Non-Contact Countdown Timer Model TM-29
Thank you for purchasing the Non-contact countdown timer model TM-29.
Read this manual thoroughly before using and keep it in a safe place for your future references.
Features
Model TM-29 timer does not have a start/stop button. You can start the timer and stop the alarm by
only putting your hand over the sensor by adopting the Non-contact sensor. So this timer is
hygienic safety.
Names of Components
LCD Display
(Running time is displayed)
Setting Button (minute/分)
Setting Button (second/秒)
Setting Button (sound/音)
How to Use
Remove the battery insulating tape before using the timer for the first time.
1) Setting the alarm sound
Press the Sound setting button on the back of the unit to select the alarm sound. After selecting a
sound, press the Minute or Second setting button to set it and return to the time display.
Press the
Sound (音)
button
*
: Beep
Alarm sound 1
* If no button is pressed for 30 seconds while setting the alarm sound, the sound currently selected is
set and the unit returns to the timer display.
Instruction Manual
<Front View>
Sensor: Non-contact sensor senses the hand and timer starts.
Sensitivity is about 3cm vertically from sensor.
<Rear View>
Battery Lid
A
larm sound 1
Press the
Sound (音)
button
: Beep Beep
Alarm sound 2
Battery Lid fixing screws
Alarm sound 2
: Beep Beep Beep Beep Beep
Alarm sound 3
1
LED
lamp
Hooking hole
Magnet
Hole for buzzer sound
Alarm sound 3
Press the
Sound (音)
button
Advertisement
Related Manuals for SATO TM-29
Summary of Contents for SATO TM-29
- Page 1 Read this manual thoroughly before using and keep it in a safe place for your future references. Features Model TM-29 timer does not have a start/stop button. You can start the timer and stop the alarm by only putting your hand over the sensor by adopting the Non-contact sensor. So this timer is hygienic safety.
- Page 2 2) Setting the countdown time Use the Minute and Second setting buttons to set the countdown time. - It can be set from 1 second to 99 minutes and 59 seconds in increments of 1 second. - Holding down the Minute or Second button will quickly change the value. - The non-contact sensor is designed not to react for five seconds after pressing each button (the "minute"...
- Page 3 Replacing Batteries When the batteries are insufficient, the following phenomenon occurs. Replace batteries immediately. ⚫ The display dims. ⚫ The volume of alarm sound gets smaller or buzzer does not sound at all. ⚫ Sensor does not work (the timer does not start even if put a hand over the sensor) (1) Rotate two screws on the battery lid counterclockwise with a screwdriver until these are free.
- Page 4 Cat. No. : 1707-30 Name : Non-Contact Countdown Timer Model : TM-29 Setting countdown time : Between 1 sec. to 99 min. 59 sec. by 1 sec. : “AAA” size manganese battery x 3 pcs. Power Requirements Battery life : Approx. one year (in use of 50 times per day)
