AOLBEA P100 User Manual

AOLBEA P100 User Manual

Body worn camera

Advertisement

AOLBEA
Model: P100
Body Worn Camera
User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P100 and is the answer not in the manual?

Questions and answers

Chad Duncan
May 31, 2025

how do I save video from the body camera to my PC

1 comments:
Mr. Anderson
May 31, 2025

To save video from the AOLBEA P100 body camera to your PC, connect the camera to the PC using the USB cable. If your PC has a USB-C port (such as on a Mac), use a USB-C to USB-A adapter. Then, download the videos and pictures directly from the camera to the PC.

This answer is automatically generated

Jorge Diaz
January 28, 2025

How to delete videos and photos

1 comments:
Mr. Anderson
May 14, 2025

To delete videos and photos on the AOLBEA P100, you must connect the device to a computer. Files cannot be deleted directly on the device. Alternatively, you can format the SD card by following these steps:

1. Long press until you hear the second click.
2. Short press, then short press again.
3. Long press until a pop-up box says "The SD card Format is processing."
4. Wait for the process to complete. All files will be deleted.

Note: Back up important data before formatting.

This answer is automatically generated

Veronica
January 30, 2025

How to download the videos and as well how to delete them.

Summary of Contents for AOLBEA P100

  • Page 1 AOLBEA Model: P100 Body Worn Camera User Manual...
  • Page 2 Foreword>> Thank you for purchasing this P100 police body worn camera made by JWKG Co., Ltd. N This instruction manual contains information on how to operate your dashcam. N Before using your body camera, we recommend that you read through this manual to ensure correct usage.
  • Page 3: For Safety

    1. Warranty We provide customers with a warranty of 12 MONTHS from the date of purchase. 2. Support For any inquires with Aolbea products, please feel free to contact us, we will respond within 24 hours. E-mail: jwdkg@outlook.com Or find us through "Account service" → "Order Information" → "Contact Seller"...
  • Page 4 Body-Worn Camera Overview>> 11 12 FRONT Back Left Right 1. Photosensitive 11. Left/Up Button 19. Photo Button 2. HD Camera 12. Right/Down Button 20. USB interfere Port 3. Microphone 13. OK/Preview Button 21. Power Button 4. Flashlight 14. Walkie-Talkie(optional) 22. Status Indicator Light 5.
  • Page 5: Quick Start Operation

    Quick Start Operation>> Charge Camera Lift up the USB cover and plug the power cord into the camera's USB jack. Camera status LED shows solid BLUE while charging and automatically turns off when fully charged. IMPORTANT: • Fully charge your camera before the first operation with the provided power cord. •...
  • Page 6: Screen On/Off

    Power off Long press for 3 seconds to turn off the camera. Camera vibrates, emits a tone and the Camera Status LED turns Off. Screen On/Off When the camera is powered on, press to turn the screen off. To turn it back on, simply press again.
  • Page 7 Quick Video Recording Press and hold the Button while the camera is off. The camera will vibrate to confirm the action and automatically turn on and start video recording. Tagging important files While recording video you can tag an important file by pressing the .
  • Page 8: Audio Recording

    Audio Recording In Standby Mode, short press to record a audio file, press again to stop recording.Camera Record LED slow flashes Yellow. Preview & Playback When the device is powered on,press to enter file.Press select the files(video file,audio file or photo file),press to enter the files.
  • Page 9: Silent Mode

    Silent Mode When silent mode is enabled, all LEDs and tones are turned Off. Vibration is the only source of notification. Turn Silent Mode On You can turn it on/off in the settings Here are the steps When the camera is on, short press the button, enter the menu, press button select press...
  • Page 10 In Standby Mode, press button to enter Menus, and go to SETUP, find “IR CUT” in 1) Manual : Long press to turn on/off Infrared Light. 2) Auto : At night or in the dark, when photoresistor senses the low-light environment, Infrared Light will be turned on/off automatically.
  • Page 11 Alarm Long press to turn on, the camera will emit a continuous siren and flash the LED light; long press again to turn off. Reset Occasionally, you may need to perform a hardware reset when the camera stops responding or if it appears to be “frozen”or unresponsive.
  • Page 12: Battery Level

    Note: All data will be deleted. Before formatting your camera, please remember to backup your important data on your other devices. Walkie-talkie(Optional) The multi-functional interface can be connected with an intercom system(The walkie-talkie accessory needs to be purchased separately); press and hold button, dialogues will be sent;...
  • Page 13: Video Menu

    Settings>> During the Standby Mode, short press enter the setting menu. Video Menu 1280x720 30P 16:9/ 2560x1440 30P 16:9/ 2304x1296 30P 16:9/ 2560x1080 30P 21:9/ Video resolution 1920x1080 45P 16:9/ 1920X1080 30P 16:9/ 1920X1080 30P 16:9/ 1440x1080 30P 16:9/1280x720 60P 16:9/ 1280x720 30P 16:9/ 848x480 30P 16:9 Quality High/Medium/low Off/On...
  • Page 14: Photo Menu

    OFF/On Delay recording works very similarly to pre-recording, only this option will Record Delay continue recording for a set number of seconds after the button has been pressed. Off/On Now, when the button is pressed, the video recording will start as usual. Motion Detect However, if no movements are detected for 30 seconds, the camera will stop recording to save space and battery life.
  • Page 15: System Setting

    System Setting PAL/NTSC System Set the camera Time & Date (The initial Date & Time password is 000000) 25%~100% LCD Brightness Adjust the LCD Screen Brightness The device will shut down automatically at Auto Power Off the specified time. (Off/1 min/2 min/3 min/5 min) Selects Off to keep the LCD on, or sets the timer for the LCD to turn off automatically ( 5 SEC/30 SEC/1 min/3 min ).
  • Page 16 Set the length of each video clip for a Video File continuous recording. Duration (1min/2mins/3mins/5mins/10mins). On/Off When the storage space is full, it can automatically overwrite the unprotected Loop Recording files. If you turn it off,the camera will stop recording when the sd card is full. Off/On When silent mode is enabled, all Slient Mode...
  • Page 17 Change your password with the default password 000000. Use the Left and Right buttons to make selections. Change Password Press to save and exit. You can enter up to 6 characters for the User ID (default passcode is 000000). Change User ID Press to select.
