Elekit JS-685E Instruction Manual

Super solar car
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
685E-03
Lot.No.
SUPER SOLAR CAR
MODEL:JS-685E
Keep the Instruction Manual ready at hand for use at any time.
EK JAPAN CO.,LTD. 2001

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JS-685E and is the answer not in the manual?

Questions and answers

Summary of Contents for Elekit JS-685E

  • Page 1 685E-03 Lot.No. SUPER SOLAR CAR MODEL:JS-685E Keep the Instruction Manual ready at hand for use at any time. EK JAPAN CO.,LTD. 2001...

  • Page 2: Table Of Contents

    Contents ・ Product Information 1. Necessary Tools •••••••••••••••••••••••••••••••••••••••••••••••••••• 2. Before Assembly ••••••••••••••••••••••••••••••••••••••••••••••••••• 3. Parts List ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 4. Assembly •••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 5. Let’s Operate! ••••••••••••••••••••••••••••••••••••••••••••••••••••••• 6. Operation Check ••••••••••••••••••••••••••••••••••••••••••••••••••• 7. Solar Battery •••••••••••••••••••••••••••••••••••••••••••••••••••••••• 8. Spare Parts List ••••••••••••••••••••••••••••••••••••••••••••••••••••• PRECAUTION ◆R ead this instruction manual carefully before getting started. Have your par- ents or someone who can help you read the instruction manual with you.

  • Page 3: Product Information

    ● Product Information ・T he SUPER SOLAR CAR, with its high and low gear mechanisms, is suit- able for use even in winter. ・T he angle and direction of the solar battery is adjustable, which are the im- portant factors to decide the amount of power generation. ・U nique front wheel drive style.

  • Page 4: Necessary Tools

    1. Necessary Tools Scissors Small Hammer Used for cutting adhesive double coat- Used for driving the gear onto the motor. ed tapes and processing body parts. Pen Knife Electrical / Plastic Tape Used for taping exposed wires and for Used for stripping the vinyl insulation off holding wires in place.

  • Page 5: Before Assembly

    2. Before Assembly Use the following instructions if you would like to paint the body: 1. Paint body first and complete assembly process second. 2. Before painting, wash the plastic body gently with a detergent and then dry completely. 3. Body part is made of plastic(P.V.C).Use color paints compatible with plastic models.

  • Page 6: Parts List

    3. Parts List Check each box to confirm that all parts are enclosed. □ Front wheel (without a gear) □ Front tires 2pcs □ Rear tires □ Gear-mounted front wheel 2 pcs □ Rear wheels □ Wheel stoppers □ Drive shaft stopper 2 pcs 2 pcs 1 pc...
  • Page 7 □ Rear chassis □ Motor 1 pc 1 pc □Flat spur gear (24cogs) □ Metal shaft 1 pc with pinion (12 cogs) 1 pc □A dhesive double □ Red wire □ Battery box 1 pc 1 pc □ Black wire sided tape 1 pc 1 pc...

