Summary of Contents for Soniclean Varro

Page 1 Owners Manual www.sonicleanusa.com/varro...
Page 2: Introduction
Get Ready to Change the Way You Clean! Thank you for purchasing the Soniclean Varro Professional-Grade Steamer (Model #: VSS-1000). This premium Italian appliance allows you to clean, sanitize and deodorize virtually every surface in your home or business. Please carefully read this manual to understand how to safely and properly use this powerful and versatile appliance.
Page 3: Table Of Contents
Contents Topic Page Introduction ............................2 Who was Varro? ..........................4 What is Dry Steam? ........................... 5 Parts and Equipment ........................6 Important Safety Information ..................... 7-8 Technical Speciﬁcations ........................9 Understanding your Steamer ......................10 Getting Started - Display Screen ....................
Page 4: Who Was Varro
Rome. In 37 BCE, one of Ancient Rome’s greatest scholars named Marcus Terentius Varro predicted that: “...there are bred certain minute creatures which cannot be seen by the eyes, but which ﬂoat in the air and enter the body through the mouth and nose and cause serious diseases...”...
Page 5: What Is Dry Steam
For steam to be considered “dry steam”, the steam cannot contain more than 5% water by mass. The Soniclean Varro combines high heat with 7 bars of pressure, to produce dry steam that is up to 338°F with a dryness fraction greater than 0.95.
Page 6: Parts And Equipment
Parts & Equipment Your Varro Steamer includes the following parts and accessories: Steamer Hose Rectangular Brush Triangular Brush Detail Nozzle Extension Tubes Small Nylon Brush (30mm) Small Copper Brush (30mm) Medium Round Nylon Brush (60mm) Rectangular Pad Triangular Pad Reﬁll Bottle Boiler Key Thermoﬁber Cloths (3)
Page 7: Important Safety Information
TEST a small, hidden surface power off and unplug the appliance. to make sure the surface can be steamed. Please note that Soniclean is not liable for damage to personal Before adding water, connecting attachments, and property caused by improper use of this appliance.
Page 8 In case of damage turn off the appliance and never Make sure children never play with the appliance. attempt to repair it by yourself. Contact Soniclean for Not for space heating purposes. assistance.
Page 9: Technical Specifications
Technical Speciﬁcations Electrical Rating......... 110 - 120V AC - 50/60 Hz Power............ 1650 Watts Boiler Capacity ........0.58 gal. Reﬁll Tank Capacity ......0.55 gal. Working Temperature ....338 °F Working Pressure ......7 bar (101 psi) Maximum Pressure ......9 bar (130 psi)* Weight (without water) ....
Page 10: Understanding Your Steamer
Understanding Your Steamer Boiler tank cap Reﬁll tank cap Touch screen display Power cord winder Hose/Accessory port Connecting the Steam Hose To attach the steam hose to the steamer, lift up the protective cover on the Hose/Accessory Port (5) and insert the rectangular end of the steam hose into the port. To remove the steam hose, lift up the protective cover on the Hose/Accessory Port (5) and pull out the hose.
Page 11: Getting Started - Display Screen
Getting Started - Display Filling with Water Before connecting the power cord to the electrical outlet, make sure that the boiler cap on the underside of the steamer is tightened completely. Fill the reﬁll tank with TAP WATER* using the included Fig.
Page 12: Getting Started - Controlling The Steam
Getting Started - Controls Once your steamer is ﬁlled with water, turned on, and is at operating temperature, you can connect the hose to the machine. The handle on the steam hose allows you to select from three different power settings, control when the steam is released, and operate the safety locking feature. As a safety feature, the steam release trigger (B) will be locked by default.
Page 13: Using The Thermofiber Cloths
Using your ThermoFiber Cloths Your Soniclean Varro steamer includes (3) specially engineered, ultra-absorbent ThermoFiber steam cloths. While normal microﬁber cloths melt at around 140° F, these ThermoFiber cloths are designed to withstand temperatures of up to 340° F without losing their shape and absorbency properties.
Page 14: Cleaning Guide
Before steam cleaning, we recommend test cleaning an inconspicuous area to assess whether the selected steam power is too hot. Please note that Soniclean is not responsible for any damage to objects or surfaces caused by improper use of this appliance.
Page 15 Accessories Amount of steam Metal Stainless steel, anodized aluminum, and brass. LOW/MEDIUM STEAM *If the metal is painted or has a heat sensitive Depending on the size of the surface choose the detail nozzle or the triangular brush (then polish with the coating, use steamer ThermoFiber cloth) or the triangular brush with with caution.
Page 16 Accessories Amount of steam Glass LOW/MEDIUM STEAM The more dirt on the glass, the less distance between the point nozzle and the surface you need. Short distance means better cleaning with high temperature. Avoid direct contact of the surface with the point nozzle.
Page 17 Accessories Amount of steam Carpets You can clean and sanitize carpets and area rugs. Carpets and rugs may be made of various LOW STEAM Thoroughly vacuum the entire carpet before steam types of synthetic/natural cleaning. Check the resistance of colors and the adhesion by doing a test cleaning on small hidden fibers.
Page 18 Accessories Amount of steam Bathtubs, bidets, LOW STEAM shower trays, Clean larger surfaces with the medium nylon round toilets, and sinks. brush. Use the detail nozzle for the corners with or without attached brush. For detail cleaning, use the small nylon brush. Degreasing HIGH STEAM Drains...
Page 19: Descaling Instructions
Once the boiler has been drained, you are now ready to reﬁll your steamer with tap water and resume cleaning. IMPORTANT: Using a descaling solution that is not approved for use in the Soniclean Varro VSS-1000 steamer may cause irreparable damage to the machine and will void your machine’s warranty.
Page 20: Warranty Information
Product found by Soniclean to be defective in material or workmanship or refund the purchase price of the Product or replace the Product or a portion of same. Soniclean reserves the right to charge shipping and handling during the Initial Warranty Period. If the product is not repairable, a refurbished equivalent product, or a replacement equivalent product or a store gift certificate equivalent to the current value towards the purchase of a new product will be issued.
Page 21 The Purchaser understands that it shall strictly comply with the operation instructions and/or manual of operations provided by Soniclean in relation to the Product. FAILURE TO DO SO SHALL VOID THE WARRANTY AND RELEASE SONICLEAN FROM ANY WARRANTY AND LIABILITY WHATSOEVER.
Page 22 1.12 Soniclean may subcontract or assign performance of its Warranty obligations to third parties. 1.13 Soniclean is not responsible for any failures or delays in performing under the Warranty that are due to events outside Soniclean’s reasonable control. 1.14 The Warranty does not cover machines used for rental purposes.
Page 24 Illustrations may differ from actual product. We are constantly striving to improve our products; therefore the specifications contained herein are subject to change without notice. © 2021 Soniclean Soniclean is a registered trademark of Zenith Technologies, LLC. Rev. 1.0.0 PRINTED IN ITALY...

This manual is also suitable for:

Vss-1000
