Summary of Contents for LG L17LM
- Page 1 FCC ID : BEJL17LM APPENDIX F : USER’S MANUAL...
-
Page 2: Regulatory Information
Regulatory Information FCC Compliance Statement CE Conformity Notice (for Europe) This equipment has been tested and found to comply within Products with the “CE” Marking comply with the EMC the limits of a Class B digital device pursuant to Part 15 of Directive(89/336/EEC) and LOW VOLTAGE Directive the FCC Rules. - Page 3 Regulatory Information cont. scheme, which provides for international environmental Lead can be found in picture tubes, display screens, solder, labelling of personal computers. The labelling scheme was and capacitors. Lead damages the nervous system and in developed as a joint effort by the TCO (The Swedish higher doses causes lead poisoning.
- Page 4 Regulatory Information cont. TCO99 The energy requirements include a demand that the computer and/or display, after a certain period of inactivity, shall reduce its power consumption to a lower level in one or more stages. The length of time to reactivate the computer shall be reasonable for Congratulations! the user.
- Page 5 (U.S.A only) is a set of power-saving guidelines NERGY issued by the U.S. Environmental Protection Agency(EPA). As an ENERGY STAR Partner LG Electronics U.S.A.,Inc. has determined that this product meets the ENERGY STAR guidelines for energy efficiency. EPA POLLUTION PREVENTER...
-
Page 6: Important Precautions
Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential e shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing. - Page 7 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
-
Page 8: Connecting The Display
Connecting the Display Using the Computer Connect the signal cable. When attached, tighten the thumbscrews to secure the connection. Connect the power cord into a proper power outlet that is easily accessible and close to the display. NOTE This is a simplified representation of the rear view. This rear view represents a general model;... - Page 9 Connecting the Display Side Jack Headphone/Earphone Input Automatically mutes the speaker volume when the headphones are plugged in. <Display> Bottom Microphone Output Connects to the microphone jack of the PC sound card. Microphone Input Connects to the microphone. Audio Input Connects to the *LINE OUT jack of the MIC.
-
Page 10: Control Panel Functions
Control Panel Functions Front Panel Controls Control Function Power Button Use this button to turn the display on or off. Power (DPMS) This Indicator lights up green when the display Indicator operates normally. If the display is in DPM (Energy Saving) mode, this indicator color changes to amber. - Page 11 Control Panel Functions Control Direct Access Function AUTO adjustment function When adjusting your display settings, always press the SELECT/AUTO button before entering the On Screen Display(OSD). This will automatically adjust your display image to the ideal settings for the current screen resolution size (display mode).
-
Page 12: On Screen Display (Osd) Control Adjustment
On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. The following section is an outline of the available adjustments and selections you can make using the OSD. - Page 13 On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu Sub menu Reference BRIGHTNESS BRIGHTNESS To adjust the brightness and CONTRAST contrast of the screen CONTRAST PRESET 9300K COLOR To customize the color of the screen...
-
Page 14: On Screen Display(Osd) Selection And Adjustment
On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. NOTE OSD (On Screen Display) menu languages on the monitor may differ from the manual. -
Page 15: To Improve The Clarity And Stability Of The Screen
On Screen Display(OSD) Selection and Adjustment To improve the clarity and stability of the screen OSD Adjust Description To minimize any vertical bars or CLOCK stripes visible on the screen background.The horizontal screen size will also change. PHASE To adjust the focus of the display. This item allows you to remove any horizontal noise and clear or sharpen the image of characters. -
Page 16: Troubleshooting
Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the Check and see if the power cord is connected display connected? properly to the power outlet. Is the power indicator Press the Power button. -
Page 17: Display Image Is Incorrect
Troubleshooting Display image is incorrect Display Position is Press the SELECT/AUTO button to automatically incorrect. adjust your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display. -
Page 18: Have You Installed The Display Driver
Troubleshooting Have you installed the display driver? Have you installed the Be sure to install the display driver from the display driver? display driver CD (or diskette) that comes with your display. Or, you can also download the driver from our web site: http://www.lge.com. Do you see an Make sure to check if the video card supports "Unrecognized monitor,... -
Page 19: Specifications
Specifications 17 inches (43.2cm) Flat Panel Active matrix-TFT LCD Display Anti-Glare coating 17 inches viewable 0.26 mm pixel pitch Horizontal Freq. 30 - 83kHz (Automatic) Sync Input Vertical Freq. 56 - 75Hz (Automatic) Input Form Separate TTL, Positive/Negative Composite TTL Positive/Negative SOG (Sync On Green) Video Input Signal Input... -
Page 20: Preset Modes (Resolution)
Specifications Preset Modes (Resolution) Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.469 640 x 350 31.468 720 x 400 31.469 640 x 480 VESA 37.500 640 x 480 VESA 37.879 800 x 600 46.875 VESA 800 x 600 49.725 832 x 624 48.363... -
Page 21: Usb Connection
Making use of USB (Universal Serial Bus) - Optional USB (Universal Serial Bus) is an innovation in connecting your different desktop peripherals conveniently to your computer. By using the USB, you will be able to connect your mouse, keyboard, and other peripherals to your display instead of having to connect them to your computer. -
Page 22: Usb Specifications
Making use of USB (Universal Serial Bus) - Optional USB Specifications Rev. 1.1 complied BUS-powered hub USB standard Downstream power supply 100mA for each (MAX) Communication speed 12 Mbps (full), 1.5 Mbps (low) 1 Upstream port USB port 2 Downstream ports IMPORTANT: These USB connectors are not designed for use with high-power USB devices such as a video camera, scanner, etc.
