Summary of Contents for Bigaole 6G-B
- Page 2 2.2 Mode selection Transmitter setting Turn on the transmitter and create a new model,set the trims and sub-trims of all channels to zero,making that all mix-function are off. S1/S2 for corresponding Model Diagram AILE OUT ELEV OUT RUDD OUT Normal Ai AIL Servo ELE Servo RUD Servo...
- Page 3 3. LED Status Turn the switch 1 and 2 to the “ON” position to initialize when you use the 6G-B first . LED flashes rapidly for 10 seconds after power on. When the LED is steady on, Initialization is ok , Then cut off the power and turn the switch S1 and S2 into corresponding flying type.
- Page 4 6.2 Gyro gain Direction Verifiaction a.)Please adjust the direction and range of the two channels :AIL,ELE At the balance mode, pick up the aircraft around the pitch axis and the roll axis to check if the direction and range is correct. Adjust the screw correspond to AIL and ELE to the optimal position. Gyro Gain Correction Diagram 1.Rotaing the plane around pith axis .check the correction of gain for elevator as showing in the diagram 1 and 2 2.Rotaing the plane around roll axis .check the correction of gain for aileron as showing in the diagram 3 and 4.
