  • Page 1 Recorder SBR-EW100 User's Manual IMSBR07-E1...

  • Page 3: Foreword

    This manual describes the functions (excluding the communication functions), installation and wiring procedures, operating procedures, and lists the handling precautions of the SBR-EW100 Recorder. To ensure correct use, please read this manual thoroughly before beginning operation. The following two manuals, in addition to this one, are provided as manuals for the SBR- EW100 Recorder.

  • Page 4: Safety Precautions

    Safety Precautions The general safety precautions described here must be observed during all phases of operation. Safety Standards and EMC Standards This recorder conforms to IEC safety class I (provided with terminal for protective grounding), Installation Category II, Measurement Category II (CAT II), and EN61326-1 (EMC standard), class A (use in a commercial, industrial, or business environment).
  • Page 5 Safety Precautions WARNING • Power Supply Ensure that the source voltage matches the voltage of the power supply before turning ON the power. • Protective Grounding Make sure to connect the protective grounding to prevent electric shock before turning ON the power. •...

  • Page 6: Checking The Contents Of The Package

    RKC INSTRUMENT INC. Made in China MODEL and SUFFIX Code Model Suffix Code Optional Code Description EW101 SBR-EW100 1 pen recorder EW102 SBR-EW100 2 pen recorder EW103 SBR-EW100 3 pen recorder EW104 SBR-EW100 4 pen recorder EW106 SBR-EW100 6 dot recorder Japanese English &...
  • Page 7 Blue Violet Plotter pen Purple Mounting bracket SBR-EW100 Recorder Operation Guide IMSBR06-E( ) Optional Accessories (Sold Separately) The optional accessories below are available for purchase separately. If you make an order, make sure that all contents are present and undamaged.
  • Page 8 Checking the Contents of the Package Removing the Packing Materials Open the door, put your finger on the tab at the lower left of the display, and open the display. Tab on the display Open Display Open Remove all packing materials. •...

  • Page 9: How To Use This Manual

    User’s Manual (IMSBR08-E). Chapter Title and Description Functional Description Describes the functions of the SBR-EW100 Recorder. Refer to this chapter when you are unsure of the details of the function that you are operating. Before Using the Recorder Describes the installation and wiring procedures.
  • Page 10 How to Use This Manual Conventions Used in This Manual Unit K ..Denotes 1024. Example: 768 KB (file size) k ..Denotes 1000. Safety Markings The following markings are used in this manual. Improper handling or use can lead to injury to he ser or damage to the instrument.

  • Page 11: Table Of Contents

    Safety Precautions .......................... ii Checking the Contents of the Package ..................iv How to Use This Manual ....................... vii Chapter 1 Functional Description Overview of the SBR-EW100 ..................1-1 Detailed Explanation of Functions ................... 1-2 Alarms ..........................1-7 Recording ........................1-13 Display ...........................
  • Page 12 Contents Changing the Chart Speed .................... 5-13 Setting the Date/Time ....................5-14 Chapter 6 Setup Operations for Convenient Functions (Setting Mode) Setting the Dot Printing Interval (Dot Model)..............6-1 Setting the Filter (Pen Model) ..................6-2 Setting the Moving Average (Dot Model) ................. 6-3 Setting Recording Zones for Each Channel (Zone Recording) ........
  • Page 13 Contents Setting the Partial Expanded Recording ................ 9-16 Turning Trend Recording (Dot Model) and Periodic Printout ON/OFF for Each Channel ....................9-17 9.10 Setting Tags on Channels ....................9-18 9.11 Setting the Alarm Delay Duration ................... 9-19 9.12 Setting the Timer Used in TLOG Computation and Periodic Printout ......9-20 9.13 Changing the Channel Recording Color (Dot Model) ............

  • Page 15: Chapter 1 Functional Description

    Chapter 1 Functional Description 1.1 Overview of the SBR-EW100 The SBR-EW100 Recorder (hereafter referred to as the recorder) can be used to assign DC voltage, 1-5V, thermocouple, RTD, and contact or voltage ON/OFF signal to channels for measurement. The measured results are recorded with pens or dots on a chart paper that is fed at a constant speed.

  • Page 16: Detailed Explanation Of Functions

    1.2 Detailed Explanation of Functions Input Section Number of Measurement Channels and Scan Interval The recorder samples the input signals on the measurement channels at the scan interval to obtain the measured values. Model Number of Channels Scan Interval 1-pen model 125 ms 2-pen model 125 ms...
  • Page 17 1.2 Detailed Explanation of Functions • Delta Computation The value obtained by subtracting the measured value of another channel (called the reference channel) from the input value of the channel set to delta computation is used as the measured value of that channel. The reference channel must be assigned to a channel whose channel number is less than that of the channel on which delta computation is specified.
  • Page 18 1.2 Detailed Explanation of Functions Bias A given value (bias value) is added to the input value and used as the measured value of that channel. Biased channel Input value Measured value Bias value <Related Topics> Setting the bias: Section 7.15 and 6.12 Burnout Detection of Thermocouples This function makes the recording go off the scale to the right or left when the thermocouple burns out while measuring temperature with a thermocouple.
  • Page 19 1.2 Detailed Explanation of Functions Noise Elimination from Input Signals Filter and Moving Average This function used to suppress the effects of noise that is riding on the signal. The pen model and dot model are equipped with a filter function and a moving average function, respectively.
  • Page 20 1.2 Detailed Explanation of Functions Integration Time of the A/D Converter The recorder uses an A/D converter to convert the sampled analog signal to a digital signal. By setting the integration time of the A/D converter to match the time period corresponding to one cycle of the power supply or an integer multiple of one cycle, the power supply frequency noise can be effectively suppressed.

  • Page 21: Alarms

    1.3 Alarms This function generates an alarm when the measured data meets a certain condition. The alarm occurrence/release can be recorded on the chart paper. The alarm status can be displayed on the screen. Also, alarm output relays can be used to output contact signals when alarms occur (/A1, /A2, and /A3 options).
  • Page 22 1.3 Alarms • Delay High Limit Alarm (T) An alarm occurs when the measured value remains above the alarm value for a specified time period (alarm delay period). • Delay Low Limit Alarm (t) An alarm occurs when the measured value remains below the alarm value for a specified time period (alarm delay period).
  • Page 23 1.3 Alarms Alarm Indication The alarm status can be displayed on the screen. For details on the display, see section 1.5. Non-Hold/Hold Operation of the Alarm Indication The alarm indication can be set to operate in the following fashion when the alarm condition is no longer met.
  • Page 24 1.3 Alarms Reflash Alarm When multiple alarms are assigned to one alarm output relay, this function notifies the occurrence of subsequent alarms after the relay is activated by the first alarm. When subsequent alarms occur, the output relay is released temporarily (approximately 500 ms).
  • Page 25 1.3 Alarms AND/OR Operation of Alarm Output Relays When multiple alarms are assigned to one alarm output relay, the condition for activating the alarm output relay can be selected from the following: • AND: Activated when all assigned alarms are occurring simultaneously. •...
  • Page 26 1.3 Alarms Non-Hold/Hold Operation of Alarm Output Relays The alarm output relay can be set to operate in the following fashion when the alarm condition is no longer met. • Turn off the relay output (non-hold). • Hold the relay output until the alarm ACK operation is executed (hold). The setting applies to all alarm output relays.

