Summary of Contents for Butts of Bawtry AIW0050
- Page 1 1/2" Super Heavy Duty Composite Body Impact Wrench AIW0050 ORIGINAL INSTRUCTIONS SAVE THESE INSTRUCTIONS AND PRECAUTIONS. READ ALL PRECAUTONS AND INSTRUCTIONS BEFORE USE.
-
Page 2: Specification
1. SAFETY WARNING! DO NOT use wrench if damaged or thought to be faulty. WARNING! Disconnect from the air supply before changing accessories or servicing. WARNING! Due to the possible presence of asbestos dust from brake linings, when working around vehicle brake systems we recommend you wear suitable respiratory protection. - Page 3 4. PREPARATION WARNING! Ensure the air supply is clean and does not exceed 90psi while operating the wrench. Too high an air pressure and/or unclean air will shorten the product life due to excessive wear, and may be dangerous causing damage and/or personal injury. 4.1.
-
Page 4: Operation
5. OPERATION WARNING! Ensure you read, understand and apply safety instructions before use. 5.1. Only use impact sockets which are specifically designed for use with an impact wrench. 5.2. Connect the wrench to the air hose as in section 4. 5.3. -
Page 5: Troubleshooting
7. TROUBLESHOOTING 7.1. Loss of power or erratic action may be due to the following: a) Excessive drain on the air line. Moisture or restriction in the air pipe. Incorrect size or type of hose connectors. To remedy check the air supply and follow instructions in section 4. - Page 6 Index Description Q'ty Index Description Q'ty ▲1 Housing Ass'y Air Regulator Air Inlet Bushing Throttle Valve Exhaust Deflector Seal Screw Spring Rear End Plate Spring Spacer Cap Screw Rotor Screw ★9 Rotor Blade Screw ▲10 Cylinder Screw Gasket Screw Front End Plate Screw Hammer Cage Washer...
