  • Page 1 CAXA0 Rugged Tablet User Manual...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safety Precautions and Usage Notes ............2 Regulatory Information ................5 Directive 2014/53/EU ..................... 6 Your Tablet ....................9 Package Contents ......................9 Tablet Overview ..................10 Front View ........................10 Right View ......................11 Left View ......................12 Rear View ......................

  • Page 4: Safety Precautions And Usage Notes

    CAXA0 Rugged Tablet User Manual Safety Precautions and Usage Notes To reduce the risk of injury, loss of life, electric shock, fire, malfunction, and damage to equipment or property, always observe the following safety guidelines: DANGER: Precautions on the Battery: Failure to comply with the following precautions may result in electrolyte leakage, generation of heat, ignition or rupture.
  • Page 5 Safety Precautions and Usage Notes  DO NOT expose bare skin to this product when handing this unit in extreme hot or cold environments. CAUTION:  When using in a hot or cold environment, some peripherals and battery packs may fail to work properly.
  • Page 6 CAXA0 Rugged Tablet User Manual Camera Notes： The camera's autofocus function may not perform as expected in the following circumstances.  The subject is very dark.  The subject lacks contrast (e.g. the sky, a white wall, etc.) or there is little contrast between the subject and the surroundings (e.g.

  • Page 7: Regulatory Information

    Regulatory Information Regulatory Information CAUTION: Do not operate this personal computer or handheld computer’s incorporated wireless WAN modem in the presence of flammable gases or fumes. Switch off the cellular terminal when you are near petrol stations, fuel depots, chemical plants or where blasting operations are in progress.

  • Page 8: Directive 2014/53/Eu

    Radio Equipment Directive, 2014/53/EU. Disregard all current statements in other publications that relate to the R&TTE Directive, as they no longer apply to your product. Hereby, Compal Electronics, INC., declares that the radio equipment types listed at the beginning of this document are in compliance with Directive 2014/53/EU.
  • Page 9 Regulatory Information The radio wave exposure guidelines use a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit for mobile devices is 2W/kg. Tests for SAR are conducted using standard operating positions with the device transmitting at its highest certified power level in all tested frequency bands.
  • Page 10 CAXA0 Rugged Tablet User Manual Compal Electronics, Inc. No. 581, Ruiguang Rd., Neihu District, Taipei City 11492, Taiwan, R.O.C Declaration of Conformity We, Compal Electronics, Inc., Address: No. 581, Ruiguang Rd., Neihu District, Taipei City 11492, Taiwan, R.O.C. declare under our sole responsibility that the below mentioned radio equipment type is in...

  • Page 11: Your Tablet

    CAXA0 Rugged Tablet User Manual Your Tablet Package Contents Ensure that all of the proper items are included with the tablet in the packaging. The items that should be included in the packaging are: Tablet Power Adapter Quick Start Guide...

  • Page 12: Tablet Overview

    Your Tablet Tablet Overview Front View The following illustration shows the front side of the system. Number Component Front-Facing Camera (2MP) Captures images and videos. Senses the ambient light in order to make adjustments Ambient Light Sensor to the brightness of the display. Microphone Captures audio.

  • Page 13: Right View

    CAXA0 Rugged Tablet User Manual Right View The following illustration shows the right side of the system. Number Component Power Button Turns the tablet or display on/off. SmartCard Reader (Optional) Reads SmartCards. Used to attach a carrying strap to the tablet.

  • Page 14: Left View

    Tablet Overview Left View The following illustration shows the left side of the system. Number Component Connects to headphones, speakers, microphones and Universal Audio Jack other audio output/input devices. Connects to video devices such as a display, television, HDMI Port or projector.

  • Page 15: Rear View

    CAXA0 Rugged Tablet User Manual Rear View The following illustration shows the rear side of the system. Number Component Covers the removable battery, optional SIM card, and Battery Compartment Cover SD card slots. Used to attach an optional holder to conveniently carry Hand-Holder Slot the tablet using a single hand.

  • Page 16: Top View

    Tablet Overview Top View The following illustration shows the top side of the system. Number Component Barcode Scanner (Optional) Scans barcodes/QR codes. RS-232 Port Receives and transmits data from/to other computers or data devices.

  • Page 17: Bottom View

    CAXA0 Rugged Tablet User Manual Bottom View The following illustration shows the bottom side of the system. Number Component Docking Connector Connects to the optional tablet dock.

  • Page 18: Getting Started

    Tablet Overview Getting Started LED Indicators The system status LEDs are located on the front of the system, they include LEDs for the following: power, and battery charging status. Power Indicator LED icon LED Behavior Description Solid Blue The power is on. The system is in Sleep mode or is powered off.

  • Page 19: Battery Charge Status Indicator

    CAXA0 Rugged Tablet User Manual Battery Charge Status Indicator When the tablet is equipped with a primary battery (main battery) and a secondary battery (bridge battery): LED icon LED Behavior Description Solid Green Both batteries are fully charged. Solid Amber Either one of the batteries is charging.