  • Page 27: Recording

    1.4 Recording The recorder is capable of recording the measured values with pens or dots (trend recording) as well as various other types of information. Recording Example on the Pen Model Recording Example on the Dot Model The recording examples may appear differently from the actual recording as a result of functional improvements made on the recorder after this manual was written.
  • Page 28 1.4 Recording Trend Recording The measured values are printed within a width of 100 mm. Recording Method (Pen Model) • The measured value is updated every scan interval and continuously recorded. • The recording colors in order from channel 01 are red, green, blue, and violet. Recording Method (Dot Model) •...
  • Page 29 1.4 Recording Partial Expanded Recording This function expands a section of the recording range. By default, partial expanded recording is disabled. Compressed Expanded <Related Topics> Setting the partial expanded recording: Section 7.13 and 6.5 Pen Offset Compensation (Pen Model) This function compensates for the pen offset (phase difference) along the time axis. On 2-pen, 3-pen, and 4-pen recorders, there are offsets along the time axis (phase difference) between the pens.
  • Page 30 1.4 Recording Printout The figure below is used to explain the printout contents. The actual printout and font are different from those illustrated in the figure. The printout positions are also slightly different. Printout Example on the Pen Model Manual printout Nov.09.04 15:00 223.5mg/cm 437.2µS/cm...
  • Page 31 1.4 Recording Printout Example on the Dot Model Manual printout Nov.09.04 16:00 223.5mg/cm 437.2µS/cm −0.222V 591.6˚C −0.665V 6 L −0.448V New chart speed printout _50mm/h 14:55 Periodic printout Nov.09.04 Time tick 13:50 218.7mg/cm 390.6µS/cm 598.4˚C −0.222V Scale −0.995V L −0.448V 500.0 mg/cm Delta computation...
  • Page 32 1.4 Recording Alarm Printout Alarm information is printed when an alarm occurs or releases. Time of alarm occurrence/release Indicates that there are alarms that are not printed because the alarm printout buffer is full. Level number Alarm type Channel No. or tag : Alarm occurrence, : Alarm release •...
  • Page 33 1.4 Recording • Turning ON/OFF the Periodic Printout Periodic printout can be turn ON/OFF. By default, periodic printout is enabled with the interval synchronized to the chart speed. Also, the measured values that are printed are the instantaneous values. Manual Printout Measured values and alarm status can be printed manually using the keys.
  • Page 34 1.4 Recording Setting Printout List or Setup List can be printed. When setting printout is executed, trend recording stops and restarts when the printout is complete. List contains settings such as the input range and alarm for each channel. Setup List contains settings of functional specifications such as the alarm output relay operation and printout method.
  • Page 35 1.4 Recording • Printout Example of List on the Dot Model The printout examples may appear differently from the actual printout as a result of functional improvements made on the recorder after this manual was written. 1-21 IMSBR07-E1...

  • Page 36: Display

    1.5 Display Displayed Information Main Display The recorder is capable of displaying measured values, alarm information, and so on the VFD (Vacuum Fluorescent Display). Using normal fonts, 17 characters × 2 lines can be displayed. Using large fonts, 11 characters can be displayed. Status display Main display 1 2 3 4 5 6...
  • Page 37 1.5 Display Several display examples are shown below. For details on the display types, see “Display Function Specifications” in section 12.4. 1 Channel Digital + 1 Bar Graph Display Channel No. Alarm status Measured value Unit Bar graph Scale Alarm point mark Flag Display Flag (the number indicates the channel No.) Scale...

  • Page 38: Computation Function (/M1 Option)

    1.6 Computation Function (/M1 Option) Computation Function Computing equations can be set up using measured values and other computed values as variables in computation-dedicated channels, and the computation can be executed. The computed result can be recorded. Computation is performed every scan interval. Channels Dedicated to Computations The computation-dedicated channels below can be used.
  • Page 39 Range of values (maximum significant digits is 5): -9.9999E+29 to -1.0000E-30, 0, 1.0000E-30 to 9.9999E+29 For the procedure of setting the communication input data, see the SBR-EW100 Recorder Communication Interface User’s Manual (IMSBR08-E). • Status of the Remote Control Input Terminal (D01 to D05, /R1 option) The status of the remote control input signal (1 or 0) can be used in the computation.
  • Page 40 1.6 Computation Function (/M1 Option) • The Number of Channels Being Trend Recorded and the Fastest Recording Interval The fastest recording interval varies depending on the number of channels being trend recorded. Only display or printout is possible on measurement channels or computation channels that are not trend recorded.

  • Page 41: Fail/Chart End Output Function (/F1 Option)

    1.7 FAIL/Chart End Output Function (/F1 Option) FAIL Output When a failure occurs in the CPU of the recorder, a relay contact signal (1 signal) is output. The relay is energized when the CPU is normal and de-energizes when a CPU failure occurs.

  • Page 42: Remote Control Function (/R1 Option)

    Specified operations can be carried out by applying remote signals (contact or open collector signals) to the remote control input terminals. There are five remote control input terminals. An action can be assigned to each terminal. SBR-EW100 Recorder Contact Open collector Assignable Functions •...
  • Page 43 1.8 Remote Control Function (/R1 Option) • Computation Start/Stop • Remote input signal: Rising edge signifies start; falling edge signifies stop • Starts/stops the computation. This is valid only on models with the computation function (/M1 option). • If the computation is started, applying a rising edge signal produces no effect. If the computation is stopped, applying a falling edge signal produces no effect.

  • Page 44: Other Functions

    1.9 Other Functions Key Lock Key operations can be disabled such as when keys are not needed for an extended time. When key lock is enabled, pressing keys produces no effect. To release the key lock, a password is entered. Key Lock Items Each of the following keys can be included or excluded from the key lock function.

  • Page 45: Chapter 2 Before Using The Recorder

    Chapter 2 Before Using the Recorder 2.1 Handling Precautions This section describes the precautions to be taken when using the recorder. Read this section before use. Handling Precautions • Use care when cleaning the recorder, especially any plastic parts. When cleaning, wipe using a dry soft cloth.

  • Page 46: Installation

    2.2 Installation Installation Location Install the recorder indoors in a location that meets the following conditions. See also the normal operating conditions described in section 12.6, “General Specifications”. • Instrument Panel and Rack The recorder is designed for panel or rack mounting. •...
  • Page 47 2.2 Installation Installation Procedure The recorder should be mounted on a steel panel of thickness 2 mm to 26 mm. Insert the recorder from the front side of the panel. As shown in the figure below, mount the recorder to the panel using the mounting brackets that come with the package.
  • Page 48 2.2 Installation External Dimensions of the Recorder Unit: mm Unless otherwise specified, tolerance is ±3% (however, tolerance is ±0.3 mm when below 10 mm). 27.5 151.5 2-26 Mounting panel (Dimensions before attaching thickness the mounting bracket) 136.5 151.5 (Dimensions after attaching the mounting bracket) Panel Cutout Single-Unit Mounting...

  • Page 49: Input Signal Wiring

    2.3 Input Signal Wiring General Precautions to Be Taken While Wiring WARNING To prevent the possibility of electric shock when wiring, make sure that the power supply source is turned OFF. CAUTION • If a strong tension is applied to the cable wired to the recorder, the terminals of the recorder and/or the cable can be damaged.
  • Page 50 2.3 Input Signal Wiring When using internal reference junction compensation on the thermocouple input, take measures to stabilize the temperature at the input terminal. • Always use the terminal cover. • Do not use thick wires which may cause large heat dissipation (cross sectional area of 0.5 mm or less recommended).
  • Page 51 2.3 Input Signal Wiring Dot Model Channel 1 Channel 2 Channel 1 Channel 2 Channel 3 Channel 4 Channel 3 Channel 4 Channel 5 Channel 6 Channel 5 Channel 6 Screw input terminal Clamped input terminal (/H2 option) Turn OFF the recorder and remove the terminal cover. Connect the signal wires to the terminals.
  • Page 52 2.3 Input Signal Wiring Measuring Input Wiring Thermocouple input Resistance temperature detector input –/B –/B Leadwire resistance: Extension leadwire 10 max./wire. The resistance of the three wires should be equal. DC voltage input, 1-5V input, DC current input and ON/OFF input –/B –/B Shunt resistor...

  • Page 53: Optional Terminal Wiring

    2.4 Optional Terminal Wiring General Precautions to be Taken While Wiring the Input/Output Signal Wires WARNING • To prevent electric shock while wiring, ensure that the power supply source is turned OFF. • If a voltage of more than 30 VAC or 60 VDC is to be applied to the output terminals, use ring-tongue crimp-on lugs with insulation sleeves on all terminals to prevent the wires from slipping out when the screws become loose.
  • Page 54 2.4 Optional Terminal Wiring /A1/F1 /A1/R1 /A1/F1/R1 (/F1) (/F1) FAIL FAIL (/R1) (/R1) /A2/F1 /A2/R1 /A2/F1/R1 (/F1) (/F1) FAIL FAIL (/R1) (/R1) /A3/R1 (/F1) FAIL (/R1) (/R1) /F1/R1 CE: Chart end (/F1) FAIL (/R1) Alarm Output Relay Terminals and FAIL/Chart End Output Relay Terminals NC (Normally Closed), C (Common), NO (Normally Opened) Remote Control Input Terminals 1 to 5 (remote control input terminals), C (Common)
  • Page 55 2.4 Optional Terminal Wiring Wiring Procedure Turn OFF the recorder and remove the terminal cover. Connect the input signal wires to the terminals. Philips screwdriver Crimp-on lug with insulation sleeves Replace the terminal cover and fasten it with screws. The proper torque for tightening the screws is 0.6 N-m. Alarm output Remote control input FAIL/chart end output...

