Model 6103
OZONE TRANSFER STANDARD
MULTI-GAS CALIBRATOR
User's Guide
Rev 4
12SEPT2003
For S/W Rev 6103-1.35-XX
Environics, Inc.
69 Industrial Park Road East
Tolland, CT 06084-2805 USA
Phone (860) 872-1111
Fax (860) 870-9333
www.environics.com
SEPTEMBER 2003

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6103 and is the answer not in the manual?

Questions and answers

Related Manuals for Environics 6103

Summary of Contents for Environics 6103

  • Page 1 Model 6103 OZONE TRANSFER STANDARD MULTI-GAS CALIBRATOR User’s Guide Rev 4 12SEPT2003 For S/W Rev 6103-1.35-XX Environics, Inc. 69 Industrial Park Road East Tolland, CT 06084-2805 USA Phone (860) 872-1111 Fax (860) 870-9333 www.environics.com SEPTEMBER 2003...
  • Page 2 WARRANTY Environics, Inc. warrants this product to be free from defects in material and workmanship for a period of one year from the date of shipment. Environics warrants the following expendable items for 30 days from the date of shipment: fuses, lamps, batteries, scrubbers/filters.
  • Page 3 6103 User’s manual changes Manual Software Manual Revision Revision Release Enhancements Date 1.31-03 10/12/2002 Initial release 1.33-01 4/8/2003 Added manual change log page, added UL listing requirements to preface, Adjusted index, Pages 6 and 13 - Changed PORTS Mode to GASES Mode.
  • Page 4 The Model 6103 is a 6100 Multi-Gas Calibrator with an added photometer. The addition of the photometer allows the 6103 to be used as an Ozone Transfer standard for performing ozone calibration. Although the Model 6103 is very easy to operate, we strongly suggest you read this User’s Guide portion of this document completely prior to operating the...

  • Page 5: Table Of Contents

    Status input mode Status output mode Series 101 status emulation Analog outputs 34-39 Remote mode, RS232 (REMOTE) 40,41 Automatic photometer pump control ( * ) = As seen on display in one of three main menus SERIES 6103 USER’S GUIDE SEPTEMBER 2003...
  • Page 6 LIST OF ILLUSTRATIONS ILLUSTRATION TITLE PAGE # Front panel layout Rear panel layout Photometer diagnostics Ozone generator diagnostics Photometer mode display options Piping and instrument diagram SERIES 6103 USER’S GUIDE SEPTEMBER 2003...
  • Page 7 Output Gas Concentration P&ID Piping and Instrument Diagram Parts Per Million PSIA Pounds Per Square Inch Absolute PSIG Pounds Per Square Inch Gauge SCCM Standard Cubic Centimeters per Minute Volts, Alternating Current Volts, Direct Current SERIES 6103 USER’S GUIDE SEPTEMBER 2003...
  • Page 8 ( ) Permanently Connected; (X) Other Cord Connected. Overall size: 17”x7”x15” Weight: 27 lbs. Ventilation requirements: Do not cover or block the ventilation holes in the top cover or fan filter on the rear panel. SERIES 6103 USER’S GUIDE SEPTEMBER 2003...
  • Page 9 Model 6103 with an incorrect line voltage may damage the instrument and could cause personal injury. The standard supplied 115 volt power cord should be plugged into the rear panel power entry module of the Model 6103, the other end should then be plugged into a properly grounded outlet. IMPORTANT: Before connecting or disconnecting any cables, wiring harnesses or other sources of potential electrical impulse, be sure the unit is powered OFF.
  • Page 10 CAUTION (Refer to accompanying documents). ISO 3864, No. B.3.1 Refer to specific WARNINGs and CAUTIONs in Operating Manual. IEC 417, No. 5019 PROTECTIVE CONDUCTOR TERMINAL IEC 417, No. 5007 ON (SUPPLY) IEC 417, No. 5008 OFF (SUPPLY) SERIES 6103 USER’S GUIDE SEPTEMBER 2003...

