Instructions for Collecting Pickleballs

Thank you for purchasing a Kollectaball! Our collectors work brilliantly with

Pickleballs however, it's very important that they are assembled in a slightly

different manner to when collecting tennis balls.

The only difference is in the assembly of the wires; because Pickleballs are

lighter than most sports balls, it's important you only assemble the cage with

half the wires. This will decrease the tension between the wires and allow the

Pickleballs to enter into the cage instead of being pushed further away when

collecting.

Please insert a wire in every other slot, as seen in the below pictures and

instructions. You will be left with 30 spare wires.

Step 1: Assemble

the handle as

explained in the

instructions that

come in the box.

Step 2: Insert a

wire in every other

slot. (Insert one

wire, miss a space

and then insert the

other).

Step 3: Continue

this until you have

completed the

sequence for the

first black plastic

disk.

Table of Contents

Do you have a question about the Kollectaball K-Max and is the answer not in the manual?

Page 1 Instructions for Collecting Pickleballs Thank you for purchasing a Kollectaball! Our collectors work brilliantly with Pickleballs however, it’s very important that they are assembled in a slightly different manner to when collecting tennis balls. The only difference is in the assembly of the wires; because Pickleballs are lighter than most sports balls, it’s important you only assemble the cage with half the wires.
Page 2 Take the other end of If you make a mistake and place two wires side by side the wires and begin as above, use the wire removal tool as shown. Push the placing them into the pin end of the tool into the hole corresponding with the holes on the other black wire you would like to remove.
Page 3 Place the V-opener over It should look like this Lay down the rest the pieces on the the handle so the holes floor, you should have the handle, the on either side of the v- v-opener, the long screw, two flat opener line up with the head screws, two washers and an M6 holes on the handle...
Page 4 Tighten the M6 nut with the spanner provided. At the end of assembly you will be left with 30 wires. If you enjoy your Kollectaball, please shout about us to your friends or on social media or review our products on the sales channel you bought off!
