AGT 210 Automatic Gate
User's Manual
Issue Date: 2015.06
Parktron Technology Co., Ltd.
© 2014 - 2024 Parktron Technology Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AGT 210 and is the answer not in the manual?

Questions and answers

Summary of Contents for Parktron AGT 210

  • Page 1 AGT 210 Automatic Gate User's Manual Issue Date: 2015.06 Parktron Technology Co., Ltd. © 2014 - 2024 Parktron Technology Ltd.

  • Page 2: Table Of Contents

    1) Products outline Table The AGT210 is a barrier gate product series from Parktron. We adopt the most reliable barrier motor from an OEM barrier manufacturer in China, and with our own Production Outline cabinet design and built to match our parking system 2)Production Series devices.
  • Page 3 Notice: The "Boom Height" means height from the boom holding point to the ground © 2014 - 2024 Parktron Technology Ltd. © 2014 - 2024 Parktron Technology Ltd.
  • Page 4 Electric cabinet working temperature -20°C ~ +75°C Buffer spring Rating voltage 220/110V±10%,50/60Hz Rating power Adjust screw 100W ≦ 90% Relative humidity ≧ 30m Remote control distance Net weight 65kg © 2014 - 2024 Parktron Technology Ltd. © 2014 - 2024 Parktron Technology Ltd.

  • Page 5: Installation For Mechanism Part

    (refer to the Fig.4) Unlock Lock Barrier fix at left side of the gate Fig.2 The barrier gate fix at the left hand side of the access Fig.4 © 2014 - 2024 Parktron Technology Ltd. © 2014 - 2024 Parktron Technology Ltd.
  • Page 6 Adjust the adjusting screws of the balance spring (Attention: the spring tension could not be too hard.) anticlockwise to diminish the tension of the spring. © 2014 - 2024 Parktron Technology Ltd. © 2014 - 2024 Parktron Technology Ltd.
  • Page 7 Link pole pull down the boom by hand lightly.(Refer to Fig.4) Balance crank Link hole 1 Sway up and down Fig.9.2 Link hole 2 Fig.8 © 2014 - 2024 Parktron Technology Ltd. © 2014 - 2024 Parktron Technology Ltd.

  • Page 8: Springs Selection, Installation And Adjustment 1

    3 inbuilt springs covered with PVC pipe are inserted into the 6.5mm compressed balance spring and separated with rubber cushion. Adjusted nut Fig.10 © 2014 - 2024 Parktron Technology Ltd. © 2014 - 2024 Parktron Technology Ltd.

  • Page 9: Installation And Connections Of The Electric Part 1

    If the electrical connections in the user manual differ from (D-c) In the downtrend area, the boom will be fallen down to this diagram, please reference this diagram. horizontal position because of the gravity. Fig.12 © 2014 - 2024 Parktron Technology Ltd. © 2014 - 2024 Parktron Technology Ltd.
  • Page 10 The software please refer to the instruction in the disk.(Optional device) © 2014 - 2024 Parktron Technology Ltd. © 2014 - 2024 Parktron Technology Ltd.

  • Page 11: Packing List 1

    Please check the capacitance is correctly fixed or not. For fixing the supporting b. Please check the sensor is right inserted or not. Expansion nut pole © 2014 - 2024 Parktron Technology Ltd. © 2014 - 2024 Parktron Technology Ltd.

  • Page 12: Service Items 1

    When the laser obstacle moves into the slot and the green light is on, the rising limit will work and the boom will stand straight. Check the vertical angle between the boom and the horizontal position and adjust. © 2014 - 2024 Parktron Technology Ltd. © 2014 - 2024 Parktron Technology Ltd.
  • Page 13 Check the horizontal angle between the boom and the horizontal position and adjust the laser obstacle, to make the boom be perfectly horizontal. © 2014 - 2024 Parktron Technology Ltd. © 2014 - 2024 Parktron Technology Ltd.
