DIGITAL VIDEO WIRELESS SYSTEM

DV009

INSTRUCTION MANUAL

Thank you for purchasing this product.

For proper usages and application, please read this

instruction manual carefully.

ver. 1.0

PRINTED IN KOREA

* The design and specifi cations of this product in order to improve its quality may be changed without notice.

Table of Contents

Need help?

Do you have a question about the DV009 and is the answer not in the manual?

Questions and answers

Summary of Contents for MTB Cameras DV009

Page 1 DIGITAL VIDEO WIRELESS SYSTEM DV009 INSTRUCTION MANUAL Thank you for purchasing this product. For proper usages and application, please read this instruction manual carefully. ver. 1.0 PRINTED IN KOREA * The design and specifi cations of this product in order to improve its quality may be changed without notice.
Page 2 CONTENTS SAFEGUARD INSTRUCTIONS -------------------------------------- 3 BOX CONTENTS ------------------------------------------------------- 5 FEATURES --------------------------------------------------------------- 5 FUNCTIONS ------------------------------------------------------------- 6 CONNECTING & INSTALLATION -------------------------------- 6 CLEANING & MAINTANANCE ----------------------------------- 8 SPECIFICATIONS ----------------------------------------------------- 8...
Page 3 SAFEGUARD INSTRUCTIONS DIGITAL VIDEO WIRELESS SYSTEM Please read the “Safety Rules” carefully before using this product. Following the safety rules prevents users from damages related with the misuse of the product. It is very important to follow these safety rules. We state “Caution” and “Warning”...
Page 4 WARNING Do not put the product in place where sudden temperature increasing and should use on optimum voltage, temperature and humidity --- It may cause to electronic shock or malfunction. Do not get product wet and operate with wet hands. --- It may cause to electronic shock or malfunction.
Page 5 FEATURES DIGITAL VIDEO WIRELESS SYSTEM • Black anodized aluminium housing with installation bracket • Fixed unit 2,4 GHz High power short antenna • Connections for 4-Pol Mini DIN • High Level operating system • Own DVWS ID-System • Waterprotected housing BOX CONTENTS DIGITAL VIDEO WIRELESS SYSTEM ** Before use this products, please check below contents.
Page 6 FUNCTIONS DIGITAL VIDEO WIRELESS SYSTEM With this digital video- and audio transmitting system, images and audio signals will be transmitted wirelessly from the rear-view camera to the monitor. The transmitter will be connected to power supply with 12/24V and the 4-POL MINI DIN screw-type adaptor is connected directly with the camera.
Page 7 ATTENTION : The transmission time of the picture from the camara to the monitor takes less than 200ms, so please take care while driving backwards. ** The surrounding temperature should be between -10˚C und 60˚C Monitor (Optional) Receiver (RX) 4-POL MINI DIN plug 12/24V DC (-) IN (BLACK) 12/24V DC (+) IN (RED) Camera (Optional) Transmitter (TX) 4-POL MINI DIN screw type socket...
Page 8 CLEANING & MAINTENANCE DIGITAL VIDEO WIRELESS SYSTEM Cleaning • - Disconect the modul from power supply - Cleaning with a clammy cloth Entering of contaminats • Never enter contaminats into the body, there could be a short circuit and the system could be broken.