  • Page 20: Charging The Tablet

    Getting Started Charging the Tablet 1. Connect the power cord to the power adapter. 2. Connect the power adapter to the DC-In port of the tablet. 3. Plug the power supply into an electrical outlet. The battery charge LED lights amber when your tablet is getting charged.

  • Page 21: Turning On/Off The Display

    CAXA0 Rugged Tablet User Manual Turning On/Off the Display Press the power button when the system is on to turn off the display and put the system in standby mode. When the system is in standby mode, press the power button once to wake up the system and...

  • Page 22: Operating Your Tablet

    Getting Started Operating Your Tablet R232 Connection The RS-232 port located on the top of the tablet is an interface that allows for the transmission of data to and from the tablet and other data devices (such as a computer or infrastructure- related equipment) for various purposes including the transfer of information or sending commands.

  • Page 23: Smartcard Reader (Optional)

    CAXA0 Rugged Tablet User Manual SmartCard Reader (Optional) The optional SmartCard reader located on the right side of the tablet allows for the transmission of data, mainly for identification/authentication purposes, to and from the tablet and a smart card Insert a smart card into the reader to read/process/write information from/to the smart card.

  • Page 24: Nfc Sensor

    Operating Your Tablet NFC Sensor The NFC sensor located on the front of the tablet allows it to interact with other NFC-enabled devices or NFC cards/tags, such as smartphones or contactless smart cards. Tap an NFC-supported device or card/tag to the NFC logo, indicating the sensor area, to activate the NFC sensor, as shown in the image below.

  • Page 25: Fingerprint Reader

    CAXA0 Rugged Tablet User Manual Fingerprint Reader The fingerprint reader located on the front of the tablet allows for a quick, convenient and more secure way to log into the system by scanning your fingerprint instead of entering a password.

  • Page 26: Barcode Scanner (Optional)

    Operating Your Tablet Barcode Scanner (Optional) The optional barcode scanner located on the top of the tablet allows the tablet to retrieve information from bar codes when the barcode scanner button is pressed. 1. Open the application/software that you want to use to read the barcode data. NOTE: The application/software is not provided by the manufacturer and must be installed separately by the user.

  • Page 27: Entering The Bios Menu

    CAXA0 Rugged Tablet User Manual Entering the BIOS Menu BIOS (Basic Input / Output System) is a hardware configuration program installed in the tablet and initialized when the tablet is powered on. The BIOS is preset to optimal default settings for normal use, but in certain cases a user or technician might want to access the BIOS menu to change certain hardware settings for the tablet or to boot directly to a specific bootable device.

  • Page 28: Replacing The Battery

    Operating Your Tablet Replacing the Battery Battery Removal and Replacement The primary battery is a 7.2V / 3950mAh battery installed on all models under the battery compartment cover located on the rear of the tablet, which can be removed and replaced by the user.
  • Page 29 CAXA0 Rugged Tablet User Manual 5. To insert/replace the battery reverse the steps described above NOTE: Dispose of used batteries according to the local laws and regulations of your region.

  • Page 30: Specifications

    Operating Your Tablet Specifications ® ® Intel Celeron Processor N3350 Memory* 4GB / 8GB on-board LPDDR4 Storage* 128GB / 256GB M.2 SSD (Type 2242) Display 10.1" 1280 x 800 (HD) pixels, 500 nits  Gorilla ® Glass III touchscreen, supports 10 finger touch, and touch for PVC/latex gloves Pointing Device ...
  • Page 31 The HDMI port does not guarantee compatibility with all HDMI-compatible Note peripherals. Only for use with the CAXA0 dock. The RS232 port does not guarantee compatibility with all RS232-compatible peripherals. Battery performance features such as charge time and life span can vary according to the condition under which the computer and battery are used.
  • Page 32 FCC: Federal Communication Commission Interference Statement This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 33 the Specific Absorption Rate, or SAR. The SAR limit set by the FCC is 1.6W/kg. Tests for SAR are conducted using standard operating positions accepted by the FCC with the device transmitting at its highest certified power level in all tested frequency bands.
  • Page 34  La fonction de sélection de l'indicatif du pays est désactivée pour les produits commercialisés aux États-Unis et au Canada. Radiation Exposure Statement: The product comply with the Canada portable RF exposure limit set forth for an uncontrolled environment and are safe for intended operation as described in this manual.
  • Page 35 canaux; le gain maximal d’antenne permis pour les dispositifs utilisant les bandes 5250-5350 MHz et 5470-5725 MHz doit se conformer à la limite de p.i.r.e.; le gain maximal d’antenne permis (pour les dispositifs utilisant la bande 5725-5825 MHz) doit se conformer à la limite de p.i.r.e. spécifiée pour l’exploitation point à...
