firewood 7 Instructions For Use

7

IMPORTANT SAFETY INSTRUCTIONS

MISUSE CAN CAUSE INJURY AND PROPERTY DAMAGE!
Read instructions before use and only use vaporizer
according to instructions.
• Only use with High Drain Lithium
Ion 18650 cells that are rated for a
minimum of 20 Amps continuous
discharge current and have a
nominal voltage of 3.7V. See the
Firewood website for specific
recommendations.
• Never use a battery that has been
damaged or that has a damaged
plastic covering.
• Only use a battery charger that is
intended for use with 18650 cells
and has over-charge circuit
protections.
• Remove battery when traveling by
air or sending by mail.
• Do not use near water or if wet.
• The oven and lid can get HOT
while in use. Please use caution
and allow a few minutes for cooling
before handling.

Load Battery:

-
Remove Lid Insert the negative terminal first
Push down and into place
Vaporizer will not work if the
battery is inserted backwards.
Please ensure negative end
goes in first!

Load Oven:

Fill oven no higher
than the air intake
holes near the top Use end of lid to
edge of the oven evenly pack down the
contents

Button Summary (details for each function below):

+ Click:
1x Quick
Hold
1x Quick & Hold
2x Quick & Hold
3x Quick & Hold
2x Quick
3x Quick
4x Quick

Check Battery Level:

Click the button 1 time
quickly. The vaporizer will
buzz between 1 and 5
times to indicate the
battery level. 3 sets of 3
buzzes indicates the
charge level is too low to
use (<3.5V) Recharge immediately to prevent battery damage! 3 sets
of 4 buzzes indicates the charge level is too high (>4.3V), please
Replace lid
check charger!
Turn Heater On & Draw:
Hold the button down. The vaporizer will buzz quickly 1, 2, or 3 times
to indicate the current preset as the heater starts to heat up. When it
is close to the preset temperature it will buzz 1 time again to indicate
that the vaporizer is ready for a draw. Continue to hold the button
throughout the draw as the vaporizer will hold the temperature at the
preset level. The heater turns off whenever the button is released and
will buzz once shortly thereafter to indicate shutdown.
Function:
Check battery level
Turn heater on
Change to preset 1 & turn heater on
Change to preset 2 & turn heater on
Change to preset 3 & turn heater on
Check Current Preset

Check temperature for current preset

Set Temperature For Current Preset
Buzzes Battery Level
5 High (above 4.1V)
4 Medium-High (3.95V - 4.1V)
3 Medium (3.8V – 3.95V)
2 Medium-Low (3.7V – 3.8V)
1 Low (below 3.7V)
