Rider Concept KINGTOYS moto 1000GS Owner's Manual

Children's electronic motorcycle
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MANUEL EN COURS DE TRADUCTION

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KINGTOYS moto 1000GS and is the answer not in the manual?

Questions and answers

Related Manuals for Rider Concept KINGTOYS moto 1000GS

Summary of Contents for Rider Concept KINGTOYS moto 1000GS

  • Page 1 MANUEL EN COURS DE TRADUCTION...
  • Page 2 CHILDREN’S ELECTRONIC MOTORCYCLE OWNER’S MANUAL Styles and colo(u)rs may vary. Adult assembly required. Read and understand this entire manual before using. Before first time use, charge the battery for at least 8-12 hours. Please keep this manual for future reference as it contains important information.
  • Page 3 On the purchase of your new Ride-On. This ride-on car will provide your child with many miles of riding of enjoyment. To help assure you and your rider a safe ride we ask you to please read this manual carefully, and keep it for future reference. Follow the recommendations in this manual, they are designed to improve the safety and operation of your ride-on car and it’s rider.

  • Page 4: Parts List

    Parts List PART PART NAME Q’TY (PCS) REMARKS Vehicle body Rear number plate Tank cover Lock nut Ø8 washer Side wheel Iron tube Brake Wheel Gear box Rear axle Front axle Front fork Front fender Face guard Handle bar Spanner Charger BATTERY INFORMATION ●...

  • Page 5: Parts Diagram

    Parts Diagram...
  • Page 6 Attach the Rear Wheel...

  • Page 7: Attach The Front Wheel

    Attach the Front Wheel Front axle 1. Tighten a lock nut to the end of the front axle with a spanner. 2. Slide a Ø8 washer onto the front axle. 3. Insert the front axle through the hole on one side of the front fork. Slide a brake on the front axle.

  • Page 8: Attach The Handle Bar

    Attach the Handle Bar-1 1. Insert the tabs on the tank cover into the slots on the vehicle, push until you hear it “click” into place. 2. Fit the front fender onto the front wheel assembly. 3. Insert the front fork into the hole on the front vehicle and out the hole on the tank cover.
  • Page 9 Attach the Handle Bar-2 1. Plug the sound unit connector on the handle bar into the connector on the vehicle body. 2. Fit the handle bar to the end of the front fork. 3. Line up the holes on the steering wheel with the holes on the steering column, insert the M5x35 machine screw.
  • Page 10 Attach the Face guard & Rear Number Plate Batteries Not Included, and refer to the battery information on page 2. 1. With a screwdriver remove the screw on the battery cover located in the center of the Face guard. 2. Remove the battery cover from the Face guard.

  • Page 11: Connect The Power Supply

    Connect the Power Supply 1. Using a scrwdriver to remove the seat. 2. Plug the red power connector into the red termianl on the battery. Replace the Seat. Use Your New Vehicle Sounds button: Press for sounds playing. Forward button: Press to move the vehicle forward.

  • Page 12: Troubleshooting Guide

    Troubleshooting Guide Possible Cause Solution Problem Vehicle does not run Battery low on power Recharge battery. Thermal fuse has tripped The fuse will reset automatically in 20 seconds. Check that the battery connectors are firmly plugged Battery connector or wires into each other.
  • Page 13 Charging • The POWER SWITCH must be turned in OFF position when charging. • Before the first use, you should charge the battery for 4-6 hours. Do not recharge the battery for more than 10 hours to avoid overheating the charger. •...