  • Page 56: Power Supply Wiring

    2.5 Power Supply Wiring Precautions to Be Taken While Wiring the Power Supply Make sure to follow the warnings below when wiring the power supply. To prevent electric shock and damage to the recorder, observe the following warnings. WARNING • To prevent electric shock when wiring, ensure the main power supply is turned OFF.
  • Page 57 2.5 Power Supply Wiring Wiring Procedure The power supply terminals and a protective ground terminal are located on the rear panel. Turn OFF the recorder and open the transparent power terminal cover. Power terminal block Screw for fixing the power terminal cover in place Power terminal cover Open...

  • Page 58: Turning On/Off The Power Switch

    2.6 Turning ON/OFF the Power Switch CAUTION Check the following points before turning ON the power switch. • The power cord/wires are connected correctly to the recorder. • The recorder is connected to the correct power supply (see section 2.5). The power switch is located inside the door at the lower right.

  • Page 59: Chapter 3 Names Of Parts And Run Operations

    Chapter 3 Names of Parts and Run Operations 3.1 Names of Parts Front Name plate The model name is written on the name plate. Display and key panel Hold the tab at the lower left and pull to open. Door Mounting hole Tag plate There is one hole on each of the...
  • Page 60 3.1 Names of Parts Display and Key Panel Status display Displays the following information. RECORD Illuminates while recording measured values. KEY LOCK Illuminates when key lock is enabled. MATH Illuminates when computation on the computation function (/M1 option) is in progress. CHART END Illuminates when the chart paper is out (/F1 option).
  • Page 61 3.1 Names of Parts Rear Panel Heatsink Dissipates the internal heat. Power terminal block The power terminal and protective ground terminal. Optional terminal block This is where terminals or ports used by options such as alarm output relays and communication interface are installed.

  • Page 62: Installing Or Replacing The Chart Paper

    3.2 Installing or Replacing the Chart Paper CAUTION • Do not install or remove the chart cassette with the chart paper guide open. This may damage the stopper. • Continuing to record or print without the chart paper on the dot model can cause damage to the chart cassette platen (the cylindrical section that holds the paper during the recording operation).
  • Page 63 3.2 Installing or Replacing the Chart Paper Open the chart holder and the chart paper guide. Chart holder This sheet is provided on models with the chart end detection function (/F1 option). Do not remove or bend this sheet. Chart paper guide Load the chart paper.
  • Page 64 3.2 Installing or Replacing the Chart Paper Replace the chart cassette back into the recorder case. Align the left and right projections of the sprocket section with the guide grooves of the recorder and press the entire chart cassette into the recorder case. The chart cassette is fixed in place with the stoppers.

  • Page 65: Installing/Replacing Felt Pens Or Plotter Pen (Pen Model)

    3.3 Installing/Replacing Felt Pens or Plotter Pen (Pen Model) CAUTION • Do not press or pinch the felt tip to prevent deformation. • Do not move the penholder left or right by force to protect the driving mechanism. • Make sure to remove the pen cap before installation. •...
  • Page 66 3.3 Installing/Replacing Felt Pens or Plotter Pens (Pen Model) When the Pen (Pen Holder) Is at a Position That Is Not Easily Accessible If the pen (pen holder) is at a position that is not easily accessible, carry out the procedure below to move it near the center position.

  • Page 67: Installing/Replacing The Ribbon Cassette (Dot Model)

    3.4 Installing/Replacing the Ribbon Cassette (Dot Model) CAUTION • Improper cassette insertion may cause the color to change or damage the ribbon. • Do not apply upward force to the printer carriage. If you do, the carriage position may be offset, and the recorder may not print correctly. Open the door.

  • Page 68: Starting/Stopping The Recording

    3.5 Starting/Stopping the Recording This section describes the procedures for starting/stopping the recording and checking the recorded result. Procedure Starting the Recording Press the key to start recording. The status display shows the word “RECORD”. Stopping the Recording While recording is in progress, press the key to stop recording.

  • Page 69: Switching The Display Screen

    3.6 Switching the Display Screen This section describes the procedure for switching the display screen. To change the displayed content, see chapter 8. Procedure Switching the Display Screen The display screen switches each time the key is pressed. DISP Screen 01 through 15 are switched in order. Channel Auto Switching On screens that show the measured values and computed values, the displayed channel is automatically switched in ascending order.

  • Page 70: Printing Measured Values (Manual Printout)

    3.7 Printing Measured Values (Manual Printout) The measured values of all channels are printed. Procedure Starting the Manual Printout Press the key. FUNC key or SHIFT + key to select Print out and then press the Press the key. Func=Print out key with ManualStart shown on the screen.

  • Page 71: Printing The Recorder Settings

    3.8 Printing the Recorder Settings This section explains the procedure for printing the recorder settings. There are two sets of settings that can be printed: List and Setup. List: Prints the settings of Setting mode (input range for each channel, etc.) Setup: Prints the settings of Basic Setting mode Note •...

  • Page 72: Clearing The Alarm Printout Buffer

    3.9 Clearing the Alarm Printout Buffer Alarm information waiting to be printed is temporarily stored in the buffer memory. This operation clears all of the alarm information in the buffer. This function can be used to prevent unneeded alarm printouts from being executed. Procedure Press the key.

  • Page 73: Printing Messages

    3.10 Printing Messages This section explains the procedure for printing the preset character strings. For the procedure of setting the character strings, see section 6.6. Note • Messages can be printed only during trend recording. However, regardless of whether trend recording is ON or OFF, messages waiting to be printed are temporarily stored in the buffer memory.

  • Page 74: Resetting The Report Data Of The Periodic Printout

    3.11 Resetting the Report Data of the Periodic Printout This operation resets the past report data when the recorder is configured to print the report data (the average, the minimum, the maximum, or the sum) of the measured values in periodic printout. Procedure Resetting the Report Data Press the...

  • Page 75: Releasing The Alarm Output (Alarm Ack Operation)

    3.12 Releasing the Alarm Output (Alarm ACK Operation) This operation releases the alarm indication or relay output (/A1, /A2, or /A3 option) when the alarm indication or output relay is set to hold operation. Procedure Releasing the Alarm Output Press the key.

  • Page 76: Activating/Releasing The Key Lock

    3.13 Activating/Releasing the Key Lock When the recorder is configured to use the key lock function, this operation activates or releases the key lock. Note Key lock does not apply to the DISP keys. CH UP Procedure Activating the Key Lock Press the key.

  • Page 77: Chapter 4 Common Operations For Setting Functions And Setup Guide

    Chapter 4 Common Operations for Setting Functions and Setup Guide 4.1 Run Modes The recorder has three run modes. Operation Mode This mode is used for normal recording operation. The recorder enters this mode when the power is turned ON. The operations that can be carried out in this mode are described in chapter 3.

  • Page 78: Key Operations

    4.2 Key Operations This section describes basic operations on the panel keys to change various settings. Functions are set in Setting mode or Basic Setting mode. Entering Setting Mode Hold down the key for 3 seconds. MENU The Setting mode display appears. The top and bottom lines are the setup item and comment, respectively.
  • Page 79 4.2 Key Operations Changing the Settings Note The comment line shows useful information such as a description of the setup item and the range of selectable values. Read the comment and change the items as necessary. The selected item change each time you press the key.
  • Page 80 4.2 Key Operations Entering Characters key or SHIFT + Use the key to move the cursor. SHIFT key + Unit=ppm CHR:a-z Cursor Use the CHARACTER key or SHIFT + CHARACTER key to select the character key or SHIFT + type. Use the key to select a character.

