of protective
earth)
S2
EN 60335-1
EAC; CCC; VDE
With regard to cyclic speed loads, note that the rotating parts of
the device are designed for a maximum of one million load
cycles. If you have special questions, consult ebm-papst for
support.
locking screws).
8.8
+ 80 °C
- 40 °C