  • Page 11: Unpacking And Inspecting The System

    Any damage to the shipping case should be noted and immediately reported to the freight carrier. Report any damage to the Model 6103 to the Environics home office or your local Environics distributor. Place the unit at the desired operating location where there is easy access to both the front and rear panels of the unit.

  • Page 12: System Layout

    Each time the menu key is pressed, the menu will advance to the next menu (if applicable). The nine function modes are described in detail in the operating mode Summary and system operation sections of this User’s Guide SERIES 6103 USER'S GUIDE - 2 - SEPTEMBER 2003...
  • Page 13 FRONT PANEL LYOUT (CONTINUED) FRONT PANEL LAYOUT SERIES 6103 USER'S GUIDE - 3 - SEPTEMBER 2003...
  • Page 14 The exhaust port vents the ozone-containing sample once it has been analyzed by the photometer system RS-232 PORTS Two RS-232 serial ports are supplied for connection to a serial terminal or for remote communications. SERIES 6103 USER'S GUIDE - 4 - SEPTEMBER 2003...

  • Page 15: Rear Panel Layout

    REAR PANEL LAYOUT (CONTINUED) STATUS INPUT/OUTPUT The status outputs allow the Model 6103 to signal external devices when certain operating events occur. The Status inputs allow external devices to initiate various system functions. ANALOG OUTPUT Two analog output signals are supplied. Currently only analog channel one is active.

  • Page 16: Operating Mode Summary

    If ozone is required in this mix, the ozone concentration is also entered in this mode. The Model 6103 software then translates these output concentrations into gas flow rates and, using the dilution flow controller (MFC1), proceeds to dilute the span gas to the defined OGC, with or without ozone.
  • Page 17 This mode displays the system model number, software version and serial number. NOTE: A detailed description of each mode, outlined in this section, appears in the system operation section of this manual. Mode that is under development is the Program mode. SERIES 6103 USER'S GUIDE - 7 - SEPTEMBER 2003...

  • Page 18: Power And Gas Connections

    POWER AND GAS CONNECTIONS After the Model 6103 is unpacked and inspected, the User should connect the power and appropriate gas sources to the gas inlet ports on the rear panel. POWER CONNECTION WARNING OPERATING THE MODEL 6103 AT AN INCORRECT LINE VOLTAGE WILL DAMAGE THE INSTRUMENT AND VOID THE MANUFACTURER’S WARRANTY.

  • Page 19: Gas Connections

    SAMPLE IN port as possible. Also, it is important to supply the sample port with at least 3 SLPM of a sample containing ozone. The 6103 internal photometer will draw 2 SLPM from this sample and 1 SLPM will exhaust through the external vent.
  • Page 20 Turn the compression fittings with a wrench following the fitting manufacturer’s procedure for compression tube connections. 1. On the rear of the Model 6103, connect a source of zero air, at a pressure of 20 to 25 PSIG (30 PSIG MAX.), to PORT 1 (dilution gas port). Connect all span gases to PORTS 2 through 5 (span gas ports) at a pressure between 15 and 25 PSIG.

  • Page 21: System Operation

    The SPACE function key is used to enter a blank space. The CLEAR function key will clear all data entered. The DONE function key will complete the entry of data. SERIES 6103 USER'S GUIDE - 11 - SEPTEMBER 2003...

  • Page 22: Main Screen (Ready)

    MAIN SCREEN (READY) The Model 6103 was designed with emphasis on simplicity and ease of operation. The system’s menu-driven software guides the User through all operating routines. After the system has powered up, the user will see the READY screen...

  • Page 23: Gas Setup Mode (Gases)

    EDIT. The row is identified by the cursor line under the first letter/number in the GAS column. The next screen to appear is: GAS: (name) CONC: (XXXXX ppm) PORT: SPACE CLEAR SERIES 6103 USER'S GUIDE - 13 - SEPTEMBER 2003...
  • Page 24 When all the gases have been named, the concentrations entered and the port identified, press the function key under the word EXIT to bring back to the main menu. SERIES 6103 USER'S GUIDE - 14 - SEPTEMBER 2003...