  • Page 81: Menu Structure, Settings, And List Of Default Values

    4.3 Menu Structure, Settings, and List of Default Values Operation Menus Using the FUNC Key (Operation Mode) Below are the items that are operated using the key. Information indicated inside FUNC the parentheses is references. FUNC : Use the key. Alarm ACK : Use the key.
  • Page 82 4.3 Menu Structure, Settings, and List of Default Values Menu Structure of Setting Mode Below are the setup items in Setting mode. Information indicated inside the parentheses is references. Range Volt Range Span_L Span_R (section 5.1) Range Span_L Span_R Use the key.
  • Page 83 4.3 Menu Structure, Settings, and List of Default Values Menu Structure of Basic Setting Mode Below are the setup items in Basic Setting mode. Information indicated inside the parentheses is references. Alarm Diagnosis Reflash Behavior (section 7.1) Indicator Increase Decrease Hysteresis M_Hysteresis Integrate...
  • Page 84 4.3 Menu Structure, Settings, and List of Default Values Setup Items in Setting Mode and Their Default Values Items with an asterisk on the left are not displayed in the default condition. To display these items, settings must be changed in Basic Setting mode. Setup Item Pen/Dot Selectable Range or Selections...
  • Page 85 4.3 Menu Structure, Settings, and List of Default Values Setup Item Pen/Dot Selectable Range or Selections Default Value Math > Alarm > CH 0A/0B/0C/0D/0E/0F/0G/0J/0K/0M/0N/0P Math > Alarm > Level 1/2/3/4 Math > Alarm > Alarm On/Off Math > Alarm > Type H/L (*/T/t) Math >...
  • Page 86 4.3 Menu Structure, Settings, and List of Default Values Setup Item Pen/Dot Selectable Range or Selections Default Value Print2 > CH 01 to 06 Print2 > Mode AVE/MIX/SUM/MIN/MAX/INST Print2 > SUM scale Off, /s, /min, /h, /day Bar graph > CH 01 to 06 Bar graph >...
  • Page 87 4.3 Menu Structure, Settings, and List of Default Values Setup Item Pen/Dot Selectable Range or Selections Default Value Math > Color > Color Dot Model Purple/Red/Green/Blue/Brown/Black Purple: 01/OA/0G Red: 02/OB/0J Green: 03/OC/0K Blue: 04/OD/0M Brown: 05/OE/0N Black: 06/OF/0P Math > Output pen > Pen←CH Pen Model Pen: 1 to 4, Channel: 01 to 04/0A to 0J 1pen: 01, 2pen: 02, 3pen: 03, 4pen: 04,...

  • Page 88: Function Setup Guide

    4.4 Function Setup Guide This section explains the settings necessary to use various functions of the recorder. Read the section corresponding to the function you wish to use. Note This section contains all the settings related to each item. If the desired setting is the same as the default value, you do not have to set it.
  • Page 89 4.4 Function Setup Guide Alarm functions Item Description Reference Section Alarms for each channel Use Alarm in Setting mode. Delay high limit alarm/delay low limit alarm • Alarm type 7.15 Use Personalize > Add function > Alarm delay in Basic Mode and select Use or Not. If Use is selected, delay high limit alarm and delay low limit alarm become selectable under Alarm >...
  • Page 90 4.4 Function Setup Guide Item Description Reference Section Channel/tag selection Use Print > CH/Tag in Basic Setting mode to select whether to use channel numbers or tags in printouts. Alarm occurrence/release printout • Turn printout On/Off Use Print > Alarm in Basic Setting mode to select whether to print the alarm occurrence and release, print only the alarm occurrence, or not print.
  • Page 91 4.4 Function Setup Guide Computation function (/M1 option) Item Description Reference Section Computing equation and recording span Use Math > Formula in Setting mode to set the computing equation and recording span for each channel. TLOG computation If TLOG computation is selected, use Math > Timer in Basic Setting mode to 9.12 set the timer operation Use Math >...
  • Page 92 4.4 Function Setup Guide Item Description Reference Section Alarm occurrence/release printout Common with measurement channels. • Channel/tag selection Common with measurement channels. • Tag name 9.10 Use Math > Aux > Tag in Setting mode to set the tag name. Bar graph display mode Use Math >...

  • Page 93: Chapter 5 Frequently Used Setup Operations (Setting Mode)

    Chapter 5 Frequently Used Setup Operations (Setting Mode) 5.1 Setting the Input Range Input range is set for each measurement channel. • The input range cannot be changed on models with the computation function (/M1 option) when computation is in progress (the menu does not appear). •...
  • Page 94 5.1 Setting the Input range Description • Selectable Range of Input Range, Span Left, and Span Right The input range, span left, and span right can be set in the range shown below. Span left and span right cannot be set to the same value. DC voltage (Volt) Range Type Selectable Span Range...
  • Page 95 5.1 Setting the Input range Linear Scaling Set=Range Set the channel range. CH=01-01 First channel Last channel Select Scale. Mode=Scale Select Volt, TC, RTD, or DI. Type=Volt Select the range type. Range=2V Set the left span value. Span_L= -2.000 Set the right span value. Span_R= 2.000 Set the left scale value.
  • Page 96 5.1 Setting the Input range Delta Computation Set=Range Set the channel range. CH=02-02 First channel Last channel Select Delta. Mode=Delta Set the reference channel. Ref.CH=01 Set the left span value. Span_L= -2.000 Set the right span value. Span_R= 2.000 The new setting takes effect. 02-02 Channel ESC/? Setting complete...
  • Page 97 5.1 Setting the Input range ON/OFF Input Set=Range Set the channel range. CH=01-01 First channel Last channel Select DI. MOde=DI Select Cont or Level. Range=Level Set the left span value. Span_L=0 Set the right span value. Span_R=1 The new setting takes effect. 01-01 Channel ESC/? Setting complete...
  • Page 98 5.1 Setting the Input range 1-5V Input Set=Range Set the channel range. CH=01-01 First channel Last channel Select 1-5V. Mode=1-5V Set the left span value. Span_L= 1,000 Set the right span value. Span_R= 5,000 Set the left scale value. Scale_L= 0.00 Set the right scale value.
  • Page 99 5.1 Setting the Input range Square Root Computation Set=Range Set the channel range. CH=01-01 First channel Last channel Select SQRT. Mode=SQRT Select the range type of DC voltage. Range=2V 20 mV, 60 mV, 200 mV, 2 V, 6 V, 20 V, or 50 V Set the left span value.
  • Page 100 5.1 Setting the Input range Note • The displayable/printable range of scale values is -19999 to 30000 excluding the decimal. • If the leftmost value of the scale is set to -20000 (excluding the decimal) and the low-cut value is set to -20000, the value when the low-cut function is applied is displayed as “-Over”. Skip (Unused Channels) Set=Range Set the channel range.

  • Page 101: Setting The Alarm

    5.2 Setting the Alarm The alarm is set for each channel. If you change the input range, set the alarm again. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Alarm and then press the Press the key.
  • Page 102 5.2 Setting the Alarm Explanation Channel Range The only case when an alarm can be set on multiple channels simultaneously is when the channels are set to the same range type (for example channel 01 and 02 are set to 2 V range).
  • Page 103 5.2 Setting the Alarm Note For channels whose the leftmost value of the scale is set to -20000 (excluding the decimal), the alarm value of -20000 is invalid. Set a value that is greater than or equal -19999. • Difference High Limit Alarm/Difference Low Limit Alarm Values in the measurable range can be specified.

  • Page 104: Setting The Unit On Scaled Channels

    5.3 Setting the Unit on Scaled Channels Units are set on channels whose input range is set to Scaling, 1-5V, or SQRT. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Unit and then press the Press the key.

  • Page 105: Changing The Chart Speed

    5.4 Changing the Chart Speed This section explains the details of changing the chart speed. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Chart and then press the Press the key.

  • Page 106: Setting The Date/Time

    5.5 Setting the Date/Time This section explains the details of setting the date/time. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Clock and then press the Press the key.

  • Page 107: Chapter 6 Setup Operations For Convenient Functions (Setting Mode)

    Chapter 6 Setup Operations for Convenient Functions (Setting Mode) 6.1 Setting the Dot Printing Interval (Dot Model). This section explains the details of setting the trend recording interval (dot printing interval) on the dot model. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + Press the...

  • Page 108: Setting The Filter (Pen Model)

    6.2 Setting the Filter (Pen Model) This section explains the details of setting a filter on the measurement channels on the pen model. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Aux and then press the Press the key.

  • Page 109: Setting The Moving Average (Dot Model)

    6.3 Setting the Moving Average (Dot Model) This section explains the details of setting the moving average function on measurement channels on the dot model. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Aux and then press the Press the key.

  • Page 110: Setting Recording Zones For Each Channel (Zone Recording)

    6.4 Setting Recording Zones for Each Channel (Zone Recording) This section explains the details of setting the recording zone for each measurement channel. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Aux and then press the Press the key.

  • Page 111: Setting The Partial Expanded Recording

    6.5 Setting the Partial Expanded Recording This section explains the details of expanding a section of the recording range. If you change the input range, set the partial expanded recording again. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Aux and then press the...

  • Page 112: Turning Trend Recording (Dot Model) And Periodic Printout On/Off For Each Channel

    6.6 Turning Trend Recording (Dot Model) and Periodic Printout ON/OFF for Each Channel This section explains the details of setting the trend recording and periodic printout for each measurement channel. The following settings can be entered for each channel on the dot model. •...

  • Page 113: Setting Tags On Channels

    6.7 Setting Tags on Channels This section explains the details of setting tags to measurement channels. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Aux and then press the Press the key.

