Keyboard

USING THE KEYBOARD

Your Fujitsu LifeBook notebook has an integral 82-key
keyboard. The keys perform all the standard functions of
a 101-key keyboard, including the Windows key and
other special function keys. This section describes the
following keys. (Figure 2-11)
Numeric keypad: Your notebook allows certain keys to
n
serve dual purposes, both as standard characters and
as numeric and mathematical keys. The ability to tog-
gle between the standard character and numerical keys
is controlled through the [NumLk] key.
Cursor keys: Your keyboard contains four arrow
n
keys for moving the cursor or insertion point to the
right, left, up, or down within windows, applications
and documents.
Function keys: The keys labeled [F1] through [F12],
n
are used in conjunction with the [Fn] key to produce
special actions that vary depending on what program
is running.
Windows key: This key works with your Windows
n
operating system and functions the same as the
onscreen Start menu button.

NUMERIC KEYPAD

Certain keys on the keyboard perform dual functions as
both standard character keys and numeric keypad keys.
NumLk can be activated by pressing the [NumLk] keys.
Turning off the NumLk feature is done the same way.
Function Keys
Numeric Keypad
Figure 2-11 Keyboard
Once this feature is activated you can enter numerals 0
through 9, perform addition (+), subtraction (-),
multiplication (*), or division (/), and enter decimal
points (.) using the keys designated as ten-key function
keys. The keys in the numeric keypad are marked on the
front edge of the key to indicate their secondary functions.
(Figure 2-11)

WINDOWS KEY

Your LifeBook notebook has one Windows Start key.
The Start key displays the Start menu. This button func-
tions the same as your onscreen Start menu button.
(Please refer to your Windows documentation for addi-
tional information regarding the Windows key.)
(Figure 2-11)

CURSOR KEYS

The cursor keys are the four arrow keys on the keyboard
which allow you to move the cursor up, down, left and
right in applications. In programs such as Windows
Explorer, it moves the "focus" (selects the next item up,
down, left, or right). (Figure 2-11)
G e t t i n g t o K n o w Y o u r N o t e b o o k
x
Cursor Keys
