- Page 1 User’s Guide N1742L N1942L ake sure to read the Important Precautions before using the product. Keep the User's Guide(CD) in an accessible place for future reference. ee the label attached on the product and give the information to your dealer when you ask for service.
-
Page 2: Important Precautions
Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential electrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing. - Page 3 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
- Page 4 Important Precautions NOTE THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV INTRERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS EQUIPMENT.SUCH MODIFICATIONS COULD VOID THE USER'S AUTHORITY TO OPERATE THE EQUIPMENT. NOTE This epuipment has been tested and found to comply with the limits for a class B digital device,pursuant to part 15 of the FCC Rules.These limits are designed to provide reasonable protection against harmful interference in a residential installation.This equipment generates,uses and can radiate radio frequency...
- Page 5 Important Precautions On Cleaning Unplug the display before cleaning the face of the display screen. Use a slightly damp (not wet) cloth. Do not use an aerosol directly on the display screen because over-spraying may cause electrical shock. When cleaning the product, unplug the power cord and scrub gently with a soft t a r h t i other liquids directly onto the product.
-
Page 6: Connecting The Display
Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connecting the stand Place the monitor with its front facing downward on a soft cloth. Assemble the Stand Body into the product in the correct direction as shown in the picture. -
Page 7: Disassembling The Stand
Connecting the Display Disassembling the stand Put a cushion or soft cloth on aflat Place the monitor face Down on surface. the cushion or soft cloth. Change your lock on the product as it follows and turn it in the arrow direction. If you can't release the stand base even the locking knob is at a release position, Please push the indicated knob down and retry it. -
Page 8: Positioning Your Display
Connecting the Display Pushing the PUSH button, Take the stand base from stand body. Warning: You can hurt your finger. Good Position Bad Position Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Positioning your display Adjust the position of the panel in various ways for maximum comfort. -
Page 9: Using The Computer
Connecting the Display Using the Computer Make sure to turn off the computer and product. Connect the cable as below sketch map form Connect LAN Cable (X550 port) Connect Dsub Cable (PC) Connect Dsub Cable (Mac) NOTE This is a simplified representation of the rear view. This rear view represents a general model;... - Page 10 Connecting the Dispaly Connecting to a X550 port using a LAN cable. Cautions Turning the power off while booting the PC may damage the product. Turning the power off while booting the PC may cause it to operate incorrectly. If the mouse is connected using a USB device and is not detected, disconnect and connect it again.
-
Page 11: Control Panel Functions
Control Panel Functions Front Panel Controls MENU SOURCE Use this button to enter or exit from the On Screen Display. MENU Button OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that these settings are not inadvertently changed. To lock the OSD settings, press and hold the MENU button for several seconds. - Page 12 Control Panel Functions Use these buttons to select or adjust functions in the SOURCE On Screen Display. Use this button to make either D-Sub or X-PORT connector active. This feature is used when two input sources are connected to the display. Use these buttons to select or adjust functions in the On VOLUME Screen Display.
-
Page 13: On Screen Display (Osd) Control Adjustment
On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. The following section is an outline of the available adjustments and selections you can make using the OSD. -
Page 14: On Screen Display(Osd) Selection And Adjustment
On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. X : X-PORT Input NOTE The order of icons may differ depending on the model (A12~A17 ). - Page 15 On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the MENU Button, then the main menu of the OSD appears.
- Page 16 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description PICTURE PICTURE To adjust the brightness of the screen. BRIGHTNESS To adjust the contrast of the screen. CONTRAST Set your own gamma value. : -50/0/50 GAMMA On the monitor, high gamma values display whitish images and low gamma values display high contrast images.
- Page 17 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description POSITION To move image left and right. HORIZONTAL To move image up and down. VERTICAL MENU : Exit : Decrease : Increase SET : Select another sub-menu TRACKING To minimize any vertical bars or CLOCK stripes visible on the screen background.
- Page 18 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description SETUP To choose the language in which the LANGUAGE control names are displayed. To adjust position of the OSD window POSITION on the screen. If the output of the video card is different WHITE BALANCE the required specifications, the color...
- Page 19 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description MOVIE This feature lets you easily select the best desired INTERNET image condition optimized to the environment F-ENGINE (ambient illumination, image types etc). MOVIE: For animation images in videos or movies INTERNET: For text images (Word processing etc.) USER User...
-
Page 20: Troubleshooting
Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the • Check and see if the power cord is connected display connected? properly to the power outlet. Is the power indicator •... -
Page 21: Display Image Is Incorrect
Troubleshooting Display image is incorrect Display Position is • Press the AUTO/SET button to automatically incorrect. adjust your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display. -
Page 22: Have You Installed The Display Driver
Troubleshooting Display image is incorrect The screen color is • Check if the signal cable is properly connected mono or abnormal. and use a screwdriver to fasten if necessary. • Make sure the video card is properly inserted in the slot. •... -
Page 23: Specifications
Specifications N1742L Display 17 inches (43.2 cm) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size: 43.2 cm 0.264 mm pixel pitch Horizontal Freq. 30 - 66 kHz (Automatic) Sync Input Vertical Freq. 57 - 63 Hz (Automatic)(640x350/720x400 support 70Hz) (RGB support 60Hz only(except Dos mode)，X-PORT can support ~75Hz) Input Form Separate TTL... - Page 24 Specifications N1942L Display 19 inches (48.2 cm) Flat Panel Active matrix-TFT LCD Anti-Glare coating Visible diagonal size: 48.2 cm 0.294 mm pixel pitch Horizontal Freq. 30 - 83 kHz (Automatic) Sync Input Vertical Freq. 56 - 75 Hz (Automatic)(640x350/720x400 support 70Hz) (RGB support 60Hz only(except Dos mode)，X-PORT can support ~75Hz) Input Form Separate TTL...
-
Page 25: Preset Modes (Resolution)
Specifications Preset Modes (Resolution) Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.469 640 x 350 31.468 720 x 400 31.469 640 x 480 37.879 800 x 600 48.363 1024 x 768 63.981 1280 x 1024 * Recommend Mode Indicator MODE LED Color... -
Page 26: Installing The Wall Mount Plate
Installing the Wall mount plate This monitor satisfies the specifications of the Wall mount plate or the interchange device. Place the monitor with its front facing downward on a soft cloth. Separate the stand by pushing the PUSH button. Good Position Bad Position Warning: You can hurt your finger. - Page 27 Digitally yours...