  • Page 114: Setting The Message String

    6.8 Setting the Message String This section explains the details of setting the message strings to be printed on the chart paper. Up to five message strings can be registered. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Aux and then press the...

  • Page 115: Setting The Secondary Chart Speed (Remote Control Function, /R1)

    6.9 Setting the Secondary Chart Speed (Remote Control Function, /R1) This section explains the details of setting the secondary chart speed when the chart speed is to be switched using the remote control function (/R1 option). Procedure Hold down the key for 3 seconds to enter Setting mode.

  • Page 116: Setting The Alarm Delay Duration

    6.10 Setting the Alarm Delay Duration This section explains the details of setting the duration of the delay alarm. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Aux and then press the Press the key.

  • Page 117: Setting The Brightness Of The Display And Internal Light

    6.11 Setting the Brightness of the Display and Internal Light This section explains the details of setting the brightness of the display and the internal light. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Aux and then press the Press the key.

  • Page 118: Applying A Bias On The Measuring Input Signal

    6.12 Applying a Bias on the Measuring Input Signal This section explains the details of setting a bias on the measuring input signal. If you change the input range, set the bias again. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Bias and then press the...

  • Page 119: Setting The Date/Time When Switching Between Standard Time And Dst

    6.13 Setting the Date/Time When Switching between Standard Time and DST This section explains the details of setting the date/time when switching from the standard time to DST and the date/time when switching back from DST to standard time if the recorder is used in a region that has DST. When the preset date/time arrives, the recorder internal clock automatically switches.

  • Page 121: Chapter 7 Setup Operations For Changing/Adding Functions (Basic Setting Mode)

    Chapter 7 Setup Operations for Changing/Adding Functions (Basic Setting Mode) 7.1 Changing the Auxiliary Alarm Function This section explains the details of setting the alarm system items listed below. • Diagnosis output using the alarm output relay (I01) • Reflash alarm operation of the alarm output relay (I01 to I03) •...
  • Page 122 7.1 Changing the Auxiliary Alarm Function Basic=Alarm Select On to set relay I01 to diagnosis Diagnosis=Off output. Select On to set relays I01, I02, and I03 Reflash=Off to reflash alarm operation. Select the range of relays that are to AND=None operate using AND logic.
  • Page 123 7.1 Changing the Auxiliary Alarm Function Reflash Turns On/Off the reflash alarm operation of alarm output relays I01, I02, and I03. When set to On, alarm output relays I01, I02, and I03 set to reflash alarm operation, and the operation is fixed to OR, de-energized, and non-hold. Sets the AND/OR operation of alarm output relays.

  • Page 124: Changing The Integration Time Of The A/D Converter

    7.2 Changing the Integration Time of the A/D Converter This section explains the details of setting the integration time of the A/D converter. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option). Procedure Changing the Settings Hold down the...

  • Page 125: Setting The Burnout Detection Function Of Thermocouples

    7.3 Setting the Burnout Detection Function of Thermocouples This section explains the details of setting the burnout detection function of thermocouples to channels set to 1-5V or TC input. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option).

  • Page 126: Setting The Rjc Function On Channels Set To Tc Input

    7.4 Setting the RJC Function on Channels Set to TC Input This section explains the details of setting RJC on channels set to TC input. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option). Procedure Changing the Settings Hold down the...
  • Page 127 7.4 Setting the RJC Function on Channels Set to TC Input Explanation Sets the RJC mode. Internal: Uses the RJC function on the recorder. External: Uses an external RJC function. If external is selected, set the compensation voltage. Volt Sets the compensation voltage when using an external RJC function. The compensation voltage can be set in the range of -20000 µV to 20000 µV.

  • Page 128: Changing The Channel Recording Color (Dot Model)

    7.5 Changing the Channel Recording Color (Dot Model) This section explains the details of changing the trend recording color on the dot model. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option). Procedure Changing the Settings Hold down the...

  • Page 129: Recording By Compensating For The Pen Offset Along The Time Axis (Pen Model)

    7.6 Recording by Compensating for the Pen Offset along the Time Axis (Pen Model) This section explains the details of setting the compensation for the pen offset along the time axis (pen model). Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option).

  • Page 130: Turning Printouts On/Off

    7.7 Turning Printouts ON/OFF. This section explains the details of turning ON/OFF the printouts of various items. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option). Procedure Changing the Settings Hold down the...
  • Page 131 7.7 Turning Printouts ON/OFF. Applying the Changes and Returning to Operation Mode key or SHIFT + key to select End and then press the Press the key. key to select Store and then press the Press the key. The changes are applied, and the screen returns to Operation mode.

  • Page 132: Setting The Periodic Printout Interval And The Type Of Measured Values To Be Printed

    7.8 Setting the Periodic Printout Interval and the Type of Measured Values to Be Printed This section explains the details of setting the periodic printout interval and the type of measured values to be printed. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option).
  • Page 133 7.8 Setting the Periodic Printout Interval and the Type of Measured Values to Be Printed Types of Report Data to Be Printed Changing the Settings Hold down the key for 3 seconds to enter Setting mode. MENU Hold down the keys simultaneously for 3 seconds to enter Basic Setting mode.
  • Page 134 7.8 Setting the Periodic Printout Interval and the Type of Measured Values to Be Printed Explanation Periodic Printout Interval Periodic Select the periodic printout interval mode. Auto: Automatically sets the printout interval in sync with the chart speed. Manual: Set the printout interval manually. Ref.

  • Page 135: Setting The Bar Graph Display Mode

    7.9 Setting the Bar Graph Display Mode This section explains the details of setting the bar graph display mode. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option). Procedure Changing the Settings Hold down the...

  • Page 136: Setting The Key Lock Function

    7.10 Setting the Key Lock Function This section explains the details of setting the keys that can be locked and the password for releasing the key lock. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option).
  • Page 137 7.10 Setting the Key Lock Function Basic=Key Lock Select whether to use the key lock Keylock=Use function. Set the password for releasing the key Password= lock. Select Lock to apply the key lock function RCD=Free to the RCD key. Select Lock to apply the key lock function Feed=Free to the FEED key.
  • Page 138 7.10 Setting the Key Lock Function Applying the Changes and Returning to Operation Mode key or SHIFT + key to select End and then press the Press the key. key to select Store and then press the Press the key. The changes are applied, and the screen returns to Operation mode.

  • Page 139: Enabling The Moving Average Function (Dot Model)

    7.11 Enabling the Moving Average Function (Dot Model) This section explains the details of enabling/disabling the moving average function on the dot model. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option). Procedure Changing the Settings Hold down the...

  • Page 140: Enabling The Filter Function (Pen Model)

    7.12 Enabling the Filter Function (Pen Model) This section explains details of enabling/disabling the input filter function on the pen model. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option). Procedure Changing the Settings Hold down the...

  • Page 141: Enabling The Partial Expanded Recording Function

    7.13 Enabling the Partial Expanded Recording Function This section explains the details of enabling/disabling the partial expanded recording function. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option). Procedure Changing the Settings Hold down the...

  • Page 142: Changing The Display/Recording Language

    7.14 Changing the Display/Recording Language This section explains the details of changing the display/recording language. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option). Procedure Changing the Settings Hold down the...

  • Page 143: Enabling The Bias Function, Low-Cut Function, And Alarm Delay Function

    7.15 Enabling the Bias Function, Low-Cut Function, and Alarm Delay Function This section explains the details of enabling/disabling the bias function, low-cut function, and the alarm delay function. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option).
  • Page 144 7.15 Enabling the Bias Function, Low-Cut Function, and Alarm Delay Function Explanation Bias Enables/Disables the bias function. Use: Enables the setting of the bias value in Setting mode. Not: The Bias item does not appear in Setting mode. SQRT low-cut Enables/Disables the square root low-cut function.

  • Page 145: Changing The Time Printout Format

    7.16 Changing the Time Printout Format This section explains the details of changing the time printout format of alarm printout, message printout, recording start printout, and new chart speed printout. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option).
  • Page 146 7.16 Changing the Time Printout Format Explanation Alarms Sets the time printout format of the alarm printout. HH:MM: Hour:Minute HH:MM:SS: Hour:Minute:Second M/D H:M: Month/Day Hour:Minute M/D H:M:S: Month/Day Hour:Minute:Second YMD H:M:S: Year/Month/Day Hour:Minute:Second Message Sets the time printout format of the message printout. HH:MM: Hour:Minute HH:MM:SS: Hour:Minute:Second...

  • Page 147: Initializing The Settings

    7.17 Initializing the Settings This section explains the details of initializing the recorder settings to their factory default. Be careful, because all settings except the date/time setting in the recorder will be initialized. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option).

