Genius Audio GHL-5C3V User Manual

GHL-5c3v / GHL-5c7v
professional converter high to low
Product Introduction:
Thanks for your purchase of this unit. Please read this manual carefully
before installing to get more better using.
Product Feature:
1. Adjustable gain output
2. Volume control Max to 3V output (GHL-5C3V) / 7V output (GHL-5C7V)
3. 5 Channel pre amp output, one of with
SUBWOOFER pre amp output
4. Optional with 4Ch. RCA input or with 4Ch. High-level input
5. REM wire connection to car amplifier REM wire connection when
use high-level input
CH 1
power
HI input

INPUT PANEL

1. 1/2CH. High Level: FL, FR channels high-level signal input; connect
to car head unit speaker cable
2. 3/4CH. High Level: RL, RR channels high-level signal input; connect
to car heah unit speaker cable
3. 1CH. FL channel input; connect to car head unit FL channel RCA input
4. 2CH. FR channel input; connect to car head unit FR channel RCA input
5. 3CH. RL channel input; connect to car head unit RL channel RCA input
6. 4CH. RR channel input; connect to car head unit RR channel RCA input
CH 2 CH 3 CH 4
line input

INSTALLATION:

ADJUSTMENT SETTINGS

Before starting: Please turn down the master volume to minimum; and
please tune down the signal source volume to minimum.
Starting UP: Once finished the signal source wire connection, please start
up this unit.
Adjustment: Please turn down the volume to minimum, then, turn up the
volume slowly and listen carefully to check if there has distortion or not.
Please adjust the volume to a proper level till can´t hear the distortion, and
turn down the volume to minimum, then adjust the volume to comfortable
level.

PRODUCT SPECIFICATION

3V (GHL-5C3V) / 7V (GHL-5C7V)
