Instruction Manual JAVA / TH1500DB Please read through the manual for appropriate use of the product. After you read through the manual, keep it ※ in a proper place for the users. Contents Cautions for Safety Features of Product Name of Each Part...
Page 2: Cautions For Safety
1. Cautions for Safety (You must observe the followings for your safety.) This manual is for users to use the machine safely and properly and has several indications to prevent the risks and property damage in use beforehand. You should read it carefully for a proper use. And make sure to keep this manual in a place where a user can easily access to read after reading it.
Page 3: Features Of Product
20 seconds after continuous running. You can reuse it by pull the hands out and then put them in again. The built-in water receiver is removable slide, therefore anyone can easily remove the water that is full in the receiver. TH1500DB...
Page 4 2. Features of Product (2) Unique Features of "TH1500DB" You can control the strong wind speed coming out of the 1330W motor in 6 phases. 6-phased Wind Speed Blue led illuminations come to light time it will be able to...
Page 5: Name Of Each Part
?6mm 드릴로 깊이 30mm Instruction Manual 구멍 뚫을 것 JAVA 28.8 / TH1500DB Please read through the manual for appropriate use of the product. ※ After you read through the manual, keep it in a proper place for the users.
Page 6: Drawing Of Finished Installation
4. Drawing of Finished Installation Install it 320mm away from the oor 5. Cautions in Installation Thank you very much for purchasing our product. Install the machine correctly following this manual so it can perform well. Cautions for Safety ■ This indication means that the person can be seriously injured Warning or even dead if he or she uses the machine improperly, ignoring...
Page 7: Installation Method
6mm as shown in the drawing. Insert nylon anchors into the holes. Fix the bracket with xing screws. In case of installation on the other walls than a concrete wall, install the machine after suf cient reinforcement. TH1500DB...
Page 8 6. Installation Method 2. Fix the machine in the installation plate. Fix the machine in the locking sill. (At this time, install the water receiver independently.) After xing the machine, fasten it with xing screws completely into the 2 holes in the bottom. Connect the water receiver into the machine.
Page 9: How To Use
Power ※ If you set the wind strength to the weak mode, you can use the machine a little bit more quietly as the motor output decreases. It will be able to economize an electricity. TH1500DB...
Page 10: How To Clean
8. How to Clean Make sure to remove the power cable from the socket while you are cleaning the machine. (Or electric shocks may possibly occur.) Do not insert or pull out the power cable with a wet hand. (There is an electric shock hazard.) Warning Never spread water or cleanser on the main body or the power cable part.
Page 11 In case of cleaning it with water or cleanser, connect them after drying out the water completely. After cleaning ■ Turn the power switch on with an unwet hand. TH1500DB...
Page 12: Trouble Shooting
9. Trouble Shooting Symptoms Checkups Actions -Is there any power failure? -Check the power state of other product. -Is the power cable unplugged? -It makes the power plug paste in the cone In case that the cent, to connect. wind doesn't -Is the power 230V? -Connect into 230V power supply.
Page 13: Speci Cations
10. Speci cations Model Name TH1500DB Size 300(W) x 557(H) x 194(D) mm Rated Power AC230V / Usable for both 50Hz and 60Hz Rated Power Consumption 1330W Motor Brush Motor Filter HEPA Filter Blast Fan Turbo Fan Safety Device Temperature Fuse, Overcurrent Fuse, and Bimetal SW...