  • Page 148: Assigning Functions To The Remote Control Input Terminals (/R1 Option)

    7.18 Assigning Functions to the Remote Control Input Terminals (/R1 Option) This section explains the details of assigning functions to the input terminals of the remote control function. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option).
  • Page 149 7.18 Assigning Functions to the Remote Control Input Terminals (/R1 Option) Explanation Remote No. The remote control terminal numbers are from 1 to 5. Function to Be Assigned Record On/Off: Starts/stops recording. Alarm ACK: Executes alarm output release. Time adjust: Adjusts the internal clock to the nearest hour.

  • Page 150: Changing The Temperature Unit

    7.19 Changing the Temperature Unit This section explains the details of changing the temperature unit on the temperature measurement channels. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option). Procedure Changing the Settings Hold down the...

  • Page 151: Chapter 8 Setup Operations For Changing The Displayed Contents

    Chapter 8 Setup Operations for Changing the Displayed Contents 8.1 Key Operations for Changing the Displayed Information Displaying the Data Display Setup Screen Hold the key for 3 seconds to show the data display setup screen. MENU Power ON Hold down MENU or 3 s to switch.
  • Page 152 8.1 Key Operations for Changing the Displayed Information Data Display Setup Menu This menu is used to assign display types to screen 01 to 15. The indicates a display type. The items to set for each type are shown to the right of the display type. Display type Screen 1-channel digital display...

  • Page 153: Changing The Displayed Information

    8.2 Changing the Displayed Information This section explains the details of registering display types to screens 01 to 15. As an example, the procedure of setting 1-channel digital display is explained below. Procedure 1-Channel Digital Display Hold the key for 3 seconds to show the data display setup screen. MENU key or SHIFT + Press the...

  • Page 155: Chapter 9 Operations Related To The Computation Function (/M1 Option)

    Chapter 9 Operations Related to the Computation Function (/M1 Option) 9.1 Starting/Stopping/Resetting the Computation This section explains the details of starting/stopping the computation and resetting the statistical calculation value (TLOG computation). Procedure Starting the Computation Press the key. FUNC key to show Math and then press the Press the key.

  • Page 156: Setting The Computing Equation

    9.2 Setting the Computing Equation The computing equation cannot be entered when the computation is in progress. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Math and then press the Press the key.
  • Page 157 9.2 Setting the Computing Equation Each time you press the CHARACTER key the display changes as shown below. key or SHIFT + Pressing the key switches the character within the selected character type and displays the character at the cursor position. Display ( key) Description Character (...
  • Page 158 Enter the data as C01 to C12 in the equations. Range of values (maximum significant digits is 5): -9.9999E+29 to -1.0000E-30, 0, 1.0000E-30 to 9.9999E+29 For the procedure of setting the communication input data, see the SBR-EW100 Recorder Communication Interface User’s Manual (IMSBR07-E). IMSBR07-E1...
  • Page 159 9.2 Setting the Computing Equation • Status of the Remote Control Input Terminal (D01 to D05, /R1 option) The status of the remote control input signal (1 or 0) can be used in the computation. Use D01 to D05 (the number following the letter D is the remote control input terminal number) to specify the status in the equations.
  • Page 160 9.2 Setting the Computing Equation Relational Computation The data that can be used in equations are measured values, computed values, constants, communication input data, and remote control input terminal status. You can specify a computing equation that performs relational computation on a computing element.
  • Page 161 9.2 Setting the Computing Equation Logical sum (Syntax) e1ORe2 (Condition) If the two data values e1 and e2 are both zeroes, the computed result is [0]. Otherwise, it is [1]. (Explanation) e1 = 0 → e1ORe2 = 0 e2 = 0 e1 ≠...
  • Page 162 9.2 Setting the Computing Equation TLOG Computation Only measured values and computed values can be used in TLOG computation. In the explanation below, e1 is used to represent a measurement or computation channel. You cannot specify an equation that contains a computing element inside e1. In addition, only one TLOG computation can be specified in a single computing equation.

  • Page 163: Setting The Unit

    9.3 Setting the Unit This section explains the details of setting the unit on computation channels. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Math and then press the Press the key.

  • Page 164: Setting The Constants Used In Equations

    9.4 Setting the Constants Used in Equations This section explains the details of setting constants to be used in computing equations. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Math and then press the Press the key.

  • Page 165: Setting The Alarm

    9.5 Setting the Alarm This section explains the details of setting alarms for each computation channel. If you change the computing equation or the recording span, set the alarm again. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Math and then press the...
  • Page 166 9.5 Setting the Alarm Explanation Alarm Type Symbol Name High limit alarm Low limit alarm Delay high limit alarm* Delay low limit alarm* * Selectable only when the alarm delay function is enabled. See section 7.15. If delay high limit alarm or delay low limit alarm is specified, set the alarm delay time. <Related Topics>...

  • Page 167: Specifying The Timer Used In Statistical Calculations (Tlog)

    9.6 Specifying the Timer Used in Statistical Calculations (TLOG) On channels that perform statistical calculation (TLOG), the timer for determining the interval is specified. The sum scale is also specified when using statistical calculation. The timer is also used for the periodic printout of computed values. Procedure Hold down the key for 3 seconds to enter Setting mode.
  • Page 168 9.6 Specifying the Timer Used in Statistical Calculations (TLOG) Explanation Timer No. There are three timers. Periodic: The timer for determining the periodic printout interval. Statistical calculation is performed every periodic printout interval, and the computed value is printed. The timer of timer No. 1. Statistical calculation is performed every timer 1 interval.

  • Page 169: Setting Recording Zones For Each Channel (Zone Recording)

    9.7 Setting Recording Zones for Each Channel (Zone Recording) This section explains the details of setting the recording zone for each computation channel. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Math and then press the Press the key.

  • Page 170: Setting The Partial Expanded Recording

    9.8 Setting the Partial Expanded Recording This section explains the details of expanding a section of the recording range. If you change the computing equation or the recording span, set the partial expanded recording again. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Math and then press the...

  • Page 171: Turning Trend Recording (Dot Model) And Periodic Printout On/Off For Each Channel

    9.9 Turning Trend Recording (Dot Model) and Periodic Printout ON/OFF for Each Channel This section explains the details of setting the trend recording and periodic printout for each computation channel. The following settings can be entered for each channel on the dot model. •...

  • Page 172: Setting Tags On Channels

    9.10 Setting Tags on Channels This section explains the details of setting the tag on computation channels. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Math and then press the Press the key.

  • Page 173: Setting The Alarm Delay Duration

    9.11 Setting the Alarm Delay Duration This section explains the details of setting the duration of the delay high limit and delay low limit alarms. Procedure Hold down the key for 3 seconds to enter Setting mode. MENU key or SHIFT + key to select Math and then press the Press the key.

  • Page 174: Setting The Timer Used In Tlog Computation And Periodic Printout

    9.12 Setting the Timer Used in TLOG Computation and Periodic Printout This section explains the details of setting the timer used in TLOG computation and periodic printout. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option).
  • Page 175 9.12 Setting the Timer Used in TLOG Computation and Periodic Printout Applying the Changes and Returning to Operation Mode key or SHIFT + key to select End and then press the Press the key. key to select Store and then press the Press the key.
  • Page 176 9.12 Setting the Timer Used in TLOG Computation and Periodic Printout Reset Selects whether to reset the TLOG computed value at each interval. The figure below illustrates the reset operation for sum computation (TLOG.SUM). Example: TLOG.SUM computation Timer timeout Reset Reset Reset Reset: On...

  • Page 177: Changing The Channel Recording Color (Dot Model)

    9.13 Changing the Channel Recording Color (Dot Model) This section explains the details of changing the recording colors of measurement channels and computation channels. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option). Procedure Changing the Settings Hold down the...

  • Page 178: Changing The Channel Assignments Of Recording Pens (Pen Model)

    9.14 Changing the Channel Assignments of Recording Pens (Pen Model) Measurement channels and computation channels can be arbitrarily assigned to recording pens. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option). Procedure Changing the Settings Hold down the...

  • Page 179: Changing The Type Of Report Data Printed In Periodic Printout

    9.15 Changing the Type of Report Data Printed in Periodic Printout This section explains the details of selecting the type of computed value (the average, minimum, maximum, sum, or instantaneous) printed in periodic printout Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option).
  • Page 180 9.15 Changing the Type of Reported Data Printed in Periodic Printout Explanation Mode Sets the type of report data to be printed. AVE: Prints the average value over the interval. MIX: Prints the minimum, maximum, and average values over the interval. SUM: Prints the sum value over the interval.

