Page 1 Daymark LED Headlight Operating Manual...
Page 3: Table Of Contents
Table of Content Symbol Description ..................2 Warnings and Cautions ................3 Intended Use ....................... 4 Unintended Uses ......................4 Overview .....................5 System Description ...................... 5 Assembly and Operation ................6 Ferrite .......................... 6 Headlight ........................7 Classic Headband ......................8 Key West Headband ....................8 Controller ........................
Page 4: Symbol Description
Symbol Description These important symbols may appear on your Long Island Technology Group Optic Headlight. Please note their meaning. Attention: Read this owner’s manual for all warnings, precautions and instructions for use. CE marking of conformity indicates this device complies with European Directive 93/42 EC on medical devices and Directive 2002/95/EC on the restriction of the use of certain hazard- ous substances in electrical and electronic equipment.
Page 5: Warnings And Cautions
DO NOT use this device for anything other than its intended use. DO NOT modify this equipment. DO NOT open device. No serviceable components are inside device. Only Qualified Personnel should operate the BFW Daymark DO NOT submerge the device or any of its components in liquid.
Page 6: Intended Use
WARNING Portable RF communications equipment (including peripherals such as antenna cables and external antennas) should be used no closer than 30 cm (12 inches) to any part of the Daymark , in- cluding cables specified by the manufacturer.
Page 7: Overview
Overview System Description The BFW Daymark LED Headlight is constructed of durable plastic housing encasing a precision aluminum lens system holder with glass anti-reflective coated lenses and a spot size adjusting iris. Light is provided by a high power LED, driven by a solid state controller and battery to provide ON/OFF and 5 levels of light output.
Page 8: Assembly And Operation
Ferrite 1. Open the Ferrite by pulling on the tab. 2. Attach the provided Ferrite onto the Power Cable close to the connector over-mold. DO NOT use the Daymark without the Ferrite as it may result in non-compliant EMC levels.
Page 9: Headlight
Headlight Front Lens Iris Adjustment Ring Power Cable Mounting Linkage Daymark Operation: 1. The lower portion of the headlight (below the Iris Adjustment Ring) can be turned a small amount to the left and right to facilitate aiming the light.
Page 10: Classic Headband
Assembly and Operation Classic Headband Adjustment Knobs Classic Headband Adjustment: 1. Turn the Adjustment Knobs (A) to tighten or loos- en the headband. Key West Headband Adjustment Tab Release Button Key West Headband Adjustment: 1. To tighten pull on the Adjustment Tab (A). 2.
Page 11: Controller
Assembly and Operation Controller Power Connector Battery Holster and Battery Side Buttons Battery Holster/Controller: 1. Connect headlight cable to Power Connector (A), secure threaded cap tightly. 2. Attach the holster to waistband with the holster clip. 3. To turn the light on, push either of the Side Buttons (C). 4.
Page 12: Battery
Assembly and Operation Battery Your BFW Daymark will come with one of two versions of the 4-cell batteries shown below. 1. To Remove the battery from the holster pull the Retaining Tab (A) or pushing the battery though the Ac- cess Hatch (B) on the back of the holster.
Page 13: Charging The Battery
Assembly and Operation Charging the Battery Your BFW Daymark may come with one of two versions of battery chargers shown below. Regular on the left and Mini on the right. Charging Indicator (See Table Below)* Charging Indicator* Green Blinking Battery is currently being charged...
Page 14: Linkage Assembly
Assembly and Operation Linkage Assembly Headband (Classic Shown) Headlight Bolt Barrel Washer X 2 Set Screw Flathead Screwdriver Allen Wrench DO NOT use Thread Locking Glue On the Linkage. Can Cause Irreparable Damage to Linkage Leading to a Hazardous Situations...
Page 15: Removing The Headlight
Assembly and Operation Removing the Headlight 1. Use the Allen wrench and Phillips head screwdriver to unlock the binding post. 2. Use the flathead screwdriver and Phillips head screwdriver to unscrew the binding post.
Page 16: Mounting The Headlight
Assembly and Operation Mounting the Headlight 3. Put the linkage in-between the fork bar. 4. Place the washers concave side towards the fork on the outsides of the fork.
Page 17 Assembly and Operation 5. Place the barrel through the left side of the fork bar. 6. Thread the bolt into the right side of the fork bar and tighten the binding post with the flathead and Phil- lips screwdriver.
Page 18 Assembly and Operation 7. Place the set screw inside the barrel and tighten it using the Allen wrench and Phillips screwdriver.
Page 19: Cleaning And Maintenance
3. Use a can of compressed air to clean out any dust accumulations. DO NOT pour cleaning solution directly on the surface of the Daymark DO NOT use any sterilization process or cleaning process using excessive heat or humidity as it will...
Page 20: Specifications
Specifications Classification Classification & Type Class I: Medical Accessory, General Medical Equip- ment as to fire and mechanical hazards Environment Operation 60 Degrees F (15 C) to 80 Degrees F (26.7 C) Storage 23 Degrees F (0 C) to 104 Degrees F (40 C) Relative Humidity 45% - 75% Pressure/Altitude...
Page 21: Electromagnetic Compatibility
Portable and mobile RF communications equipment can affect medical electrical equipment Guidance and manufacturer’s declaration-electromagnetic emissions The Daymark is intended for use in the electromagnetic environment specified below. The customer or the user of the Daymark should assure that it is used in such an environment Immunity...
Page 22 Daymark (2) Over the frequency range 150kHz to 80MHz, field strengths should be less than 3 V/m. Recommended separation distances between portable and mobile RF communications equipment and the Daymark The Daymark is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The cus-...
Page 23 0 % UT; 1 cycle 0 % UT; 1 cycle power supply input tions, it is recommended that the Daymark lines be powered from an uninterruptible power 70 % UT; 25/30 cycles 70 % UT; 25/30 cycles supply or a battery.
Page 24 Electromagnetic Compatibility Guidance and manufacturer’s declaration - Electromagnetic Emissions The Daymark is intended for use in the electromagnetic environment specified below. The customer or the end user of the Day- mark should assure that it is used in such an environment.
Page 25: Troubleshooting And Service
Recharge the battery Warranty and Service Warranty against manufacturer’s defects applies to the following components of the Daymark™ under normal use for one (1) year from the date of sale from Long Island Technology Group (includes parts and labor). • LED Optics •...
Page 26 Scan Here to See All Long Island Technology Group Manuals Or Visit: http://www.litgp.com/manuals Contents are fragile. Contains Li-on batteries, Handle with care. Conforms to: IEC 60601-1 Edition 4, IEC 60601-1-2 Edition 3 60 Carolyn Blvd, Farmingdale NY 11735 AAMI ES60601-1 Edition 1, CSA C22.2 NO 60601-1:08 Edition 2 (631) 270-4463 litgp.com Manufactured by Long Island Technology Group, LLC Revision 2.5...
