Assembly Instructions & User's Manual

PROPANE GAS COOKING PLATE

Model # MGP-22

Certified under ANSI Z21289-2017/CSA 1.18-2017

Outdoor Cooking Specialty Gas Appliance

Keep this manual for future reference

Warning

READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR

OPERATE THIS PRODUCT.

Adult assembly required. Keep screws and parts out of reach of children.

DO NOT RETURN YOUR DEVICE TO THE POINT OF PURCHASE

For assistance, contact our customer service at 1-800-266-1414

Monday to Friday from 8am to 5pm or by email at sales@bismar.com Bismar

inc. - 9 De Montgolfier St, Boucherville, Quebec J4B 8C4 Canada

665-020

Table of Contents

Need help?

Do you have a question about the MGP-22 and is the answer not in the manual?

Questions and answers

Summary of Contents for Marti MGP-22

Page 1 MGP-22 Assembly Instructions & User’s Manual PROPANE GAS COOKING PLATE Model # MGP-22 Certified under ANSI Z21289-2017/CSA 1.18-2017 Outdoor Cooking Specialty Gas Appliance Keep this manual for future reference Warning READ INSTRUCTION MANUAL BEFORE ATTEMPTING TO ASSEMBLE OR OPERATE THIS PRODUCT.
Page 2 WARNINGS SAFETY SYMBOLS: When using this appliance, basic safety precautions should always be observed. Read and understand the meaning of these symbols before assembling and using this appliance. DANGER Indicates a hazardous situation, which if not avoided, will result in death or serious injury. WARNING Be alert to the possibility of serious personal injury if the instructions are not followed.
Page 3: Table Of Contents
TABLE OF CONTENTS Warnings....................2, 4-9 Operating Instructions................. 8 Product Dimension..................9 Exploded View....................10 Parts List.....................11 Assembly Instructions.................12 Care and Maintenance................13 Troubleshooting..................15 Warranty ....................18 NOTE: Before beginning assembly of product, make sure all parts are present. Compare parts with package content list and hardware contents. If any part is missing or damaged do not attempt to assemble the unit.
Page 4: Warnings
WARNINGS SAVE THESE INSTRUCTIONS Read and understand all instructions before assembling and using this appliance. Follow all warnings while using this appliance. Failure to follow these instructions could result DANGER If you smell gas: If possible, immediately turn off gas supply to the appliance by turning the LP tank valve clockwise (right).
Page 5 WARNING • This appliance will be hot during and after use.Use insulated oven mitts or gloves to protect from hot surfaces or splatter from cooking liquids. Closed toed shoes should always be worn during operation of this appliance. • Keep children and pets away from the cooking appliance at all times. •...
Page 6 WARNING • Maintain proper clearances from combustible construction. Minimum clearance from sides and back of unit to combustible construction: 24 inches from sides and 36 inches from back. • Do not leave the appliance unattended. Keep children and pets away from the appliance at all times.
Page 7 WARNINGS: LP TANK DANGER Before each use, check for abrasion, wear, cuts or leaks on the hose. If damage is evident, the hose must be replaced before use. 1. Do not store LPG cylinders under or near the barbecue and any heat source. 2.
Page 8 WARNINGS: LP TANK CONNECTING HOSE ASSEMBLY TO 20LB. CYLINDER: 1. Make sure cylinder valve is turned OFF (turning clockwise). OPD triangular handle 2. Check cylinder valve to ensure it has proper external male threads as illustration(type 1 ANSI Z21.81). 3. Make sure all burner valves are in the OFF External threads (type 1 ANSI Z21.81) positions.
Page 9 WARNINGS: LP TANK STEPS TO LEAK TEST: 1. Use a clean paint brush and 50/50 soap and water solution. NOTE: Use a mild soap and water. DO NOT use household cleaning agents. Damage to gas train components could result. 2. Brush soapy solution onto all metal seams and entire valve area. Slowly turn the LP tank valve counterclockwise to the open position.
Page 10: Operating Instructions
OPERATING INSTRUCTIONS INSTRUCTIONS FOR LIGHTING BURNER: 1. Read all instructions before lighting. 2. Make sure all control knobs are in the OFF position. OFF/ARRÊT OFF/ARRÊT LIGHTING INSTRUCTIONS: 6. IF IGNITION DOES NOT OCCUR IN 5 3. SÉLECTIONNEZ LE BRÛLEUR À ÊTRE 1.
Page 11: Product Dimension
DANGER NEVER allow this appliance to operate unattended. Failure to fo or burn hazard that could cause property damage, personal injur the appliance, move everyone to safety and immediately contact CO2 extinguisher or preferably a Class “K” extinguisher. Special care must be taken to understand the manufacturers instructions and be prepared to operate the appropriate extinguisher prior to using this appliance.
Page 12: Exploded View
EXPLODED VIEW...
Page 13: Parts List
PARTS LIST NOTE: Wash all parts that will come in contact with food or water with warm soapy water. Rinse and towel dry. Part # Description Image Plate body Cooking Plate Grease Box Adjustable feet Regulator Assembly Hose Assembly...
Page 14: Assembly Instructions
ASSEMBLY INSTRUCTIONS STEP 1 Choose a good, cleared assembly area, lay a cardboard down to protect gas plancha finish and assembly area. Place the plate body (1) upside down. Screw 4 adjustable feet (4) into the plate body (1). Turn the gas plate body (1) over after this step finished.
Page 15: Care And Maintenance
CARE AND MAINTENANCE HOW TO CLEAN: CAUTION Allow unit to fully cool (115˚F or 45˚C) before performing any cleaning. Proper care and appliance maintenance will keep your product operating smoothl Keep appliance area clear and free from combustible materials, gasoline, and other flammable vapors and liquids.
Page 16 CARE AND MAINTENANCE SUGGESTED CLEANING MATERIALS: • Hot water • Mild dishwashing liquid detergent • Soft, nylon cleaning pad INSECT WARNING ! Your cooking plate might still light but... Your appliance does not reach temperature. D5 Spring Washer The cooking plate heats unevenly. M5 x 12 Screw (A) M5 Nut...
Page 17: Troubleshooting
TROUBLESHOOTING Problems Possible causes Solutions 1/ LPG gas bottle is empty Burners can’t be lit by the 1/ Replace with full bottle 2/ Faulty regulator existing ignition system 2/ Check or replace the regulator 3/ Obstructions in the burners 3/ Clean burners 4/ Obstructions in gas pipe or hose 4/ Clean gas pipe or hose Burners can’t be lit by a match...
Page 18: Warranty
Propane gas cooking plate MGP-22 for one (1) year against any material and manufacturing defect applicable from the date of purchase and applies only to the original purchaser of the appliance provided it was purchased from a representative, or authorized reseller of MARTIN gas appliances.