  • Page 181: Setting The Bar Graph Display Mode

    9.16 Setting the Bar Graph Display Mode This section explains the details of setting the bar graph display mode. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option). Procedure Changing the Settings Hold down the...

  • Page 182: Setting The Procedure Taken When The Computed Result Is In Error

    9.17 Setting the Procedure Taken When the Computed Result Is in Error This section explains the details of setting the procedure taken when the computed result is in error. Basic Setting mode cannot be entered when recording is in progress or when computation is in progress on models with the computation function (/M1 option).
  • Page 183 9.17 Setting the Procedure Taken When the Computed Result Is in Error Explanation Error Specifies how to display or print the computed result when computation errors occur. +Over: Set to +over. Displayed/Printed as [+Over]. -Over: Set to Ðover. Displayed/Printed as [-Over]. Computation that result in errors •...

  • Page 185: Chapter 10 Troubleshooting

    Chapter 10 Troubleshooting 10.1 A List of Error Messages There are cases in which error codes and messages are displayed on the screen during operation. The error messages and their description are listed below. Setting Errors Code Message Explanation/Countermeasures System error. Contact your nearest RKC dealer.
  • Page 186 10.1 A List of Error Messages Code Message Explanation/Countermeasures This key is locked. Password is incorrect. Enter the correct password. IP address doesn’t belong to class A, B, or C. The result of the masked IP address is all 0s or 1s. - SUBNET mask is incorrect.
  • Page 187 10.1 A List of Error Messages Code Message Explanation/Countermeasures Login incorrect, try again! No more login at the specified level is acceptable. Connection has been lost. The number of simultaneous connection has been exceeded. Communication has timed-out. Warning Messages Code Message Explanation/Countermeasures Initialized.

  • Page 188: Troubleshooting Flow Charts

    10.2 Troubleshooting Flow Charts Follow the flow charts to correct the problem. Nothing works (pen and chart paper do not move). Is the power switch Turn ON the power properly. Section 2.6 turned ON? Does the switch work properly? Is the power supply Connect properly.
  • Page 189 10.2 Troubleshooting Flow Charts From the previous page • Separate the input wiring from the noise source. • Ground the recorder properly. Is the input free of noise? • Ground the measured object properly. • Insulate the TC from the measured object. •...
  • Page 190 10.2 Troubleshooting Flow Charts Display and other functions do not work properly. • Separate the input and communication wiring from the Is the input free of noise? noise source. • Ground the recorder properly. • Use shielded cables for input and communication wiring.

  • Page 191: Chapter 11 Maintenance

    Chapter 11 Maintenance 11.1 Periodic Inspection Check the operation periodically to keep the recorder in good working order. Perform the following checks and replace worn parts as needed. • Is the indication and recording functioning properly? If not, see chapter 10. •...

  • Page 192: Cleaning The Recorder

    11.2 Cleaning the Recorder CAUTION • When cleaning, be sure not to scratch the flexible printed circuit board of the plotter carriage. • Do not apply lubricating oil to the shaft. Pen Model To maintain smooth operation, it is recommended that the plotter carriage shaft be cleaned once a year.

  • Page 193: Replacing The Internal Light Led

    11.3 Replacing the Internal Light LED If the brightness of the internal light degrades with time, replace the LED. For the replacement parts, see section 11.7. CAUTION • The LED is connected to the internal circuitry through the flexible printed circuit board.

  • Page 194: Calibrating The Recorder

    11.4 Calibrating the Recorder Calibrate the measured value against the input. It is recommended that the recorder be calibrated once a year to assure its measurement accuracy. For details regarding calibration, contact your nearest RKC dealer. Required Instruments A calibration instrument with appropriate resolution is required for calibrating the recorder.
  • Page 195 11.4 Calibrating the Recorder Temperature Measurement When Using an RTD The resistance of three lead wires must be equal. −/B Decade resistance box Input terminals Temperature Measurement When Using a Thermocouple Copper wires Thermocouple wires or TC extension wires – –...

  • Page 196: Adjusting The Pen Position (Pen Model)

    11.5 Adjusting the Pen Position (Pen Model) This section explains the details of adjusting the pen position on the chart paper. It is recommended that the pen be adjusted once a year to assure its recording accuracy. Procedure Warm up the recorder for at least 30 minutes. Check that the operating environment such as ambient temperature and humidity is within the standard operating conditions (see chapter 12).

  • Page 197: Adjusting The Dot Printing Position (Dot Model)

    11.6 Adjusting the Dot Printing Position (Dot Model) This section explains the details of adjusting the dot printing position on the chart paper. It is recommended that the position be adjusted once a year to assure its recording accuracy. Procedure Warm up the recorder for at least 30 minutes.
  • Page 198 11.6 Adjusting the Dot Printing Position (Dot Model) Press the ESC key to finish the adjustment. The screen returns to the Basic=P_Adj screen. Basic=P_Adj Select Zero or Full. P_Adj=Hysteresis Change the value to adjust the pen Hysteresis=-2 position. The dot printing position moves. P_Adj ESC/? Setting complete...

  • Page 199: Recommended Replacement Periods For Worn Parts

    11.7 Recommended Replacement Periods for Worn Parts To preserve the reliability of the recorder and to use the recorder in good condition for an extended time, it is recommended that periodic replacements be made on parts. The table below shows the recommended replacement period for expendable parts. The replacement period shown here applies when the recorder is used under standard operating conditions.
  • Page 200 11.7 Recommended Replacement Periods for Worn Parts Dot Model Replacement Quantity Item Part Name Part No. Note Period Used Z-fold chart paper 33 days CHART B-100EX When used at 20 mm/h Ribbon cassette 3 months RIBBON CASSETTE B9901AX Display DISPLAY ASSY 5 years* B8800CA Chart paper feed...

  • Page 201: Chapter 12 Specifications

    Chapter 12 Specifications 12.1 Input Specifications Number of Inputs and Scan Interval on the Pen Model Item Specifications Number of inputs 1, 2, 3, or 4 Scan interval 125 ms Number of Inputs and Scan Interval on the Dot Model Item Specifications Number of inputs...
  • Page 202 12.1 Input Specifications Item Specifications Input type Floating unbalanced input. Isolation between channels (except, b terminal is shared for RTD input). Burnout Detection of TC Can be set for each channel. Upscale/Downscale switchable (common to all channels). Input Type Operating Conditions 2 kΩ...

  • Page 203: Alarm Function Specifications

    12.2 Alarm Function Specifications Item Specifications Number of alarms Up to four alarms (level) for each measurement channels. Alarm types High limit (H), low limit (L), difference high limit (h), difference low limit (l), high limit on rate-of- change (R), low limit on rate-of-change (r), delay high limit (T), delay low limit (t). The symbol indicating the alarm is given in parentheses.

  • Page 204: Recording Function Specifications

    12.3 Recording Function Specifications Trend Recording (Pen Model) Item Specifications Recording pen Disposable felt pen Step response time Approx. 1 s (using the IEC61143 measurement method) Number of pens Up to 4 Recording color Channel 1: Red, channel 2: Green, channel 3: Blue, channel 4: Violet Trend recording Updates the data at the scan interval.
  • Page 205 12.3 Recording Function Specifications Printouts (Pen Model) Item Specifications Recording pen (color) Plotter pen (purple) Alarm printout Prints alarm occurrence/release. Printout contents Occurrence ( )/release ( ) marks, channel No. or tag, alarm type, alarm level, time, printout buffer overflow mark. Time printout format Selectable from hour:minute, hour:minute:second, month:day:hour:minute, month:day:hour:minute:second, and year:month:day:hour:minute:second.
  • Page 206 12.3 Recording Function Specifications Printout (Dot Model) Item Specifications Recording Dot printing. Channel printout Prints the channel number beside the trend recording every approx. 25 mm of chart paper. Channel printout ON/OFF selectable. Alarm printout Prints alarm occurrence/release. Printout contents Occurrence ( , red)/release ( , blue) marks, channel No.

