Summary of Contents for All Security Equipment FAS-HUL1200LSDM
- Page 1 FAS-HUL1200LSDM Magnetic Lock Manual...
- Page 2 ----------------------------------------------------------------- Magnetic Lock 1200 lbs. Specification Size(mm) Voltag e Holdlng Force LockSlgnal DoorSlgnal Model Time Current Door 12V/500mA±10% Single door DC12V(Default); 350kg(800Lbs) Single Door 260Lx54. 7Wx29.6H magnetic lock DC24V(Order) 24V/250mA±10% Single door magnetic lock DC12V(Default); 12V/500mA±10% 350kg(800Lbs) Single Door 260Lx54. 7Wx29.6H NO/NC/COM with signal DC24V(Order)
- Page 3 Template Door Frame Door Template T e mplat e leaf Door leaf Close the door first, then place Mark screw positions of armature Fold the plate to 90 the upper side of template on plate and magnetic lock on door °...
- Page 4 Bracket Installation Different brackets are available according to different types of doors. For example, narrow door, frameless glass door and inward opening door. L Bracket When the door frame thickness is less than 42mm, L bracket is needed. Single Door Magnetic Lock Bracket Double Door Magnetic Lock Bracket LC Bracket LC Bracket one-piece design,wires are mortised.no damage ori wires...
- Page 5 Circuit Board Diagram A.12VDC Input: B.24VDC Input: Connect the positive(+)lead from a 12VDC power Connect the positive(+}lead from a 24VDC power source to V +. source to V +. Connect the ground(-)lead from a 24VDC power Connect the ground(-)lead from a 12VDC power source to V -.