  • Page 8: Assembly

    Assembly 1. Assembling the rear wheels ① to ② . Assemble the rear wheels in order of steps Wheel stopper ① Rear tire Attach the rear tires onto the rear wheels. Shaft Rear wheel Rear chassis Rear tire Shaft Wheel stopper ②...
  • Page 9 2. Attaching the front wheels and the motor 1) Assemble the front wheels by following steps ① and ② . Front wheel (without a gear) ① Attach the front tires to the gear-mounted front wheel and the other front wheel with- out a mounted gear.
  • Page 10 IMPORTANT Gently tap in the front wheels, so that the wheel assembly come to match the wheel width as illustrated. The distance illustrated is the actu- al size of the wheel assembly. If the assembly is too wide, the gears may not engage well , and will not operate correctly.
  • Page 11 3) Attach the flat spur gear with pinion as below. (Set the gear by selecting either low-speed or high-speed rotation.) When setting the low-speed rotation When setting the high-speed rotation Attach the flat spur gear with pinion to Fit the flat spur gear with pinion into the boss which has an “L”...
  • Page 12 5) Mount the front wheel in order of ① to ② ① Insert the front wheel Drive shaft stopper *Watch the orientation when insert- shaft into the groove. ing. Front wheel ② Insert the drive shaft stopper as shown. *Align the gear-mounted front wheel, so that it engages the spur gear on the motor Illustration of the completed front wheel unit...
  • Page 13 3. Wiring 1)Routing the wire to the switch lever Motor wire (red) ① Remove the insulation on the motor wire approx. 3/4”more. 2 cm (Approx. 3/4”) Switch lever *Make sure not to wire the switch lever the wrong way. The lever has a face and a reverse.
  • Page 14 3) Attaching the switch lever Battery Box Solar Battery 4) Combining the wires Combine the exposed ends of the three wires (white / black motor wires, black battery box wire and the loose black wire) by twisting them together, then completely tape the exposed wires with electrical tape together. Battery box wire (black / -) Loose black wire Motor wire (white or black)
  • Page 15 5. Attachment of the front and rear wheels to the body Stick the front and rear wheel units to the inside of the body by using the double sided adhesive tape. Bosses Insert the Red and Black loose wires through this hole. *Carefully align the unit as illustrated.
  • Page 16 6. Attaching the battery box Attach the battery box at this position, using an adhesive double sided tape. 7. Attaching the solar battery 1) Assemble the 2) Attach the solar battery as shown. battery stand Solar battery as shown. *Attach the bat- Solar battery pedestal tery in the center.
  • Page 17 4) Wire the black and red wire onto the solar battery as shown. As in the illustration, wire the black and red wire into the terminal metal fitting provided on the solar battery. Make sure to tighten up the nut. Otherwise it will not operate.

  • Page 18: Let's Operate

    Let’s Operate! A T T E N T I O N ●Before operating the CAR, check again for incorrect wiring and attachment of parts. Errors in wiring and attaching the parts may lead to malfunction of the CAR. ●N ote that the CAR will not run on the cloudy days or in the shaded places, or under the light of a fluorescent lamp, which has a different light from that of the sun.
  • Page 19 1. How to operate the CAR 2) Adjust the angle so 1) Turn on the switch. the sunlight shines With the switch lever properly fitted, onto the solar bat- turning the lever toward the SOLAR tery at right angles. side sets the CAR ready for running by the solar battery.
  • Page 20 2. Ideas to custom build your CAR How to raise or lower the body. ◆T here are two ways to attach the wheels as shown below. (The illustra- tions below show the side views of the front and the rear wheel units.) To raise the body level Car body To lower the body level...

  • Page 21: Operation Check

    Operation Check The CAR be- Check whether the tires are touching the body. comes inopera- tive when fitted to the body. The CAR does Check whether the sunlight is sufficiently falling on the not move on solar battery. When the weather turns cloudy, the sun- cloudy days.

  • Page 22: Solar Battery

    Solar battery ● Mechanism of the solar battery The solar battery is made from materials called semiconductors (silicon, ger- manium, etc.). This battery has characteristics that electricity flows when a light falls on the battery. There are three types of semiconductors which are, a little different in their properties, respectively called p-type semiconductor , intrinsic semiconductor and n-type semiconductor .
  • Page 23 (1) When the battery receives a light energy, an electron jumps out of the intrinsic semiconductor, leaving a hole behind. Electron P-type hole semiconductors Intrinsic semiconductors N-type semiconductors Electron (2) The electron, which has jumped out of the intrinsic semiconductor, is pulled toward the n-type semi- conductor.
  • Page 24 ● Characteristics of the solar battery A silicon solar battery receives a light on its cell surface and takes out elec- tricity from the lead provided on the electrodes mounted respectively on the face and reverse. Irradiation of the light is called “ input of the light ”, while electric output that can be taken out is simply named “...

  • Page 25: Spare Parts List

    Solar battery pedestal 4701279 Front tire 4701286 Rear tire 4710370 SOLAR CAR body 7003790 Instruction Manual JS-685E When ordering parts, please include the following: 1. Name, address and phone number. 2. Model name and Model number. 3. Part number, description, and quantity.
  • Page 26 EK Japan Co.,Ltd. FUKUOKA, JAPAN. NOTICE ①MOVIT and ELEKIT are registered trademarks of EK Japan Co.,Ltd. ②All rights reserved. Reprinting any of this instruction manual without our permission is forbidden. ③The specifications, form, and contents of this product are subject to change without prior notice.