  • Page 25: Preferences Mode (Prefs)

    03 PHO FEEDBK line, and press the ENTER key. ENB – Allows control of the photometer in FLOW and CONC modes. DIS – Will not allow the photometer to correct in the FLOW or CONC mode. SERIES 6103 USER'S GUIDE - 15 - SEPTEMBER 2003...

  • Page 26: Status Input Variables

    Using the up and down arrow keys, move the pointer cursor down to the line that reads ADJUST CONTRAST and press the ENTER key. The following screen appears: ADJUST CONTRAST CONTRAST = ↑/↓ TO CHANGE DONE SERIES 6103 USER'S GUIDE - 16 - SEPTEMBER 2003...

  • Page 27: Setting Powerup Mode

    READY is the default power up setting. ANALOG OUT SETUP The 6103 has two analog output channels that represent the amount of ozone being read. Each channel is independently configurable to represent 0-1 PPM. From the PREFS menu, move the cursor down to ANALOG OUT SETUP and press ENTER.

  • Page 28: Concentration Mode (Conc)

    Gas Phase Titration (GPT), the chemical reaction between specific gases resulting in the creation of one or more new gases, is performed when the Model 6103 is in the Concentration Mode function. A thorough description of GPT is included later in this section.
  • Page 29 The screen will return to the original data entry screen for the Concentration Mode. When done using the Concentration Mode, press the MENU key and then the EXIT function key to return to the main menu. SERIES 6103 USER'S GUIDE - 19 - SEPTEMBER 2003...
  • Page 30 = sample and reference intensity of the photometer lamp O3 = measured ozone concentration P = photometer gas pressure LT = photometer lamp temperature T = photometer gas temperature F = photometer flow rate PHOTOMETER DIAGNOISTICS SERIES 6103 USER'S GUIDE - 20 - SEPTEMBER 2003...
  • Page 31 The main purpose of the LOCKED setting is for performing Gas Phase Titration of NO and Ozone. Refer to the Gas Phase Titration section for more information. SERIES 6103 USER'S GUIDE - 21 - SEPTEMBER 2003...
  • Page 32 (2) Enter 1-99 for the LOAD REGISTER> # (3) Press ENTER to accept. Enter is not necessary if entering a 2 digit register. (4) Press start to activate the blend routine. SERIES 6103 USER'S GUIDE - 22 - SEPTEMBER 2003...

  • Page 33: Flow Mode (Flow)

    When satisfied with the entries, press the START function key. The gases will begin to flow with or without ozone if specified. The photometer pump will start automatically. Refer to section titled Automatic photometer pump control for more details. SERIES 6103 USER'S GUIDE - 23 - SEPTEMBER 2003...

  • Page 34: Verify Mfcs Individually

    This will isolate any leaking that may occur back out through the photometer bench; refer to P&ID on the last page of this manual. Refer to the section titled Automatic photometer pump control for more details. SERIES 6103 USER'S GUIDE - 24 - SEPTEMBER 2003...

  • Page 35: Ozone Generator Operation

    Nox calibration. Be sure ozone closed-loop control is enabled (from the READY mode, select PREFS, Ozone Setup, 03 PHO FEEDBK = ENB). Refer to the PREFERENCES section for details. SERIES 6103 USER'S GUIDE - 25 - SEPTEMBER 2003...

  • Page 36: Gas Phase Titration

    • It is manually changed back to OFF or ON • The STOP key is pressed • The Ozone level is changed to 0.0 and UPDATE is pressed. • The instrument is powered off. SERIES 6103 USER'S GUIDE - 26 - SEPTEMBER 2003...

  • Page 37: Photometer Mode (Photo)

    = sample and reference intensity of the photometer lamp O3 = Measured ozone concentration P = Photometer gas pressure LT = Photometer lamp temperature T = Photometer gas temperature F = Photometer flow rate PHOTOMETER MODE DISPLAY OPTIONS SERIES 6103 USER'S GUIDE - 27 - SEPTEMBER 2003...

