Summary of Contents for Fusion Flow FG-P
- Page 1 O&M Operation and Maintenance Manual for Fusion “Flow” series TOP ENTRY open tank mixers Models FG-P, FR-P, & FW-P...
-
Page 2: Table Of Contents
Contents Safety…………………………………………………………………………1 Inspection…………………………………………………………………..2 Storage………………………………………………………………………..2 Installation……………………………………………………………….…2-6 Maintenance………………………………………………………………..6-7 Warranty……………………………………………………………………..8 Contact Info……………………………………………………………….…..8 Section 1 – Safety... -
Page 3: Safety
Nameplates are intentionally left on the units so you can find this information. If you have difficulty locating this information, contact Fusion Fluid Equipment and we will find it for you. -
Page 4: Inspection
Please reference the approval drawing for these loads. If you do not have them, contact your Fusion rep to obtain them. Fusion is not responsible for damage done to the tank or injury to persons due to inadequate tank... - Page 5 In addition, there are only a few ways to orient the gearbox so that gear lubrication is not compromised. Please call Fusion to get a 3D layout of your application done in order to properly angle mount your mixer.
- Page 6 Caution: There are several pinch points on the mixers 2. Mount the mixer to the desired location. Be careful, as there are several pinch points in the mounting hardware, couplings, hubs, etc. Once the desired position and mounting angles are achieved, tighten all of the hardware to the torque specifications in the table below.
- Page 7 6. Electric Components: All wiring of motors, VFD’s, panels, and controls should be done according to local code. If any wiring was provided by Fusion, please have your electrical inspector inspect all connections, conductors, etc. to verify that the installation is acceptable.
-
Page 8: Maintenance
NOTE: Wire so impeller rotates clockwise when viewed from behind the gearbox Section 5 – Maintenance Warning: Turn off power to the mixer before any maintenance 1. Lubrication is the most important key to prolonging the life of your mixer. Be sure to regularly grease all fittings on the mixer. - Page 9 2. For harsh, washdown, or wet environments, special attention is required. These units are provided with additional o-rings and lip seals to prevent contamination from entering or leaving the drive. High pressure washing can allow water to enter through the seals. Check for water contamination as described in step 1 and also regularly remove motor drain plugs to remove any water.
-
Page 10: Warranty
NOTE: Any modifications or corrective work done to the equipment which were not specifically authorized in writing by Fusion Fluid Equipment LLC shall void this limited warranty, and Fusion Fluid Equipment LLC shall accept no liability for any of the corrective work or expenditures which were conducted without their prior, written authorization.
