Storage Hall
132013R 13'x20'x13'
W4.0xL6.0xH4.0m
Assembly Instructions
RECOMMENDED TOOLS
Please read instructions COMPLETELY before assembly. This shelter MUST be securely anchored.
THIS IS A TEMPORARY STRUCTURE AND NOT RECOMMENDED AS A PERMANENT STRUCTURE.
Before you start: 3+ individual recommended for assembly, approximate time 4.5 hr.
Page 1
Advertisement
Table of Contents
Related Manuals for SHELTER 132013R
Summary of Contents for SHELTER 132013R
- Page 1 Assembly Instructions RECOMMENDED TOOLS Please read instructions COMPLETELY before assembly. This shelter MUST be securely anchored. THIS IS A TEMPORARY STRUCTURE AND NOT RECOMMENDED AS A PERMANENT STRUCTURE. Before you start: 3+ individual recommended for assembly, approximate time 4.5 hr.
-
Page 2: Care And Cleaning
PROPER ANCHORING OF THE FRAME IS THE RESPONSIBILITY OF THE CONSUMER. We are not responsible for damage to the unit or the contents from acts of nature. Any shelter that is not anchored securely has the potential to fly away causing damage, and is not covered under the warranty. Periodically check the anchors to ensure stability of shelter. - Page 3 Parts List for Storage Hall 132013R W4.0xL6.0xH4m Part Code Description of Parts (PC) Roof Bent Tube Shoulder Bent Tube Upright Upright for Back Wall Purlins Tension Pipe Bracing Pipe The Front Wall Rail Hangar Rod Pulling Rod Upright for Back Wall...
- Page 4 Carriage Bolt M10x80mm for 21+3 purlins） Bolt M8x70mm for arches connection and the upright 52+6 connection of back wall Bolt M10x30mm for Connection Plate Bolt M10x60mm for Connection Plate Bolt M8x50mm for Bracing Pipe Pipe Clip 60# Tension Strap 32*1000mm Plastic Plug Φ32 Stake Anchors 14*450 Nylon Ropes 4# 100m（20m/pcs *...
-
Page 5: Base Plate Installation
INSTALLATION PROCESS Base Plate Installation Please refer to the diagram below to mark the position of base plates Frame Installation Step 1: Arch No.1 (Front Wall) Page 5... - Page 6 Step 2: Arch No.2, No.3 Page 6...
- Page 7 Step 3: Arch No.5 (Back Wall) Page 7...
- Page 8 Step 4: Purlins and Sidewall Bracing Tubes Step 5: Squaring Up The Frame and Install Stake Pegs Page 8...
-
Page 9: Cover Installation
Cover Installation Front Cover and Front Door Back Cover Page 9... - Page 10 Roof Cover Now your assembly is completed. Page 10...