  • Page 38: System Mode (System)

    SCCM. Three SCCM is the maximum leak rate allowed on a new system. LEAK TEST MODE The 6103 has an automated Leak Test function, to determine if the system has any inboard/outboard leaks. To run the Leak Test: 1.
  • Page 39 Do not apply any voltage to the status input pins, as this will result in damage to the instrument The Status Input feature allows for different methods of controlling the 6103. The various input modes are broken down into 2 categories:...
  • Page 40 For example, if inputs #2 and # 4 were active, their associated values are 2 and 8. Therefore, the group value = 2 + 8 = 10, so CONC mode #10 will be run. SERIES 6103 USER'S GUIDE - 30 - SEPTEMBER 2003...
  • Page 41 To set the STATUS INPUT mode, press MENU until the PREFS hotkey is displayed. Select PREFS. Scroll down to STATUS IN MODE. Press ENTER. Enter the desired "mode" value. Press EXIT twice. SERIES 6103 USER'S GUIDE - 31 - SEPTEMBER 2003...

  • Page 42: Status Output Mode

    The Status Outputs operation is defined by the table below: OUTPUT INDICATION MFC 1 is operating MFC 2 is operating None SERIES 6103 USER'S GUIDE - 32 - SEPTEMBER 2003...

  • Page 43: Status Input Mode

    SERIES 101 (HOLLAND) EMULATION The 6103 has the capability to emulate the operation of the Environics Series 101 Calibrator. To do so, the SYSTEM PREFERENCES must be set up as shown below. Refer to the OZONE PREBURN OPERATION and STATUS INPUT CONTROL OPTIONS sections for instructions on how to change these settings.
  • Page 44 ASCII codes: <CR> Carriage Return (ASCII Code 0x0D) This character is ignored. <LF> Linefeed (ASCII Code 0x0A) This is used to indicate the end of a command. SERIES 6103 USER'S GUIDE - 34 - SEPTEMBER 2003...
  • Page 45 ERROR RETURNED If the command received contains errors, or cannot be performed by the instrument, an error code will be returned. The error message is formatted as: RESPONSE: ERR(error code)<CR><LF> EXAMPLE: ERR12<CR><LF> SERIES 6103 USER'S GUIDE - 35 - SEPTEMBER 2003...
  • Page 46 (OGC) for the current span gas. CONC GAS ACTUAL ? Read the actual OGC for the current span gas. CONC UPDATE Start running CONC mode with the current settings. CONC STOP Stop running CONC mode. SERIES 6103 USER'S GUIDE - 36 - SEPTEMBER 2003...

  • Page 47: Remote Mode, Rs232 (Remote)

    This operates the same as the PHOTO mode available from the main menu. PHOTO STOP Take system out of PHOTO mode; refer to page 41. SERIES 6103 USER'S GUIDE - 37 - SEPTEMBER 2003...
  • Page 48 The voltage remains locked at its current level. xxxx = OFF : The ozone generator is not controlled by the photometer and relies solely on its calibration data. SERIES 6103 USER'S GUIDE - 38 - SEPTEMBER 2003...
  • Page 49 In CONC or FLOW mode, Ozone value is out of range. VALUE OUT OF RANGE Specified value is out of range. GAS # OUT OF RANGE Specified gas number must be between 2 and 20 SERIES 6103 USER'S GUIDE - 39 - SEPTEMBER 2003...

  • Page 50: Automatic Photometer Pump Control

    PHOTO mode. For troubleshooting purposes, or other reasons, they can be deactivated while in the PHOTO mode by pressing the ENTER key. Pressing the ENTER key again will turn them on. SERIES 6103 USER'S GUIDE - 40 - SEPTEMBER 2003...
  • Page 51 V1 for external ozone sampling. If the user is controlling the system remotely and wishes to turn the switching solenoid and photometer pump off, a PHOTO STOP command must follow every CONC or FLOW update command. SERIES 6103 USER'S GUIDE - 41 - SEPTEMBER 2003...
  • Page 52 SERIES 6103 USER'S GUIDE - 42 - SEPTEMBER 2003...
