ASSEMBLY INSTRUCTIONS
BH47-021-199-22
UPC# 050277000258
WARNING:
The maximum weight load capacity is 25
lbs (11.33 kgs). Exceeding capacity may
result in collapse and possible injury.
CHEYENNE PRODUCTS
** THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
DO NOT RETURN THIS ITEM TO THE STORE OR CONTACT THE RETAILER
**
In the unlikely event that you should have a problem with your merchandise, o
parts, Please contact our dedicated customer service team at 1-800-737-5267 or email
customerservice@cheyenneproducts.com to request parts or assistance with your
merchandise. Our offices are open Monday through Friday between 8:00 AM and 5:00 PM -
(Central Standard Time) - excluding major holidays. Our customer service representatives
are committed to resolving your problem as quickly as possible.
** Assemble on soft surface to prevent damage to the product finish.
** Carefully remove all parts from the box and make sure that no parts listed on
the assembly instructions are missing.
** Cheyenne products is committed to helping save the environment for future
generations. We encourage you to reuse or recycle all of the materials used in
the packaging of this product.
LOT NUMBER:
DATE OF PURCHASE:
r you are missing