  • Page 207: Display Function Specifications

    12.4 Display Function Specifications Display and Displayed Contents This section explains the specifications of the display functions of measurement channels and computation channels (/M1 option). Display examples are illustrations used to explain the displayed contents and differ in appearance from the actual displays. Item Specifications VFD (101 ×...
  • Page 208 12.4 Display Function Specifications Item Specifications Display type specifications Digital display Measured value or computed value • DC voltage input: Displays values between “the min. measurable value - 5% of the span of the measurable range” and “the max. measurable value + 5% of the span of the measurable range2” of the range (example: -2.200 to 2.200 V for the 2 V range).
  • Page 209 12.4 Display Function Specifications Item Specifications Flag display Displays measured values using flags. Display channel The flag can be turned ON/OFF for each channel. Flag (If flags overlap, the channel with the smallest number is displayed on top) Scale Displays 10 equally spaced scale marks. Channel alarm status display Lists the alarm status of all channels using the symbols below.
  • Page 210 12.4 Display Function Specifications Name Display Example Description Measurement channel 1-channel digital display Channel No. (1 digit), alarm (1 digit), 1H3000.0ABC measured value (6 digits), unit (3 digits) Displays using 5 × 7 dots when the unit Alarm Measured Unit exceeds 3 digits.
  • Page 211 12.4 Display Function Specifications Name Display Example Description DI/DO status display DI/DO status. Displays the appropriate mark. Status display Chart end Alarm Lights off No display. 1-channel digital display Measurement channel Tag (7 digits), alarm (1 digit), (Tag display) abcdefg measured value (7 digits), unit (6 digits) H-1999.9ABCDEF Alarm...
  • Page 212 12.4 Display Function Specifications Multiple display (Different screens assigned to the top and bottom sections) Name Display Example Description 1-channel digital display Channel No. (1 digit), alarm (1 digit), 1H-1999.9ABCDEF measured value (7 digits), unit (6 digits) Measurement channel Channel No. (1 digit), alarm (1 digit), AH9999999.9ABCDEF computed value (9 digits), unit (6 digits) 2-channel digital display...

  • Page 213: Specifications Of Optional Functions

    12.5 Specifications of Optional Functions Alarm Output Relay (/A1, /A2, and /A3) Item Specifications Operation Outputs relay contact signals from the dedicated terminals on the rear panel when alarms occur. Number of outputs 2 outputs (/A1), 4 outputs (/A2), 6 outputs (/A3) Relay contact rating 250 VDC/0.1 A (for resistance load) 250 VAC (50/60 Hz)/3 A...
  • Page 214 12.5 Specifications of Optional Functions FAIL/Chart End Detection and Output (/F1) Item Specifications FAIL output Relay output on CPU error Relay operation Energized during normal operation and de-energized on CPU error. Non-hold operation. Chart end detection output Stops recording and outputs a relay signal when the remaining amount of chart paper is approx. 2 cm.
  • Page 215 12.5 Specifications of Optional Functions Cu10, Cu25 RTD Input (/N1) Item Specifications Cu10, Cu25 RTD This option allows Cu10 and Cu25 inputs to be added to the standard input types. Input type and measurable range Input Type Measurable Range Cu10 (GE) Cu10 (L&N) Cu10 (WEED) –200 to 300°C...
  • Page 216 12.5 Specifications of Optional Functions Item Specifications Measurement and recording accuracy Input Type Measurement Accuracy Recording Accuracy PR40-20 0 to 450°C Not warranted 450 to 750°C ±(0.9% of rdg + 3.2°C) 750 to 1100°C ±(0.9% of rdg + 1.3°C) 1100 to 1900°C ±(0.9% of rdg + 0.4°C) PLATINEL ±(0.25% of rdg + 2.3°C) NiNiMo...

  • Page 217: General Specifications

    12.6 General Specifications Construction Item Specifications Mounting Flush panel mounting (on a vertical plane) Mounting angle Inclined backward up to 30 degrees from a horizontal plane. Allowable panel thickness 2 to 26 mm Material Case: drawn steel Front door: Aluminum die-cast Color Case: Charcoal gray light (Munsell 10B3.6/0.3 or equivalent) Front door: Charcoal gray light (Munsell 10B3.6/0.3 or equivalent)
  • Page 218 12.6 General Specifications Isolation Item Specifications Insulation resistance Each terminal to ground terminal: 20 MΩ or more (at 500 VDC) Dielectric strength Power supply to ground terminal: 1500 VAC (50/60 Hz), 1 minute Contact output terminal to ground terminal: 1500 VAC (50/60 Hz), 1 minute Measuring input terminal to ground terminal: 1000 VAC (50/60 Hz), 1 minute Between measuring input terminals: 1000 VAC (50/60 Hz), 1 minute (except for RTD input terminal) Remote input terminal to ground terminal: 500 VDC, 1 minute...
  • Page 219 12.6 General Specifications Standard Performance Item Specifications Measurement and recording accuracy The following specifications apply to operation of the recorder under standard operation conditions: Temperature: 23 ± 2°C Humidity: 55% ± 10%RH Power supply voltage: 90 to 132 or 180 to 264 VAC Power supply frequency: 50/60 Hz ±...
  • Page 220 12.6 General Specifications Item Specifications Reference junction compensation accuracy Above 0°C with input terminal temperature balanced (60 minutes after power on) Type R, S, B, W, WRe: ±1.0°C Type K, J, E, T, N, L, U: ±0.5°C Maximum input voltage ±10 VDC (continuous) for ranges of 200 mV or less, TC, RTD, and DI ranges ±60 VDC (continuous) for 2 VDC or higher ranges Input resistance...

  • Page 221: Dimensional Drawings

    12.7 Dimensional Drawings Unit: mm Unless otherwise specified, tolerance is ±3% (however, tolerance is ±0.3 mm when below 10 mm). 27.5 151.5 2-26 Mounting panel (Dimensions before attaching thickness the mounting bracket) 136.5 151.5 (Dimensions after attaching the mounting bracket) Note When mounting the recorder to a panel, use two brackets, top and bottom or left and right.

  • Page 223: Appendix

    Appendix Appendix 1 Periodic Printout and Printout Using the TLOG Timer (/M1 Option) Periodic Printout This section explains the contents of the periodic printout. The periodic printout contents vary between the pen model and dot model. The contents also vary depending on whether the periodic printout is in instantaneous mode, report mode, or Off.

  • Page 224: Appendix 1 Periodic Printout And Printout Using The Tlog Timer (/M1 Option)

    Appendix 1 Periodic Printout and Printout Using the TLOG Timer (/M1 Option) • Scale Prints the leftmost and rightmost values of the recording span and the channel number or tag for channels that have scale printout specified. The scale is printed for one channel at each periodic printout.
  • Page 225 Appendix 1 Periodic Printout and Printout Using the TLOG Timer (/M1 Option) Dot Model Instantaneous Mode Prints the letter “d” for channels set to Channel No. Measured delta computation. or tag value Unit Date Mar.31.2004 Time 15:50 Channel data TAG-001 1.000V -1.000V H-2.1050UNIT03...
  • Page 226 Appendix 1 Periodic Printout and Printout Using the TLOG Timer (/M1 Option) Printout Using the TLOG Timer (/M1 Option) Prints the computed values of computation channels for each interval determined by the TLOG timer. Pen Model Channel No. or tag Offset compensation mark/event Measured value...
  • Page 227 Appendix 1 Periodic Printout and Printout Using the TLOG Timer (/M1 Option) Special Cases This section explains the operation of the periodic printout report (statistical calculation) and the TLOG computation for special cases. In the explanation below, statistical calculation represents computation in periodic printout report mode or TLOG computation.

  • Page 229: Index

    Index chart speed ............. 1-14, 5-13 Symbols cleaning ................11-2 clearing alarm information ..........3-14 1-5V ..................1-2 comment line ............... 4-3 1-5V input ................5-6 common logarithm ............1-24 1-5V low-cut function ............7-24 communication input data ........... 9-4 compensation voltage ............
  • Page 230 Index menu (data display setup) ........... 8-2 menu (setting mode) ............4-6 message ................6-8 FAIL output ............... 1-27 message printout .............. 1-19 fastest recording interval ........... 1-26 model ..................iv feeding the chart paper ............3-6 mounting brackets ............... 2-3 felt pen ................
  • Page 231 Index standard accessories ............. v standard performance ............. 12-19 standard temperature device ..........11-5 range type ................1-2 standard time ............5-14, 6-13 rear panel ................3-3 start recording ..............3-10 recorder ................1-1 starting the computation ............9-1 recording ................1-13 status display ..............
  • Page 232 Subkect to change without notice due to design changes. The first edition : APR.2005 [IMQ00] HEADQUARTERS: 16-6, KUGAHARA 5-CHOME, OHTA-KU TOKYO 146-8515 JAPAN PHONE: 03-3751-9799 (+81 3 3751 9799) E-mail: info@rkcinst.co.jp RKC INSTRUMENT INC. FAX: 03-3751-8585 (+81 3 3751 8585) APR.2005 IMSBR07-E1...

Table of Contents
