Summary of Contents for DDS DIR-300V
- Page 1 DIGITAL REMOTE CONTROL EXTENDER MODEL :DIR-300V OWNERS MANUAL...
- Page 2 LOCATION OF CONTROLS Transmitter Side Receiver Side DC Power DC Power IR Probe Transmitter and Receiver Front Infrared Remote Control Antenna Remote Control Indicators & IR Transmitter/Receiver Accessories DC 12 V Infrared Extender X 3 AC 120V 1,1.5,2m in length Adaptor x2...
- Page 3 To avoid electric shock, do not open the units. The DIR-300V contains no user serviceable parts. Doing so will void the warranty. Use only the power supply provided with the DIR-300V Do not overload wall outlets or extension cords. If you are experiencing difficulty with this product, do not attempt to service it yourself.
- Page 4 Product Description The DIR-300V Wireless Infrared Remote Control Extender enables you to extend the range of your present Infrared Remote Control so that you can operate VCRs, stereos, Cable Converter, Satellite receivers, etc., virtually anywhere in the home. Applications The remote operation of electronics products that utilize IR (Infrared) remote control technology such as: ‧Satellite Receivers...
- Page 5 APPLICATION DIAGRAM IR Signal 1. Stereo system with remote control: RF Signal DIR-300V Receiver Wire to Extension Speaker Probe Stereo Wall IR Remote Control DIR-300V Transmitter 2. DSS / Satellite Receiver with remote control: 2nd TV DSS or Satellite Receiver...
- Page 6 Installation & Operation Guide Receiver Picture 1 Picture 2 Working with extender probe Antenna Power Adaptor (Using IR ) Make sure the IR probe is affixed toward IR sensor receiving Window with proper position Keep Vertica (within 0.5M and working angles +/- 15°). Picture 3 Picture 4 Working without...
- Page 7 Transmitter Picture 6 Picture 5 Working Angle not more than +/- 15° Antenna Power Adaptor Keep Vertical Remote Control Picture 7 Antenna Distance Not less than 0.3M and not more than 7M Working Angle not more than +/- 15°...
- Page 8 Care and Maintenance Keep the DIR-300V Remote Extender dry. If it gets wet, wipe it dry immediately. Use and store the DIR-300V only in normal temperature environments. Extreme temperature can shorten the life of electronic devices Handle the DIR-300V gently and carefully. Dropping it can damage the circuit board and can cause it to work improperly.
