5. Program setting

CURRENT
TARGET
CLOCK HEAT
SET OK
4 6 8 10 1214
2
1 3 5 7 9 1113 15
1
Press OK for 3 seconds,enter into P1~P8 program setting
2
Press SET,switch between P1~P8, for example we choose P2
3
Press OK ,TARGET is flashing
4
Press UP/DOWN,set the TARGET value
5
Press OK
6
Press UP/DOWN,choose(MO,TU,WE,TH,FR,SA,SU,MO-FR,
MO-SA, SA-SU, MO-SU)
7
Press OK
8
Press UP/DOWN,set hour of P2 ON
9
Press OK
10
Press UP/DOWN,set minute of P2 ON
11
Press OK
12
Press UP/DOWN,set hour of P2 OFF
13
Press OK
14
Press UP/DOWN,set minute of P2 ON
15
Press OK, back to program switching interface, at this time, you
can press SET button switch to P1, P3,P4,P5,P6,P7,P8,
repeat above steps to set other programs.
For example, we set as 30°C,MO-FR,18:00~23:00,show in Pic.2 and Pic.3
It means, from Monday to Friday, 18:00 to 23:00, TARGET temperature
change to 32°C,in other time, keep in 25°C
(Standard heating mode,see Pic.1)
Remark:
* P1~P4, it is period for HEATING, P5~P8, it is period for COOLING
* During setting, if you don't want to set, press POWER button to exit.
* During setting, if no operation for 10 seconds,automatically save and exit.

6. Turn on/Turn off P1~P8 programs

Press SET, enter programming ON/OFF selection,
1
ON or OFF(default) symbol is flashing.
2
Press UP/DOWN to select the ON,or OFF.
ON: turn on all programming at once,P display next to
the time,the P1~P8 program is working(see Pic.4).
OFF: turn off all programming at once,P disappear,
only standard heating or cooling is working.
3
Press OK
CURRENT
TARGET

7. How to switch Heating/Cooling mode

Pic.2
SET
CURRENT
TARGET
CURRENT
TARGET
CLOCK
Pic.3
SET OK
SET
3
1
Press UP for 3 seconds,enter selection between
1
heating (default) and cooling mode
Press UP/DOWN,select Flame(
2
Flame represents HEATING mode
Snow represents COOLING mode
3
Press OK
CURRENT
CURRENT
TARGET
TARGET
CLOCK
SET OK
2
CLOCK
Pic.4
1
3
CURRENT
TARGET
1
HEAT
CLOCK
SET OK
2
Cooling mode
) or Snow symbol( )

8. Working principle

Heating Mode:
1. When CURRENT< TARGET, it will be in ON status,the flame symbol
( )will display in LCD,turn on connected heaters,start to warm the
room, so the room temperature is rising.
2. As current temp. rising, CURRENT=TARGET, it will be in OFF status,
the flame symbol( )will disappear,remote thermostat will send OFF
commands to turn off all connected heaters.
3. The current temperature will be decreasing, when current temp.
decreased 1°C/1.8°F, it will turn on all connected heaters once again,
then infinite loop.
So in the HEATING mode, remote thermostat control will automatically
keep the room temp. in below range:
Target Temp.-1°C/1.8°F ≥ Room Temp. ≥Target Temp.
Cooling Mode:
1. When CURRENT> TARGET, it will be in ON status,the snow symbol
( )will display in LCD display,turn on connected cooling devices,
start to cool down the room, so the room temperature is decreasing.
2. As current temp. rising, CURRENT=TARGET, it will be in OFF status,
snow symbol( )will disappear from LCD display,remote thermostat
will send OFF commands to turn off all connected cooling devices
3. The current temperature will be rising, when current temp. increased
1°C/1.8°F, it will turn on all connected cooling devices once again,
then infinite loop.
So in the COOLING mode, remote thermostat control will automatically
keep the room temp. in below range:
Target Temp. ≤ Room Temp. ≤ Target Temp.+1°C/1.8°F

9. Other functions

Children Lock

1
In any mode(except standby mode),
child lock will be activated if no activity
for 10 minutes, the child lock symbol(
will appear in the top of LCD display.
Press DOWN button for 3 seconds to
disengaged child lock.
2

Reset

During heating/cooling mode,
Press UP&DOWN button at the
same time for 3 seconds.
The green backlight will flash 3 times,
all setting will be deleted, and back to
factory setting.
)
CURRENT
TARGET
1
CLOCK HEAT
SET OK
