Summary of Contents for Furman HDS-6
- Page 1 HDS-6 / E HR-6 HEADPHONE DISTRIBUTION SYSTEM AND PERSONAL HEADPHONE MIXER HEADPHONE MONITORING SERIES...
- Page 2 HDS-6/HR-6 HEADPHONE DISTRIBUTION SYSTEM INTRODUCTION Thank you for your purchase of a Furman HDS-6 Headphone Distribution System and HR-6 Personal Headphone Mixer* – and congratulations on your choice. We based this system on our own experiences with major recording projects and studios. You now own a headphone system that will make all of your sessions flow more smoothly.
- Page 3 HDS-6/HR-6 HEADPHONE DISTRIBUTION SYSTEM DESCRIPTION The Furman Headphone Distribution System is easy to set up, and makes your music sound great. It provides custom headphone mixes to a number of people in recording and rehearsal environments. The system consists of the rackmount HDS-6 Headphone Distribution System, and one or more Furman HR-6 Personal Headphone Mixers.
- Page 4 HDS-6/HR-6 HEADPHONE DISTRIBUTION SYSTEM LINKING HDS-6 TO HR-6 The HDS-6 links to your mixer or patch bay via the six TRS 1/4" phone jacks on the right side of the HDS-6 rear panel, as shown on the drawing below. You’ll have four mono jacks for the signals coming from the direct channel out of the busses of your mixer and two more jacks for the Left and Right stereo inputs from your mixer (or two more...
- Page 5 HDS-6/HR-6 HEADPHONE DISTRIBUTION SYSTEM Control: This small trim pot controls the LEVEL SET amount of gain the HR-6 applies to the signal from your console before the signal is sent. The control is designed to be adjusted by a small screwdriver to prevent accidental changes of its setting during tracking or playback.
- Page 6 HDS-6/HR-6 HEADPHONE DISTRIBUTION SYSTEM HR-6 CONTROLS Now that you have your HDS-6 connected to your console, and your chain of HR-6 mixing stations is connected to your HDS-6, the fun begins. Here’s all you need to know to create a custom headphone mix with an HR-6: Volume Controls: The front panel of the SUBMIXES...
-
Page 7: Limited Warranty
Manufacturer shall authorize Purchaser to return the Product to the Furman factory or to an au- thorized Furman repair location. Warranty claims should be accompanied by a copy of the original purchase invoice showing the purchase date;... - Page 8 NOTE: All equipment being returned for repair must have a Return Authorization (R/A) Num- ber. To get an R/A Number, please call the Furman Service Department: (707) 763-1010, ext. 120 or 121. Please display your R/A Num- ber prominently on the front of all packages.
