- Page 1 MS Series Confidence Monitoring System Owner’s Manual Furman Sound, Inc. 1997 South McDowell Blvd. Petaluma, CA 94954-6919 U.S.A. Phone: (707)763-1010 Fax: (707) 763-1310 www.fur mansound.com E-mail: info@furmansound.com 1-0126 960144-3050...
-
Page 2: Table Of Contents
Table of Contents Introduction ... 3 Package Contents ... 3 Product Description ... 3 Setup and Guided Tour ... 4 Analog Audio Monitoring ... 4 Digital Audio Monitoring ... 5 Analog Outputs... 5 Video Monitoring ... 5 System Verification ... 6 Initial Setup ... -
Page 3: Introduction
A manufacturer of quality professional audio, video, and AC power products for over a quarter century, Furman stands behind the MS Series with a Three Year Limited Warranty and a firm commitment to customer satisfaction. Knowledgeable technicians and sales staff are available to answer questions about this or any other Furman product quickly and directly via telephone, fax, or e-mail. -
Page 4: Setup And Guided Tour
Setup and Guided Tour Operation of the MS Series is basic and straightforward. The controls and operation are mostly intuitive and self-explanatory, but are discussed here in detail to allow any user to operate it successfully. Install the unit in its rack and connect the external power supply to the 5-pin DIN DC POWER INPUT connector on the rear panel. -
Page 5: Digital Audio Monitoring
Digital Audio Monitoring On MS Series units equipped for digital audio, stereo digital signal(s) may be connected via the rear panel BNC connector(s) labeled AES1, and, if present, AES2. Only one connector is needed per stereo signal. The digital input(s) conform to the AES/EBU 75 ohm/BNC (AES-3id-1995) standard. Another standard, S/PDIF 75 ohm coaxial, may also be monitored. -
Page 6: System Verification
System Verification The procedure below is the same Final Test performed on MS Series units at the factory. Assuming there has been no apparent damage in shipment, it is not necessary to repeat it. However, it may be desirable to perform it as an initial confirmation of proper operation, as a periodic performance check, or whenever there is doubt about the unit’s operation. - Page 7 7 . The LED DIMMER control comes set for full display brightneess when shipped but can be adjusted to suit the monitoring facilities needs so as not to be distracting if a less than fully bright meter display is desired. Note: The level meter brightness CANNOT be adjusted to “Full Off.”...
-
Page 8: Warranty Information
Furman factory or one of its Authorized Repair Stations. This warranty may be cancelled by Furman at its sole discretion if the unit has been subjected to physical abuse or has been modified in any way without written authorization from Furman. -
Page 11: Specifications
MS Series Specifications Analog audio: Digital audio: (if present) Video: (if present) Analog audio: Headphone: Inputs 2 (or 4) each female balanced XLR CMRR: Differential Input Impedance: Maximum Input Level: Signal present indicator: 1 (or 2) each BNC, AES/EBU Resolution: Sampling Frequency: Oversampling: Internal Clock:... - Page 12 Type: 2 each, 1.5" x 2.75" full range, acoustically tuned with chassis damping. Each channel driven by 20 Watt amplifier. Output: 87 ±6 dB SPL at 1 meter, 150 Hz to 16 kHz Magnetically shielded Front Panel: Volume Balance (non-video units only) VU/PPM Select Speaker Mute +4/+8 dBu Reference Level Select...
